HEMI GAS
USER MANUAL
G A S A N D D I E S E L T U N I N G S Y S T E M S

Advertisement

loading

Related Manuals for DiabloSport PREDATOR

Summary of Contents for DiabloSport PREDATOR

  • Page 1 HEMI GAS USER MANUAL G A S A N D D I E S E L T U N I N G S Y S T E M S...
  • Page 2 Products, with the sole exception Module (the “Module”) or the hand-held computer unit (the “Unit”), of DiabloSport Inc. ’ s liability for the refund of the purchase price of the and as the manufacturer of the Product. The Product and the Unit shall Product to Purchaser in the event that a court of competent jurisdiction be referred to collectively herein as the “Product.
  • Page 3 DiabloSport shall not credit or repair any units that are not properly returned clearly labeled on the box, or given to a DiabloSport RMA restored to the original backup upon time of return or may be VIN representative at the time the RMA is issued.
  • Page 4 30 days from date of purchase you are not satisfied with DIAMETER LOWER PULLEY APPLICATIONS the results the Predator generates in your vehicle, simply restore the factory tune to your vehicle and return the Predator to the AFTERMARKET PARTS selling dealer. Pending examination of the tool by DiabloSport, Use of the DiabloSport Predator with aftermarket products is you will receive a refund from your selling dealer.
  • Page 5 Preparing to install the Diablosport Performance Tune...
  • Page 6 Preparing to Predator Applications Install the Diablosport U7135-5.7L and 6.1 L Hemi V8 Engines Performance Tune 2006-2007 Jeep Grand Cherokee SRT-8 2005-2007 LX Magnum/Charger/300C 2005-2007 SRT-8 Magnum/Charger/300C...
  • Page 7 User must ensure that the original vehicle Factory Tune is in the vehicle’s ECU before installing DiabloSport tune. (original dealer reflashes are the same as Factory Tune). Serious engine damage can occur if the Predator tune is installed over a non-factory/ aftermarket performance tune.

  • Page 8: Display And Keypad Description

    Preparing to Display and Keypad Description Install the Diablosport Performance Tune Up arrow: Scroll up the menu ESC Key: Jump back to previous menu or jump to top of menu selection Left arrow: Set gauge value left Enter Key/Continue: Select the highlighted item...

  • Page 9: Very Important

    The vehicle is now in its original state. Predator is plugged into diagnostic port. Please attempt to locate the voltage draw before Predator is • Do not unplug the Predator while it is installing the DiabloS- used again. port Performance Tune or the Original Backup.
  • Page 11 Installing the Diablosport Performance Tune...
  • Page 12 To find out, which tune was last written to Original Backup: your vehicle, go to ‘Predator Options / Show Last Tune Written’ Stock tune, installing this will reset the Predator and allow it to be used in the Predator. on another vehicle.
  • Page 13 First Time Diablosport Performance The very first time the Predator is used on a vehicle it will auto- For more on modify tune please see the modify tune section in the Tune matically create a backup of the original factory tune.
  • Page 15 Modifing Parameters & Quick Adjust menu...
  • Page 16 • Rev limiter tor from the Diagnostic port. Cycle the key, and start the vehicle. You are now able to enjoy the force of the Predator! “Parameters/Features may not apply to all applications and may not be available upon release.
  • Page 17 Modifing Rev limiter in drive: Parameters This will allow user to adjust the rev limit in drive. Adjustable Parameter description: & Quick Adjust Rev limiter in park/neutral: Timing table 1000-3800rpm (+10/- 10deg) This will allow user to adjust the rev limit in park/neutral. This will allow user to adjust timing in the lower rpm ranges.
  • Page 18 Each Quick Adjust change will ask you to cycle the ignition key after changing them. Once ignition key is cycled the parameter Tire Size: has changed and you can unplug the Predator. This will allow user to adjust for aftermarket rims and tires. Transmission:...
  • Page 21 export/import custom tunes...
  • Page 22 This option should be handled by dealers only, as they must 1) On the Predator, go to “ Options ” then to “ Custom Tune transfer the original tune from Predator to PC and send it to “ Click “ Yes ” on the following screen, you want to overwrite Diablosport for modifications.
  • Page 23 Re installing the Original Backup...
  • Page 24 To restore Original Backup go to Performance Tune and then select Original Backup. When the Predator starts to write the Original Backup into your vehicle, a progress bar will indicate the status of writing. Follow all instructions on the Predator screen. The complete process will take about 1 minute.

  • Page 25: Vehicle Diagnostics

    Vehicle Diagnostics...
  • Page 26 Vehicle Select the “Diagnostics“ item from the main menu of the Preda- Diagnostics tor, then press the Enter key Allows user to view the vehicle trouble codes Diagnostics Show Trouble Codes Allows user to clear the trouble codes from the Clear Trouble Codes vehicle Real Time Data...

  • Page 27: Data Logging

    Vehicle Diagnostics Log Playback Diagnostics Show Trouble Codes = Display any stored trouble codes in To view the logged values, go back to main diagnostic menu memory. and select “Log Play Back”. Clear Trouble Codes = Delete any stored trouble codes in Top right hand corner will display the total time data logged.
  • Page 28 “DATALOG” yes or no, select “YES” and the data logging To obtain a copy of our data viewer, please visit our web site will start. www.Diablosport.com To stop data logging, press the “ESC” button. Log Playback To view the logged values, go back to main diagnostic menu and select “Log Play Back”.
  • Page 29 Vehicle Live Data Groups Diagnostics Gas Acceleration WOT = Contains parameters that are commonly viewed during dyno tuning and wide open throttle runs. Gas Drivability = Contains parameters that are commonly viewed during drivability testing and monitoring. Gas Fuel = Fuel related parameters Gas Ignition = Ignition related parameters Gas Speed Control = Vehicle speed related parameters Gas Trans = Transmission related parameters...
  • Page 31 Troubleshooting & Options...
  • Page 32 Vehicle? restore the stock tune to the PCM at any time. Q.Can I use the Predator to tune more than one car at a time? Depending on the year, Make, Model, and fuel type, the diablosport predator offers a mass of adjustable parameters.

  • Page 33: Options Menu

    Serial Baud = Set the serial baud rate of communications for tion. Predator. Live Table Reset = Reset this when Predator is used on a differ- ent vehicle. NOTE: When switching tool from one vehicle to another vehicle Verification = This is a troubleshooting feature and should only you must go into the options menu and press live table reset.
  • Page 34 Notes...
