OPERATORS MANUAL
T160 COMPACT HEDGE TRIMMER
Please read through manual thoroughly before operation
For any technical issues please call...
01228 712121
...or email info@mdlpowerup.com
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the T160 and is the answer not in the manual?

Questions and answers

Summary of Contents for MDL POWERUP T160

  • Page 1 Page 1 MDL POWERUP LIMITED Dalston – Carlisle - CA5 7NY OPERATORS MANUAL T160 COMPACT HEDGE TRIMMER Please read through manual thoroughly before operation For any technical issues please call… 01228 712121 …or email info@mdlpowerup.com...
  • Page 2 Page 2 ASSEMBLY INFORMATION Due to pallet size restrictions, there are some bolts that require locating and tightening upon arrival. Bolt (x1) marked with arrow requires positioning through the ram eyelet and securing. Bolts (x4) marked with BLUE arrows (trimmer bar bracket) require installing and securing.
  • Page 3: General Information

    Page 3 GENERAL INFORMATION Read this manual before fitting or operating the machine. Whenever any doubt exists contact your dealer or the MDL Service Department for assistance. NOISE The equivalent daily personal noise exposure from this machine, measured at the operators’...
  • Page 4 Page 4 SAFETY INSTRUCTIONS Before operating your machine, please read the following safety instructions. Failure to comply with these warnings may result in serious injury or death. Please review these safety instructions with all users annually. SIGNAL WORDS: The signal words DANGER, WARNING and CAUTION are used with the safety messages in this manual and with each safety sign.
  • Page 5: Safety Information

    Page 5 SAFETY INFORMATION This machine has the potential to be extremely dangerous, in the wrong hands it can kill or maim. It is therefore imperative that the owner, and the operator of this machine, read the following section to ensure that they are both fully aware of the dangers that do, or may exist, and their responsibilities surrounding its use.
  • Page 6 Page 6 ● Ensure the operator understands and follows the instructions in operator handbook. ● Ensure the tractor front, rear and side(s) are fitted with metal mesh or polycarbonate guards of suitable size and strength to protect the operator against thrown debris or parts. ●...
  • Page 7 Page 7 ● Always work at a safe speed taking account of the conditions i.e.: terrain, highway proximity and obstacles around and above the machine. ● Extra special attention should be applied to Overhead Power Lines. Some of our machines are capable of reach in excess of 8 metres (26 feet) this means they have the potential to well exceed, by possibly 3 metres (9’...
  • Page 8 Page 8 ● Never use a machine on which the hydraulic system shows signs of wear or damage. ● Never fit, or use, a machine on a tractor that does not meet the manufacturer’s minimum specification level. ● Never use the machine if the tractor cab guarding is damaged, deteriorating or badly fitted.
  • Page 9 Page 9 INITIAL ATTACHMENT TO TRACTOR The machine will be delivered in a partially dismantled condition, secured with transport strap and banding. • Choose a firm level site. • Remove any transport straps, banding straps and loose items • Raise the machine using overhead lifting equipment with a minimum capacity of 1500kg SWL.
  • Page 10: Tractor Attachment

    Page 10 TRACTOR ATTACHMENT Reverse tractor squarely into position adjacent to the machine and connect the linkages to the machine as shown: Correct linkage setup as shown above WARNING! The quadrant lever or machine controls must only be operated from the tractor seat.
  • Page 11 Page 11 NOTE: Be aware - as lift occurs, the machinery may tilt slightly. Measure PTO shaft and cut to dimension shown (distance ‘A’ minus 75mm) – see diagram opposite and refer to maintenance section for further details. NOTE: For subsequent use on a different tractor measure again - there must be a minimum of 6"...
  • Page 12 Page 12 Fit machine controls into the cab Request assistance. Operate 'Lift up' on machine controls only as much as sufficiently required to enable access to the stand legs to retract them. Raise the stand legs into the work position and secure with their pins - see diagram opposite.
  • Page 13: Hydraulic System

    Page 13 The machine can now be folded into the transport position ready to proceed to the work site - Refer to the section on Transport Position for details on this subject. REMOVAL FROM TRACTOR Select a firm safe site to remove the machine. Locate parking legs into their housings.
  • Page 14: Oil Supply

    Page 14 OIL SUPPLY Check the oil level in the reservoir daily. No fixed time period can be quoted for oil changes as operating conditions and maintenance standards vary so widely. Burnt and scorched oil odours and the oil darkening and thickening are all signs of oxidation and indicate the oil should be changed.
  • Page 15: Hose Replacement

    Page 15 braid from rusting. Hoses that have suffered damage to the metal braid should be changed at the earliest opportunity. HOSE REPLACEMENT • Replace one hose at a time to avoid the risk of wrong connections. • When the hose is screwed to an additional fitting or union, use a second spanner on the union to avoid breaking both seals.
  • Page 16 Page 16 TRACTOR ATTACHMENT – Linkage Mounted Machines...
  • Page 17 Page 17...
  • Page 18 Page 18...
  • Page 19 Page 19...
  • Page 20 Page 20...
  • Page 21 Page 21...
  • Page 22 Page 22...
  • Page 23 Page 23...
  • Page 24 Page 24...
  • Page 25 Page 25...
  • Page 26 Page 26...
  • Page 27 Page 27...
  • Page 28 Page 28...
  • Page 29 Page 29...
  • Page 30 Page 30...
  • Page 31 Page 31...
  • Page 32 Page 32 T160 Parts List...
  • Page 33 Page 33 Code Description Code GB1152-M6 oil cup 50901000 GB5783-M6X45 bolt 50101109 AMD58.01.148 pin shaft 71121005 AMD58.01.010 front arm 81121000 GB97.1-20 washer 50601006 GB6184-M20 50301031 AMD58.01.147 bolt 71121005 QHTTPG-320 clip 70466002 AM60.03.106 plate 70277007 GB6170-M8 50301004 AMD58.01.146 hood 71121005 GB27-M20X200 bolt 50101429 GB96.1-8...
  • Page 34 Page 34 GB97.1-14 washer 50601005 AM60.03.110 lock pin 70277007 AMD58.01.017 welding part 81121004 GB5782-M8X70 bolt 50101074 GB93-8 washer 50603003 GB27-M20X140 bolt 50101428 200.56.011 lock pin 70008001 GB27-M14X120 bolt 50101422 GB93-12 spring washer 50603003 GB97.1-12 plain washer 50601005 FM120.00.199D hood 70961022 GB27-M20X130 bolt 50101428...
  • Page 35 Page 35 EF100.00.111A D-pin 80092010 AMD58.01.014 brace 81121003 CBW-00.015 oil plug 80314018 AMD58.01.015 brace 81121004...
  • Page 36 Page 36 品号 Code Description 705640006 AMC130-0106 plate AMC130 (145 型)(L=1520)plate 705650001 AMC145-0106 (160 型)(L=1672) plate 708030001 AMC160-0106 (175 型)(L=1824) plate 708040001 AMC175-0106 (190 型)(L=1976) plate 708050001 AMC190-0106 705640001 AMC130-0101 blade protecting 9/10/11/12/13 AMC130-0011 blade AMC130 805640018 AMC145-0011 blade AMC145 805650002 AMC160-0011 blade AMC160...
  • Page 37 Page 37 GB5782- 501010755 bolt M12X45 705640013 AMC130-0113 506060306 GB894.1-20 circlip 705640005 AMC130-0105 plate 705640004 AMC130-0104 plate 705640003 AMC130-0103 plate 705640002 AMC130-0102 plate 705640016 AMC130-0117 plate 705640015 AMC130-0116 plate GB5783- 501011115 bolt M10X40 GB12- 501040503 bolt M12X40...
  • Page 38 Page 38 品号 Code Description 705640023 plate AMC130-1201 505011736 bolt GB70.3-M10X30 511021626 -2Z bearing GB276-6004-2Z 705640024 AMC130-1202 506030035 spring washer GB93-8 501011100 bolt GB5783-M8X25 503010046 GB6170-M10 506030036 spring washer GB93-10 503010045 GB6170-M8 705640028 plate AMC130-1206 501011101 bolt GB5783-M8X30 503010102 GB6172.1-M16 503010049 GB6170-M16 705640027...
  • Page 39 Page 39 品号 Code Description BH-6.07.091 hand shank 702830121 MBH-6.08.108 joystick 702910335 GB6172.1-M10 thin nut 503010099 AM60.01.120 shifting block 702770020 AM60.01.119 protecting bush 702770019 GB70.1-M5X40 hexagon socket cap screw 505011396 GB119.1-B-6X26 round pin 508010099 AM60.01.114 upper cover 702770015 AM60.01.109 flange sleeve 702770010 AM60.01.118A pull rod 2...
  • Page 40 Page 40 AM60.04.092 hand shank 702770171 AM60.01.107 joystick 702770008 GB78-M5X8 screw 505020541 GB97.1-6 plain washer 506010054 DIN985-M6 hexagon lock thin nut 503010759 AM60.01.105 fixed seat 2 702770006 AM60.01.104 sleeve 702770005 GB3452.1-G-16X2.65 O sealing ring 510013130 AM60.01.106 lock shaft 702770007 AM60.01.103 locating bush 702770004 AM60.01.102...
  • Page 41 Page 41...
  • Page 42 Page 42 Code Description Article No. AMS60.02.010 oil hose 807890027 GB3452.1-G-18X2.65 O seal ring 510013132 AMS60.02.013 oil hose 807890030 AMD58.02.010 oil hose 811210059 AMD58.02.011 oil hose 811210060 AM60.04.090 filter 702770174 GB3541-M14X1.5 bolt 501014707 14.7X22X1.5 washer 510015239 JB982-14(进) AMD58.02.012 oil hose 811210061 AM60.04.016-1 cylinder...
  • Page 43 Page 43 Warranty MDL warrants to the original purchaser that this product will be free from defects in material and workmanship beginning on the date of purchase by the end user according to the following schedule when used as intended and under normal service and conditions for personal use.
