BASIC PURPOSE
The ShiftGuard PLC (Power Line Communication)
modules are communication components for
electric vehicle charging infrastructure. These PLC
modems can also be used for transmission of binary
signals in a wide range of applications. For example,
they are used instead of conventional power cables
to transmit information on the current tariffs of
electricity meters. When installed in the VoltDrive
charging infrastructure system, the ShiftGuard PLC
modems are used to transmit information from the
HomeGuard residual capacity meter of the electrical
connection to the electric vehicle charging station.
It enables the PortGuard charging control unit to
set the charging current exactly according to the
current available at the point of supply (at the
distribution meter). The communication between
the HomeGuard Residual Capacity Meter and the
PortGuard charging control unit can also be done
by means of RS485 twisted pair bus, however,
such a cable is usually not installed between the
input of the power supply point and the charging
station. In case the installation uses the ShiftGuard PLC modems, the charging station can be placed anywhere
after the distribution meter. When used in the tariff control system, a pair of the ShiftGuard PLC modems replaces
the communication cable carrying information on the current tariff. PLC communication enables the distribution of
information on the current tariff to any home appliance in a flat or a house.
MAIN FEATURES
¬
PLC modems for the VoltGuard system and the binary replicator
¬
Internal power supply of 230V AC, 50Hz
¬
PLC_IN – a pair of digital inputs 230V AC
¬
PLC_OUT – a pair of bistable relays 16A/230V AC
¬
Combined input and output installation
¬
Possibility of setting Master and Slave nodes
¬
RS485 communication line for setting and data input
¬
Variable system of node addressing
¬
Possibility of data transfer through 230V Ac power network within one distribution transformer
¬
Robust S-FSK modulation within the CENELEC D-band
¬
LED status indication
¬
Compact DIN rail box dimensions – 5 modules
VOLTDRIVE s.r.o.,
Háj 365 (MICOS TELCOM premises), 798 12 Kralice na Hané, Czech Republic
Tel.: +420 582 307 603, Fax: +420 582 307 688
e-mail: info@voltdrive.com, www.voltdrive.com
ShiftGuard
USER MANUAL
