Rezontech RFD-2000X User Manual

Flame detector. uv/ir type
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Flame detector ( UV/IR Type )
RFD-2000X User's Manual
Rezontech Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RFD-2000X and is the answer not in the manual?

Questions and answers

Related Manuals for Rezontech RFD-2000X

Summary of Contents for Rezontech RFD-2000X

  • Page 1 Flame detector ( UV/IR Type ) RFD-2000X User’s Manual Rezontech Co., Ltd...

  • Page 2: Table Of Contents

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X TABLE OF CONTENTS 1 Product Overview 1.1 Product Introduction 1.2 Contents of User Manual 1.3 Revision of User Manual 1.4 Warranty 2 Technical Specifications 2.1 Electrical Specifications 2.2 Mechanical Specifications 2.3 Environmental Specifications 3 Installation 3.1 Unpacking &...
  • Page 3 Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 4 Operation 4.1 Product checklist 4.2 Initial Operation of Product 4.3 Safety Handling 4.4 Product Testing 5 Maintenance & Troubleshooting Instructions 5.1 Tools of Maintenance and Products Training 5.2 Maintenance Procedures 5.3 Troubleshooting 5.3.1 No LED responds after the power connection.

  • Page 4: Product Overview

    1. Product Overview 1.1 Product Introduction Model RFD-2000X from Rezontech Co., Ltd. is UV/IR type flame detector. It activates alarm signal or fire extinguishing system via fire or flame detection. This function can be used directly with output terminal and through connected control circuits are also available.

  • Page 5: Revision Of User Manual

    [Table 2] Revision of User Manual 1.4 Warranty Rezontech warrants the Models RFD-2000X to be free from defects in workmanship or material under normal use and service within two years from the date of shipment. Rezontech will repair or replace without charge any such equipment found to be defective during the warranty period.

  • Page 6: Technical Specifications

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 2. Technical Specifications 2.1 Electrical Specifications [Figure 1] TB1 Terminal address at product cover 2.1.1 Electrical ㆍ Recommended Operating Voltage : 24VDC ㆍ Rating Voltage : 17VDC ~ 32VDC ㆍ Max Input Voltage : 36VDC ㆍ...
  • Page 7 Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 2.1.4 RS485 Communication ㆍ Non-isolation output (2 wiring) ㆍ Communication Speed : 9600bps 2.1.5 LED Indicator ㆍ Two LED's(Yellow, Red) indicator - Yellow LED : Provides indication of Normal or Fault state - Red LED : Provides indication of Warning or Alarm state ㆍ...

  • Page 8: Mechanical Specifications

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 2.2 Mechanical Specifications [Figure 3] Front, inch[mm] [Figure 4] Side, inch[mm] [Figure 5] Combination of Detector and Bracket, inch[mm] ㆍ Enclosure (Material) : 316 Stainless Steel ㆍ Weight : Body - approximate 2.4㎏, Overall - approximate 3.4㎏...

  • Page 9: Environmental Specifications

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X ㆍ Explosion proof : ATEX Ex db IIB+H2 T6 (75℃) ㆍ Water and Dust Tight : IP67, NEMA Type 4X 2.3 Environmental Specifications ㆍ Operating Temperature : -40℃ ~ +75℃ ㆍ Storage Temperature : -50℃ ~ +80℃...

  • Page 10: Installation

    A/S center with fee applied. 3.1.1 Product Compositions ㆍ RFD-2000X 1EA ㆍ BK-2(Bracket) 1EA ㆍ Spare Bolt 1set 3.1.2 Components...

  • Page 11: Selection Of Installation Location

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 3.2 Selection of Installation Location Minimum information will be provided below for the location selection of installation. Please refer the information according to the purpose of your use. 3.2.1 Cone of Vision 3.2.1.1 Fuel ㆍ...

  • Page 12: Environment Points To Be Considered When Use

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 3.2.2.2 Detection Range of False Alarm The detector is immune to a variety of false alarm sources. Representative samples of detector's response from false alarm sources are listed below. Radiation Source Immunity Distance ft(m)

  • Page 13: Installation And Electrical Wiring

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 3.3 Installation and Electrical Wiring 3.3.1 Wiring the Detector 3.3.1.1 Conduit installation ㆍ Use 1/2 inch NPT-14 or M20X1.5 conduit connection or suitable explosion-proof gland to assemble the cable and conduit to the detector.

  • Page 14: Bracket Specification

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 3.3.2.1 Bracket Specification ㆍ Angle adjustment : Horizontal 180° , Vertical 180°, scale indications 15° each When you arrange the angle, M4 Set Screw and M10-25 Hexagon Wrench Bolt has to be released first and tighten again with 24 (N･m) Torgue for Hexagon Wrench Bolt and 1.5 (N･m) Ttorgue for Set Screw.
  • Page 15 Co.,Ltd. UV/IR Type Flame Detector RFD-2000X ㆍ Mount the bracket with M5-30 × 4pcs bolts. Refer to Figure 8 ㆍ Detector can be installed on the wall or the ceiling with bracket. Refer to Figure 9, 10 [Figure 8] 4 Holes on bracket...

  • Page 16: Terminal Wiring

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 3.3.3 Terminal Wiring This is the reference for the user on how all the connection of the electrical wiring are connected to each system or product as per stated below. 3.3.3.1 Relay Signal - Fire Relay The following signal occurs when fire is detected ㆍ...
  • Page 17 Co.,Ltd. UV/IR Type Flame Detector RFD-2000X - Fault Relay This signal shows up when product is not working properly or the fire signal is not functional. ※ Before power supply is on, FLT_N.O is connected because Fault Relay is not in error status.
  • Page 18 Co.,Ltd. UV/IR Type Flame Detector RFD-2000X ㆍ Power supply Fire, Relay and Fault Relay wires interlink (indication of Jumper setting location) [Figure 12] Terminal wiring diagram schematic at fault relay (Internal) [Figure 13] Terminal wiring diagram schematic at fault relay (External) Document No.
  • Page 19 Co.,Ltd. UV/IR Type Flame Detector RFD-2000X ㆍ Loop connection with several detectors This is Loop type connection method which can generate alarm and fault signal. But with this connection, detection performance is blocked when one flame detector is in fault condition.
  • Page 20 Co.,Ltd. UV/IR Type Flame Detector RFD-2000X - Warning Relay This signal shows when fire is detected at primary stage before the real fire is confirmed. This signal only occurs within delay time. ㆍ Warning Relay operated according to detector's condition...
  • Page 21 Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 3.3.3.2 4~20mA (Current Source) This signal shows when various recorded information of current output is transmitted through electrical wiring. It is varied according to the product status. ㆍ Non-isolation output, Common 24V-_IN (-Power) ㆍ Max. Terminating Resistance : 500Ω...

  • Page 22: Rs485

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 3.3.3.3 RS485 This signal (RS485) does not inform product status only but also supports changing and controlling in variable setting value. And this function can be used in synch with interlinking remote control or other systems.
  • Page 23 Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 3.3.3.4 External Recovery Signal It is used when the detector needs to recover from its default status after any fire detection, etc. Hence, it is similar to reset product via power on/off. Signal terminal number (TB1)
  • Page 24 Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 3.3.3.5 External Self-Diagnosis Test Within the various parts of fire detector, sensor is the most basic receiving part nearliest from 'fire signal' with transmission function. This function is enable to inspect from the receiving part to fire recognition circuit.

  • Page 25: Sensitivity Setting

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 3.3.4 Setting of Product 3.3.4.1 Sensitivity setting Sensitivity setting can be adjusted by user according to the various environmental conditions. Due to the difference in law or regulation from various countries, this function may not be applicable to all. So we have no responsibility for the troubles related with sensitivity setting over the approved range.

  • Page 26: Setting Of Others Function

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X Switch setting Delay time No.4 No.5 No.6 [Table 18] Switch setting for delay time ※ When setting of delay time to 5, an average response time is about 12 second for 1X1 feet heptane pan flame at 99 feet (30 m) from FM approval results.

  • Page 27: Ground Connection

    [Table 20] Switch setting for self-diagnosis test 3.3.5 Ground Connection For proper operation of the detector, the RFD-2000X must be grounded through a wire to the chassis. Failure to establish a ground connection can lead to greater susceptibility of the detector to electric surges, electromagnetic interference, and ultimately, damage to the instrument.

  • Page 28: Operation

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 4. Operation The contents of this page are about "Operation". As much as ‘product selection’ or ‘Installation’, the operation is also very important. Though another parts of operation "Maintenance and Troubleshooting" will be discussed separately in another chapter.

  • Page 29: Safety Handling

    4.4 Product Testing 4.4.1 Product Testing by using : TL205 TL 205 generates specific UV/IR radiations which can be detected by Rezontech Flame detector series as fire. It has an individual built in internal power supply hence, it can be moved and used easily.
  • Page 30 Co.,Ltd. UV/IR Type Flame Detector RFD-2000X [Figure 20] TL205 TEST LAMP ㆍ Testing Sequences with TL205 1. Please wait for 10seconds after the power is supplied. Check, Yellow LED blinking. 2. Face and 'Turn On' the TL 205 in front of the flame detector.

  • Page 31: Tools Of Maintenance And Products Training

    Ignoring these instructions may cause problems with the detector and may invalidate the warranty. Whenever a unit requires service, please contact rezontech or its authorized distributor for assistance. 5.1 Tools of Maintenance and Products Training Basic tools are necessary and the person in-charge shall received products training in order to maintain the detector.

  • Page 32: Troubleshooting

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 5.3 Troubleshooting If there is any error, kindly refer to the solutions as stated below. And please contact the manufacturer or authorized A/S center if the problem proceed. 5.3.1 The LED is not responding after the power supply is connected.

  • Page 33: Customer Support

    6.1 Contacts Information Rezontech Office Address Phone, Fax, E-Mail South Korea TEL : +82-31-420-0808 805, Megavally, Gwanyang-dong, FAX : +82-31-420-0800 Dongan-gu, Anyang-si, Gyeonggi-do, Homepage Site : http://www.rezontech.com Korea [Table 24] Information of Contact Document No. Manual-2000X Rev.3 March 2013 - 32 -...

  • Page 34: Appendix

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 7. Appendix 7.1 Abbreviation Abbreviation Description ATEX Atmosphere Explosives American Wire Gauge End Of Line Field Of View IECEx International Electrotechnical Commission Explosion Infrared Ultraviolet Refers to relays remaining in the ON state even after the ON condition...

  • Page 35: Things To Be Consider When Choosing Electrical Wiring For Power Supply

    Co.,Ltd. UV/IR Type Flame Detector RFD-2000X 7.2.2 Things to be consider when choosing electrical wiring for power supply:~ ㆍ The number of product to connect to one circuit ㆍ Wiring length for installation (overall space or partly space) ㆍ The necessary voltage range for product ㆍ...
