Summary of Contents for axiome eBARman

  • Page 2: Before Getting Started

    Before getting started Page 2 Document Version 1.1 Open the package and check every accessory: EBARman Stylus pen Power adaptor Battery CF open cover Hand strip holder (option) Ear/Microphone set Sync cable Turn on the Backup battery Replace the battery Turn on battery.
  • Page 3 Page 3 Document Version 1.1 front 1. Scanner Window 2. Scanner LED Indicator Green : Read Successful; : Read Error) 3. LCD Screen 4. Navigation Keys 5. Home Application button 6. USB Host 7. Sync Port 8. DC Power Jack 9.
  • Page 4 Page 4 Document Version 1.1 back 1. Compact Flash Type I/II Slot 2. Screw Hole 3. CF Type Slot Cover Lock Switch 4. IR Port 5. Hand Strap holder 6. Battery Pack Cover 7. Battery Pack Cover Lock Switch 8.

  • Page 5: Barcode Reading

    Barcode reading Page 5 Document Version 1.1 1. Execute barcode application 2. Aim the scan window at the barcode 3. Press “R” or “L” scan key 4. Aim the laser beam at the center of the barcode 5. Check the barcode reading result Device can read barcode from 40 to 300mm distance.

  • Page 6: Usb/Serial Connection

    Using peripherals Page 6 Document Version 1.1 CF Type Peheripherals USB/Serial Connection 1. Open CF slot cover Generally its used for 2. Insert correctly oriented a CF card synchronised data transmission 3. Close the CF slot cover with desktop. Connect the data sync cable. If you use data sync cable, you need to install Microsoft active sync 3.7 or above SD/MMC type card...

  • Page 7: Software Tips

    Software Tips Page 7 Document Version 1.1 battery To configure your eBARman use Control Panel Chose Power Properties and check battery status. Adjust Power Schemes for better power saving.
  • Page 8 Software Tips Page 8 Document Version 1.1 sync software To activate data synchronisation software: Start - Programs - Communication and run required application.
  • Page 9 Software Tips Page 9 Document Version 1.1 Use Date/Time Properties to adjust time and date settings. Point at icon in right bottom corner of screen to switch between applications. Use Input Panel to enter text with stylus pen. Run My Computer to access your data.

  • Page 10: Using Keypad

    Using Keypad Page 10 Document Version 1.1 Press [KBD] + [number] to get special symbols Press [KBD] + [TAB] to switch to alphabetic keyborad then press again [KBD] + [TAB] to switch to Uppercase letters and press [KBD] + [TAB] to return to numbers. See diagramm: [Keys] on screen = ‘1234’...
  • Page 11 Warning Page 11 Document Version 1.1 Never stare directly into the laser beam or shine the laser light into the eyes. Never apply strong pressure to the screen to avoid cracking the screen or LCD panel glass, which can cause the danger of personal injury. If the LCD panel glass breaks, never touch the liquid inside, which can cause skin inflammation.
