Cleanfix SW 50 Safety, Operations & Maint. Manual page 5

3.3 Preparation for usage with squeegee wand
- Connect vacuum hose (15/27) to vacuum hose
connector (9) on the tank (6).
- Assemble 2-piece (19) and attach to vacuum hose (18).
3.4 Preparation for usage with front-mount squeegee
- Place tank (6) with attached motor head (1) onto the
tipping dolley (13).
- Slide front-mount squeegee holder onto holder on the
dolley.
- Adjust with horizontal screw knob.
3.5 Transform into dry vacuum cleaner
- Detach motor head (1) from the tank (6).
- Remove float assy. (14) and replace with pan filter (26).
- For hygienic reasons it is recommended to also insert a
paper filter bag.
3.6 Operation
- Plug power cord into proper outlet.
3.7 Emptying the tank
- Turn of machine with on/off switch and unplug power
cord.
- After finishing the job move machine to a water disposal
area or restroom.
- Release latch (4) and remove motor head (1).
- Remove float assy. (14).
3.8 Emptying the tank with drain hose
- Turn of machine with on/off switch and unplug power
cord.
- After finishing the job move machine to a water disposal
area or restroom.
- Take drain hose (7) out of holder.
4. Maintenance
4.1. Safety instructions
When cleaning and servicing the machine or changing parts, always unplug the power cord.
The machine must not be cleaned with high pressure steam cleaners or powerful liquid jets.
For reparations use only original spare parts.
Important: Before commencing any maintenance work, switch of the machine and unplug power cord.
- Place motor head carefully and properly onto tank to
ensure tightness.
- On a regular basis check the gaskets for wear and
tear.
5. Corrective maintenance
We recommend that repairs and inspections are carried out
by an authorized service agent.
6. Storage
If the machine is not being used, it is to be cooled and stored
dry and under normal room conditions (not under 0°C).
7. Disposal
Disposal of packaging must take place according to national
regulations.
Safety, Operation and Maintenance Manual for SW 50; Version 1.0
- Connect squeegee tool (21) to wand (19) and then
machine is ready to use.
- Adjust the height of the squeegee blades with the
height-adjustment screw.
- Attach vacuum hose to the front-mount squeegee and
attach to connector on tank.
- Plug in power cord.
- Machine is ready to use.
- Never use as dry vacuum without the pan filter (26).
- Attach motor head (1) to tank and fasten latch (4).
- Attach suitable accessory to vacuum hose and wand.
- Turn machine on with on/off switch.
- Drain tank by tilting backwards and emptying waste
water into disposal.
- Re-attach vacuum hose (14/9) to connector (8), replace
float assy. (14) and motor head (1) and close latch (4).
Machine is now ready for use again.
- Unscrew cap.
- Drain into waste disposal/bucket/etc.
- Screw cap back onto drain hose. Make sure it's
screwed on airtight.
- Always clean machine, wheels, etc. after each use.
- Also clean inside the tank including float assy. after
each use.
- Dry (!) clean pan filter cloth on a regular basis.
5
