EQM w/Relative Humidity
Sensor Control (S224250)
Owner's Parts and Instruction Manual
Sioux Steel Company
Sioux Falls, South Dakota 57101
800-557-4689
Manual No. 224252
04-23-2020/KAG
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S224250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sioux Tools S224250

Summary of Contents for Sioux Tools S224250

  • Page 1 S TEEL COMPA N Y EQM w/Relative Humidity Sensor Control (S224250) Owner’s Parts and Instruction Manual Sioux Steel Company Sioux Falls, South Dakota 57101 800-557-4689 Manual No. 224252 04-23-2020/KAG...

  • Page 3: Table Of Contents

    Contents Safety ............. . . Fan Selection .

  • Page 4: Safety

    Safety Read and save these instructions General Safety Statements Thank you for choosing a Sioux Steel Company product. It is designed to perform and serve you for many years. It is the goal of Sioux Steel Company to improve our products whenever it is possible and practical to do so. Sioux Steel Company reserves the right to change, improve, and modify products at any time without obligation to make changes, improvements, and modifications on previously sold equipment.
  • Page 5 Safety Recognize the Safety Alert Symbol The above symbol means “Attention! Be Alert! Your Personal Safety Is Involved!” Note this symbol in instructions for important issues concerning your personal safety. Read each message carefully to avoid personal injury or death. Follow Machine Safety Signs &...
  • Page 6 Safety Warning: To reduce the risk of fire, electric shock, or injury to persons, observe the following: 1. Use this unit only in the manner intended by the manufacturer. If you have any questions, contact the manufacturer. 2. Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting means to prevent power from being switched on accidentally.
  • Page 7 Safety Danger: Never enter bin, unless all power is locked off and another person is present. Rotating augers can kill or dismember! Danger: Flowing grain may trap and suffocate. If you enter a bin of flowing grain you can be completely submerged in grain in seconds.
  • Page 8 Safety Safety Decal Locations Safety decals and shields are mounted whenever possible at factory. Please check that all decals are in place according to these drawings and in good legible condition. To order replacement decals or shields (NO CHARGE) contact your dealer or Sioux Steel Company, 196 ½ E. 6 St., Sioux Falls, SD 57101-1265.

  • Page 9: Fan Selection

    Fan Selection Determine the Right Size Fan for Your Bin Size First Warning! Determining the correct size fan for the size of the bin, type of grain and needs, is the key to successful drying. Responsibility for the Grain Condition is Yours! Warning! Incorrect fan size will cause your EQM Controls to not preform to your expectations.

  • Page 10: Installation

    Installation 1. Mount Control Box Mount (224319) to bottom of Control Box as shown below utilizing ¼”x 1/2” Hex Bolts (154002) and ¼” Lock Washers (154060). a. If mounting to a Centrifugal Fan, mount Cent Box Mounts (224414) as shown below utilizing ¼” x ¾” Hex Bolts (154003), ¼”...
  • Page 11 Installation ii. Position Control Box Assembly on top of fan as shown and mount to top of fan housing utilizing ¼” x 1.25” Drill Screws (157630). b. Triumph Fan Option i. Drill (4) 9/32” holes and 7/8” hole on top of fan where indicated by dimples.
  • Page 12 Installation 4. Seal Temperature and Relative Humidity Sensor holes with silicone caulk. 5. If the optional Headspace Temperature/Relative Humidity Sensor was provided, install at this time. a. Sensor will be mounted to the bin roof above where grain is present. To install, this requires drilling a 7/8”...

  • Page 13: Eqm Control Instructions

    EQM Control EQM Conditioning Principles 1. Shelf Life Conditioning starts with storage and the desire to keep grain as long as possible without spoilage. Shelf life is determined by grain moisture and storage temperature. This has been well documented by university research and verified by field results.
  • Page 14 EQM Control EQM Conditioning Principles These principles are important to understand because it affects how grain is dried, the Drying Front, and Equilibrium Moisture (EQM). When water is turned to vapor it takes energy away from the surface of what it is leaving. This is just like when people sweat.
  • Page 15 EQM Control EQM Conditioning Principles Relative humidity and temp create vapor pressure in the air Moisture content and temp create vapor pressure from the kernel The pressure difference drives moisture either into the air or into the kernel: • When the pressure in the air is greater, the grain gets wetter •...
  • Page 16 EQM Control EQM Conditioning Principles • The airflow (cfm) is simply how many pounds of air are available to remove water. More airflow means that more pounds of air can carry away more pounds of water per minute. 6. Typical EQM Since the EQM of the air is critical to whether we are removing or adding moisture of the grain, we need to know when the air is right to accomplish the desired Target EQM for the grain.
  • Page 17 EQM Control EQM Conditioning Principles 7. Adding heat Adding a small amount of heat has a dramatic effect on EQM. For example: a typical fall day with 45F temperature and 75% relative humidity produces an EQM of 17% for corn. Just a 3F temperature rise drops the relative humidity to 67% and the EQM to 15.3%.
  • Page 18 EQM Control EQM Conditioning Principles 9. Grain type variances Grain types absorb moisture differently. The same air that would produce 15% moisture for corn would produce 13% for wheat or soybeans. Also the amount of EQM air required to remove moisture in corn is much less than what is required to add the same amount of moisture.

  • Page 19: Components/Functions

    EQM Control Components/Functions 1. Power Supply / Breaker The Power Supply / Breaker is located on a din rail in the control box and is the source for 110VAC and 24VDC to the EQM Board. The 110VAC will not receive power if the High Limit Thermostat is tripped or if the fan is not running (Heater power must be interlocked fan control).

  • Page 20: Setup And Operation

    EQM Control Setup and Operation 1. Connecting to your mobile device a. EQM Board The EQM board is equipped with a WiFi dongle that provides access to the EQM computing and database with a mobile device or laptop computer. When power is present on the EQM board the WiFi boots up (up to 2 min) and is then accessible.
  • Page 21 EQM Control Setup and Operation c. Setup on the dashboard The setup is unique to each bin and location. To fill in or change these parameters select “edit”. This is for basic information such as the name of the farm, bin location, bin number, number of rings, grain type, and EQM Target. There is also a button to permit setting the time in the event that the battery has lost power and the unit was turned off.
  • Page 22 EQM Control Setup and Operation This is the “Operation Limits” section, which are items such as the minimum and maximum relative humidity and temperature. This is the “Select the Sensors” section, which is selecting the type of Temp/RH sensors being used and if a heater is being used.
  • Page 23 EQM Control Setup and Operation This is the “Select the VFD” section, which is selecting the brand of VFD being used. Currently there is only the Vacon X5 Series being offered. After this screen, the next button brings you back to the basic information dashboard where you are given the opportunity to save all your edits.
  • Page 24 EQM Control Setup and Operation If Gages is selected from the dashboard, the current readings on the gages will be displayed. The limits will be shown in red on the dials. The current EQM will also be calculated and if the heat would be on and the butterfly valve position in this set of conditions if it were in the run mode.
  • Page 25 EQM Control Setup and Operation 2. Operation a. Run mode The primary operational settings to get started are: • Target EQM and Grain type • Minimum and maximum EQM o the maximum EQM is primarily for wet weather if the heater is unable to drive the ambient air EQM down to reasonable levels o if using a vfd, the minimum is of little consequence •...
  • Page 26 EQM Control Setup and Operation c. Advanced settings Access to the advanced settings is provided by a checkbox on the edit screen under basic information. It allows access to additional Operation Limits such as Minimum and Maximum EQM and Minimum and Maximum Fan RPM.

  • Page 27: Troubleshooting

    EQM Control Troubleshooting EQM not working: • Check to make sure all EQM settings are set properly. • Check EQM if Red light is on. • Check EQM if Green light is flashing indicating a WIFI signal Caution: The procedures outlined below are for use only by qualified service personnel. Use caution when checking electrical components.

  • Page 28: Electrical Schematic

    EQM Control Electrical Schematic Note: 1) 120VAC Power Source supplied by end customer. 2) Heater must be interlocked through fan starter by connecting to EQM board as shown in schematic. It is the responsibility of the end customer to provide the interlocks. Failure to interlock heater through fan starter may lead to damage to heater in event of a fan shutdown and will void warranty.

  • Page 29: Electrical Layout/Components

    EQM Control Electrical Layout/Components Part Description Item Number Power Supply S224457 EQM Board S224345 Temp/RH Sensor S224225...

  • Page 30: Vfd (Vacon)

    Vacon VFD Connection to Heater Note: 1) 120VAC Power Source supplied by end customer. Separate Ground and Neutral will also need to be supplied. 2) Circuit Protection is provided by the VFD. The VFD is the control portion within and existing Branch Circuit 3) See Vacon VFD manual for proper instructions on connecting VFD.

  • Page 31: General Maintenance

    GENRAL MAINTENANCE KEEP ALL GUARDS AND SCREENS IN PLACE DISCONNECT ALL POWER SOURCES BEFORE DOING ANY REPAIR, MAINTENANCE OR INSPECTIONS! BEGINNING OF EACH DRYING SEASON: Remove inlet screen. With power off, check for foreign material on fan blade. Turn fan by hand to be sure it rotates freely.

  • Page 32: Warranty

    RODUCT ARRANTY LIMITED WARRANTY FOR NEW SIOUX STEEL COMPANY PRODUCTS A. GENERAL PROVISIONS. “Sioux Steel” means Sioux Steel Company, 196 1/2 East Sixth Street, Sioux Falls, South Dakota 57104. The warranties described below are provided by Sioux Steel to the original purchasers of new products purchased from Sioux Steel or from an authorized Sioux Steel Dealer (the “Products”).
  • Page 33 SIOUX STEEL COMPANY WARRANTY AND MANUAL ACKNOWLEDGEMENT If you prefer to fill out this information online, visit: www.siouxsteel.com/find-resources/warranties FAILURE TO RETURN THIS WARRANTY AND MANUAL ACKNOWLEDGEMENT MAY VOID THE PRODUCT “LIMITED WARRANTY” CONTAINED IN YOUR INSTALLATION AND/OR OPERATIONS MANUAL PROVIDED WITH THE PRODUCT. Please complete and return the Warranty and Manual Acknowledgement within ten *(10) days of receipt to: Sioux Steel Company, PO Box 1265, Sioux Falls, SD 57101-1265.
  • Page 34 WARRANTY REGISTRATION IS REQUIRED TO VALIDATE YOUR WARRANTY (Please Fold and Tape at the bottom for mailing.) Sioux Steel Company Warranty Department Po Box 1265 Sioux Falls, SD 57101-1265...
