- Page 1 VIP472 VIDEO LINE INSERTION PROCESSOR INSTRUCTION BOOK IB 6429-01...
- Page 2 VIP472 TABLE OF CONTENTS PAGE SHIPPING INSPECTION HOW AND WHERE TO MOUNT THE VIP472 MODUAL CARD INSTALLATION HOW TO CABLE THE VIP472 POWER SUPPLY INSTALLATION SET-UP OF THE VIP472 OPERATION FRONT PANEL CONTROLS AND INDICATORS BY-PASS MODES OF OPERATION CARE AND MAINTENANCE OF THE VIDEO MASTER...
- Page 3 SHIPPING INSPECTION Remove from shipping container and inspect for shipping damage. The VIP472 is a Slide in Card that fits into the RMS-400 Mainframe and Power Supply. The card is supplied with a retaining screw (attached to the PC Board), a Front Label Designator and this instruction book. If...
- Page 4 Therefore, if you must adjust a control, place a mark on it before moving it, so that it may be returned to its original setting with reasonable accuracy. HOW TO CABLE THE VIP472 Connect a BNC cable from your source video to the "PRIMARY VIDEO INPUT"...
- Page 5 See “Operation” in the next section. OPERATION The VIP472 is a line switcher that will insert any one video test signal line onto your NTSC video path so that you can monitor the transmission signal quality. This process allows the video test signal to pass through all digital compression systems to verify that your video is being delivered accurately without distortion.
- Page 6 “GND and INSERT”. BY-PASS MODES OF OPERATION The VIP472 has a power by-pass feature. If the power fails on the PC card the “PRIMARY VIDEO INPUT” will be connected directly to the “VIDEO OUTPUT” and the “SECONDARY VIDEO OUTPUT” will be shut off.
- Page 7 LINE SELECTOR TABLE LINE SWITCH # LINE SWITCH # LINE SWITCH # 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 X X - - - - - - - - X X X X - - X –...
- Page 8 X X – X X X X X - - X – X – X X - - X X X X X X X – X – X – X X X – X X X X X X VIP472.ISB PAGE 6 of 6...
