- Page 1 NAVVY Metal and Water Finder USER MANUAL NAVVY’S User Manual, the latest device to WF 303 GH User manual, The newest device for detecting the locations of the different types of detect the whereabouts of various kinds of underground water .
-
Page 2: Table Of Contents
Index NAVVY Metal and Water Finder page 1 Index page 2 Important warnings page 3 Technical specifications page 5 Main Unit page 6 Device Parts page 7 Set up and work on the device page 11 Long range locator system... -
Page 3: Important Warnings
Important warnings It’s better to turn off mobile while The operating in high voltage areas using the device. would limit the results and performance Don't operate two devices with Don't store in high temperature or same method of search at the high humidity same place Disconnect the batteries before... -
Page 4: Technical Specifications
NAVVY Technical specifications Search for: Searching for underground water Long-range locator system to detect energy levels Search principle : about the location of water Operating processor : ARM & MICROCONTLLER PIC18 processing the energy levels formed around the area of water existence... - Page 5 NAVVY Technical specifications -15° to 40° Storage temperature: From Humidity: %90 It can be stored and work in the degree rate of air humidity of level Weight: 1.25Kg with the case Unite dimensions: 22x5x4.5cm 27x25x9cm Case dimensions: page...
-
Page 6: Main Unit
NAVVY The main unit Main unit Transceiver antenna Power button Grip Back button Move button Gharger socket Enter button Battery box display screen page... -
Page 7: Device Parts
NAVVY Device parts Main Unit It is the unit responsible for leading the search and controlling the attached units and processing the data extracted from the ground and displaying it on the screen using the most advanced interactive programs and systems... -
Page 8: Set Up And Work On The Device
Set up the device Set up and work on the main unit Turn the device on by pressing long press on the Power switch Boot interface will show and then the language selection interface for the first use of the device When you select the language by switching between them through the move button and select the desired language by pressing the confirmation button the device moves to the main interface... - Page 9 NAVVY Set up the device The main interface has two icons Search To select the search system and settings to adjust the settings of the device in addition to an indicator indicating the level of battery charge found in all interfaces, is switching between the icons...
- Page 10 NAVVY Set up the device Volume Adjustment: When selected on the volume icon, the volume is changed by pressing the Enter button to change the volume according to five volume levels in addition to silent mode and vibration mode you could turn off the vibration mode by select the volume icon and...
- Page 11 Set up the device NAVVY When the search icon is selected and the confirmation button is pressed, the search system interface appears, where the navigation is carried out to specify the search parameters using the navigation button,Initially, the target type to be searched is determined from among the available targets (all types - natural water - mineral water - saltwater) by pressing the Enter buttonIn the same way, both the distance and depth are determined.
-
Page 12: Long Range Locator System
NAVVY Installation Long Range Locator System Connect the signal booster antenna to the main unit Connect the telescopic antenna to the main unit Connect the grip to the main unit page... - Page 13 NAVVY The working principle of the system This system works on the technology of transmission and reception, it sends and receives waves at the same time, it searches for the target according to its types by sending a signal with a frequency corresponding to the self-absorption frequency, which differs according to the type of water.
- Page 14 NAVVY Set up the device to search How to work with the search system After preparing the main unit and installing the attachments, the main unit must be turned on, selecting the search icon, and pressing the Enter key for the search settings interface to appear...
- Page 15 NAVVY Set up the device to search After selecting the search settings are finished, we go to the Start Search icon by clicking on the Navigation button in the main unit it will create a frame around the Start Search icon...
- Page 16 NAVVY Set up the device to search Right track When the user drifts the device to the left, the correction of the search path towards the water is shown by taking corrective indicators either right or left You can pause and resume the search as well as modify the search settings in the attached...
- Page 17 NAVVY Set up the attached unit for search The user should carry the face through the handle in a horizontal with the ground and slightly tilted towards the soil as shown in the drawing Soil We then stimulate the waves and fields out of the device where we move the device by hand...
- Page 18 NAVVY Set up the device to search If the target is found, the device will receive a read and signal by automatically changing the device from the normal path to which the target was located. This direction is the direction of the target's location, and then the device is installed in the same direction.
- Page 19 NAVVY Set up the device to search How to locate water At first the user should point the antennas down towards the ground slightly After confirming more than one reading of the direction of the presence of water we press the move button to install the target path and we walk in the same direction and normal to carry the device.Note...
- Page 20 NAVVY Set up the device to search There is another way for us to more accurately determine where the target is located We are the process of squaring the target site by taking four readings of the target point from four angles ,...
-
Page 21: Charging
Charging NAVVY When the battery charge runs out, the battery screen appears as shown, where the battery image appears in red flashing and an audible alert is heard When you put the device on charging in the case of extinguish the charging screen is a... - Page 22 NAVVY Charging There are four cases for battery during the work that indicate how full the battery charge in different colors in order from empty to full (red - orange - yellow - green) as shown in the drawing Warnings...
-
Page 23: Nots
NAVVY Notes page... - Page 24 Metal and Water Finder Turkey - istanbul United States of America - illinois www.mwf-metaldetectors.com www.mwf-usa.com info@mwf-metaldetectors.com info@mwf-usa.com +90 ( 212 ) 222 0946 +1 ( 708 ) 364 9602 +90 ( 212 ) 222 0947...
