Single monitor

Advertisement

Sit2Stand Single Monitor
Up
To raise the keyboard and monitor, pull the actuator handle (located under
the work surface) upwards to release the lock. If additional force is required,
apply a slight upward force to the opposite corner of the work surface or
keyboard tray.
To lower the keyboard and monitor, pull the actuator handle (located under
the work surface) upwards to release the lock. Provide the appropriate
downward force on the work surface using the palms of your hands.
additional downward force by gripping the actuator and apply additional
downward force to the horizontal portion behind the column.

Parts:

Work Surface
Base
Column
Keyboard Tray
Down
Keyboard Tray Spacer
Actuator Handle
Plastic Cap
Cable
Management Clip
x3
Screws:
M5x12mm x 2
M5x25mm x 4
VESA Mount
M5x38mm x 4

Monitor Mounting

Parts:
Screws:
M4x12mm x 4
M4x22mm x 4
Countersunk
Washer x 4
Spacer x 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ERGO Sit2Stand 500S2SNVS30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Richelieu ERGO Sit2Stand 500S2SNVS30

  • Page 1 Sit2Stand Single Monitor Down To raise the keyboard and monitor, pull the actuator handle (located under the work surface) upwards to release the lock. If additional force is required, apply a slight upward force to the opposite corner of the work surface or keyboard tray.
  • Page 2 Remove one track from the underside of the Insert the attached work surface track into work surface and set aside. the plastic guide on the column arm. Rest the unit upside down over the edge of a desktop or work surface on top of Insert the unattached work surface track cardboard divider (marked with “B”...
