INSTRUCTION MANUAL
196CC Plate Compactor
Model # PS8810
Have product questions or need technical support? Please feel free to contact us!
Website:
www.Amerisuninc.com
Toll free: 1-800-791-9458 M-F 9-5 EST
Email: support@amerisuninc.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS8810 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Power smart PS8810

  • Page 1 INSTRUCTION MANUAL 196CC Plate Compactor Model # PS8810 Have product questions or need technical support? Please feel free to contact us! Website: www.Amerisuninc.com Toll free: 1-800-791-9458 M-F 9-5 EST Email: support@amerisuninc.com...
  • Page 3: Table Of Contents

    27.6x18.9x28.3 inches Weight: 243 lb. Thank you for purchasing Power Smart products. Please register online at www. Amerisuninc.com. The information will allow us to track your warranty and update on your unit. Important: Our company does not provide email or personal information to any third party for any reason. For any questions check our website or call customer service at (800)791 9458.
  • Page 4: General Safety Rules

    GENERAL SAFETY RULES Before operating this plate compactor read and observe all warnings, cautions, and instructions both on the labels • and in this owner’s manual. NOTE: The following safety information is not meant to cover all possible conditions and situations that may occur. •...
  • Page 5 SAFETY RULES Do not operate near open flame. • Do not smoke near the plate compactor. • Always turn the plate compactor off before refueling. Allow it to cool for at least 2 minutes before removing • fuel cap. Loosen cap slowly to relieve pressure in tank. •...
  • Page 6: Knowing Your 196Cc Plate Compactor

    Knowing your plate compactor 1. Throttle level 2. Handle 3. Frame 4. Belt cover 5. Engine supporter plate 6. Bottom plate . 7. Exciter 8. Engine...
  • Page 7: Assembly Instruction

    Assembly instruction WARNING: This plate compactor is heavy. Some procedures may require lifting equipment or two people. HANDLE ASSEMBLY: • The Plate Compactor is shipped with the lower handle already assembled and attached to the plate. • To complete the handle assembly, loosen the knobs in the middle of the handle and swing the upper handle into place.
  • Page 8: Operating Instruction

    has reached the second thread from the lip of the opening. Check for oil leaks. Reinstall oil filler cap before starting engine. WARNING: This plate compactor may emit highly flammable and explosive gasoline vapors, which can cause severe burns or even death if ignited. A nearby open flame can lead to explosion even if not directly in contact with gasoline.
  • Page 9 WARNING: The exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. STARTING THE PLATE COMPACTOR: 1. Check the oil and fuel levels. 2. Turn the fuel valve to the “ON” position. 3.
  • Page 10 control the forward motion. Steer the machine by moving the handle sideways to the right or left. • ALWAYS maintain good footing so that you do not slip and lose control when starting or operating • the machine. Prior to operation Make sure that all dirt, mud, etc.
  • Page 11: Maintenance

    Transportation Be sure to stop the engine while transporting. Close the fuel valve to avoid fuel leaking.In transportation by car, fix machine securely not to move nor to fall down.In case of driving for long distance or at off-road, drain the fuel out of fuel tank....
  • Page 12 AIR CLEANER MAINTENANCE: Routine maintenance of the air cleaner helps maintains proper air flow to the carburetor. Check that the air cleaner is free of excessive dirt. 1. Remove air cleaner cover (a). Remove both elements and inspect them for holes or tears.
  • Page 13 12. Store the emptied gasoline in a suitable place. CAUTION: Do not store fuel for more than 3 months. DRAINING THE FUEL TANK THROUGH THE CARBURETOR: 1. Turn fuel valve to “ON”. 2. Loosen drain screw from carburetor. Be sure to have a vessel prepared to catch the fuel that will flow out.
  • Page 14: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE SOLUTION Engine will not Engine switch is set to “OFF.” Set engine switch to “ON.” start. Fuel valve is turned to “OFF.” Turn the fuel valve to the “ON” position. Choke is open. Close the choke. Engine is out of fuel. Add gasoline.
  • Page 15: Plate Compactor Exploded View

    PLATE COMPACTOR EXPLODED VIEW 2....
  • Page 16: Plate Compactor Parts List

    PLATE COMPACTOR PARTS LIST Item Stock# Description Item Stock# Description PS8810-001 Engine PS8810-024 Spring Gasket PS8810-002 PS8810-025 Medium Flat Gasket PS8810-003 Clutch Assembly PS8810-026 Belt Cover PS8810-004 Conical Flat Gasket PS8810-027 Locked Nut PS8810-005 Spring Gasket PS8810-028 Shock Absorber PS8810-006...
  • Page 17 EXPLODED VIEW AND PARTS LIST (ENGINE)
  • Page 18: Exploded View And Parts List Engine)

    ENGINE PARTS LIST Item Stock# Description Item Stock# Description PS8810-E001 Bolt, M6×16 PS8810-E039 Gasket, Air Filter PS8810-E002 Clip PS8810-E040 Air Filter Lower Cover PS8810-E003 Valve Cover PS8810-E041 Air Filter Base Assembly PS8810-E004 Breather Hose PS8810-E042 Nut, M6 PS8810-E005 Gasket, Valve Cover...
  • Page 19 ENGINE PARTS LIST Item Stock# Description Item Stock# Description Governor Gear Bracket PS8810-E077 PS8810-E096 Clip Assembly PS8810-E078 Fuel Cap PS8810-E097 Crankcase PS8810-E079 Fuel Tank PS8810-E098 Oil Seal, 25×41.25×6 PS8810-E080 Nut, M6 PS8810-E099 Lower Shield PS8810-E081 Governor Spring PS8810-E100 Ignition Module...
  • Page 20: Warranty

    Power Smart (“Seller") warrants to the original purchaser only, that all Power Smart consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase. Ninety (90) days for all Power Smart Products, if the tool is used for professional or commercial use.
