Summary of Contents for Maxkin KP-A1
- Page 1 Wireless Keypad User Manual Printed in China 201 V 1.0...
-
Page 2: Table Of Contents
Table of Contents Get to Know Your Keypad Parts List Working Status of Keypad Installations Digital Keypad Operation Disarm by RFID Tag/Card Settings Enroll the Keypad to the Control Panel Connecting Electronic Door Lock Add/Delete RFID Tag/Card Restore System to Default Settings Specification Maintenance Frequently Asked Question... -
Page 3: Parts List
Get to Know Your System Working Status of Keypad The KP-AI wireless keypad works as arming/disarming devices, secured with admin and user password. It can be Green LED RFID Reader installed at entry /exit locations. Once there’s an Blue LED Red LED emergency situation, press the panic button. -
Page 4: Installations
Installation Positive and Negative Terminals for Battery 1. Open the keypad case, fix the rear cover at the suitable mounting location, please make sure the location level and Battery Slot fix the rear cover in position on the wall by screws. 2. -
Page 5: Digital Keypad Operation
Digital Keypad Operation In power saving mode, please press “ ” to activate keypad. Mute Mode Then please enter admin password # or user password # before operating the digital keypad. Press “ ” button, then press “ ” “ ”... -
Page 6: Settings
Settings Command Menu Setup Enter Setup State Factory Mark Function Press Button Default In power saving mode, press“ ”to activate keypad. Enter When quick arm function is enabled, users can press “ admin password#9 ”, blue LED light up to enter setup state. Quick Arm On + to arm the system Please enter the commands as below to setup. -
Page 7: Enroll The Keypad To The Control Panel
Enroll the keypad to the control panel Factory Press Button Mark Function Default If keypad is powered by the batteries, Press enroll button of control panel, the enroll LED light up, power saving mode press“ ”to activate keypad, and then press “ ”, the is recommended. -
Page 8: Add/Delete Rfid Tag/Card
Add/Delete RFID Tag/Card RFID Enrollment (Up to 50 pcs can be expanded) Clearing All RFID Tags Press“ ”to activate keypad, then enter “ admin password# 8 ”, Press“ ”to activate keypad, then enter “ admin password # 0 ” , green LED light up;... -
Page 9: Specification
Maintenance Specification Product Name: Keypad Keypad requires an adequate maintenance to make sure it works properly and prolong its usage life. Power Supply: 3pcs of 1.5V AAA / LR03 Battery Standby Current: ≤6μA Regular check & Forbiddance 1. Make sure the keypad is enrolled into control panel before use. Disarm by RFID Current: ... -
Page 10: Frequently Asked Question
Frequently Asked Questions 1.Why wireless keypad cannot work? A.Please check if the keypad is in low battery or the positive and negative terminals are revered. B.No programming within 30 seconds, the keypad will enter power saving mode, please press “*” to activate. 2.Why wireless keypad cannot connect to control panel? A.Make sure the alarm panel is powered on.
