CIRRUS DESIGN CAPS Component Manual

Airframe parachute system
Hide thumbs
Table of Contents

Advertisement

Quick Links

CIRRUS AIRFRAME PARACHUTE SYSTEM
MAINTENANCE MANUAL with ILLUSTRATED PARTS LIST
FAA APPROVAL HAS BEEN OBTAINED ON THE TECHNICAL DATA IN THIS PUBLICATION THAT AFFECTS AIRPLANE TYPE DESIGN.
Procedures and parts listed in this manual are reflective of Cirrus Design SR20 airplanes serial numbers 1195 and subsequent, SR22 airplanes serial numbers 0210 and
subsequent, and all prior airplanes incorporating Service Bulletin SB 20-95-05 or SB 22-95-05 respectively.
For the
CIRRUS DESIGN SR Series Airplane
CIRRUS DESIGN INCORPORATED
4515 Taylor Circle
Duluth, MN 55811
COPYRIGHT 2002 CIRRUS DESIGN CORPORATION DULUTH, MINNESOTA, USA
P/N 12128-001
ISSUED SEPT, 2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAPS and is the answer not in the manual?

Questions and answers

Related Manuals for CIRRUS DESIGN CAPS

Summary of Contents for CIRRUS DESIGN CAPS

  • Page 1 ISSUED SEPT, 2002 Procedures and parts listed in this manual are reflective of Cirrus Design SR20 airplanes serial numbers 1195 and subsequent, SR22 airplanes serial numbers 0210 and subsequent, and all prior airplanes incorporating Service Bulletin SB 20-95-05 or SB 22-95-05 respectively.
  • Page 3 Log of Revisions Revision Issue Date Inserted Revision Issue Date Inserted Number Date Inserted Number Date Inserted 95-RevLog 12128-001 15 Sept 2002 Page 1...
  • Page 5 CHAPTER 95 - CIRRUS AIRFRAME PARACHUTE SYSTEM LIST OF EFFECTIVE PAGES Chapter/Section Page Date 95-REVLOG 15 SEPT 2002 95-LOEP 15 SEPT 2002 95-LOEP 15 SEPT 2002 95-TOC 15 SEPT 2002 95-TOC 15 SEPT 2002 95-01 15 SEPT 2002 95-01 15 SEPT 2002 95-01 15 SEPT 2002 95-01...
  • Page 6 CHAPTER 95 - CIRRUS AIRFRAME PARACHUTE SYSTEM LIST OF EFFECTIVE PAGES Chapter/Section Page Date 95-01 15 SEPT 2002 95-01 15 SEPT 2002 95-01 15 SEPT 2002 95-01 15 SEPT 2002 95-01 15 SEPT 2002 95-LOEP 12128-001 Page 2 15 Sept 2002...

  • Page 7: Table Of Contents

    Installation - Caps Parachute Assembly Caps Activation Handle and Cable Assembly Removal - Caps Activation Handle and Cable Assembly Installation - Caps Activation Handle and Cable Assembly Operational Check - Caps Activation Handle and Cable Assembly 95-TOC 12128-001 15 Sept 2002...
  • Page 8 CHAPTER 95 - CIRRUS AIRFRAME PARACHUTE SYSTEM TABLE OF CONTENTS Subject Chapter/Section Page ILLUSTRATED PARTS LIST 95-01 General SR2X CAPS Installation (Sheet 1 of 3) SR2X CAPS Installation (Sheet 2 of 3) SR2X CAPS Installation (Sheet 3 of 3) 95-TOC 12128-001 Page 2 15 Sept 2002...

  • Page 9: Introduction

    The purpose of the Cirrus Design CAPS Maintenance Guide with Illustrated Parts List (CAPS Component Manual) is to provide shop verified procedures that will enable an authorized CAPS technician to restore the system to a functional condition. Procedures and parts listed in this manual are reflective of Cirrus...

  • Page 10: General

    3. GENERAL The airplane is equipped with a Cirrus Airplane Parachute System (CAPS) designed to bring the aircraft and its occupants to the ground in the event of a life-threatening emergency. CAPS consists of a parachute, a solid-propellant rocket to deploy the parachute, a rocket activation sys- tem, and a harness imbedded within the fuselage structure.
  • Page 11 Figure 95-011 CAPS System and Deployment 95-01 12128-001 15 Sept 2002 Page 3...

  • Page 12: Activation System

    Rocket Motor The CAPS rocket motor uses stored chemical energy in the form of a solid propellant to provide the thrust forces necessary to rapidly remove the enclosure cover and extract the parachute from its enclosure.
  • Page 13 Figure 95-012 CAPS Handle and Ignition System 95-01 12128-001 15 Sept 2002 Page 5...

  • Page 14: Incremental Bridle And Deployment Bag

    The CAPS parachute is fabricated from woven textiles in the form of fabrics, tapes, webbing, and thread. All of the textile components in CAPS are fabricated from either Kevlar or Nylon and are woven to military specifications that define specific parameters such as yarn count, yarn twist, weave type, and finish.
  • Page 15 Figure 95-013 Incremental Bridle and Deployment Bag 95-01 12128-001 15 Sept 2002 Page 7...

  • Page 16: Slider

    On the CAPS system the last link is held in place by a short length of nylon cord which is severed by the pyrotechnic reefing line cutters.
  • Page 17 Figure 95-014 Parachute Assembly and Line Cutters 95-01 12128-001 15 Sept 2002 Page 9...
  • Page 18 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 19: Maintenance Guide

    MAINTENANCE GUIDE 1. GENERAL Procedures and parts listed in this manual are reflective of Cirrus Design SR20 airplanes serial numbers 1195 and subsequent, SR22 airplanes serial numbers 0210 and subsequent, and all prior airplanes incor- porating Service Bulletin SB 20-95-05 or SB 22-95-05 respectively.

  • Page 20: Installation - Pyrotechnic Line Cutters Replacement

    Cinch nylon cord tight. Tie standard Square Knot and cinch tight. Sew nylon cord ends together just below CAPS knot, tie off with CAPS knot. CAUTION: Ensure trimmed ends of nylon cord do not interfere with line cutter’s ignition loops.
  • Page 21 Figure 95-015 Pyrotechnic Line Cutters Replacement (Sheet 1 of 2) 95-01 12128-001 15 Sept 2002 Page 13...
  • Page 22 Figure 95-015 Pyrotechnic Line Cutters Replacement (Sheet 2 of 2) 95-01 12128-001 Page 14 15 Sept 2002...

  • Page 23: Caps Cover

    Exercise caution when sanding composite surface to prevent sanding into laminate. Control dust migration. Using die grinder and disc, at CAPS cover edge-seam reference mark, sand in a 0.5 inch (1.3 cm) area, and locate CAPS cover seam line. Sand around cover circumference follow- ing seam line to reveal entire perimeter of cover.
  • Page 24 Using die grinder and sanding disc, remove all remnant adhesive from fuselage flange, burnish lightening protection mesh, and abrade flange surface for adhesive application. Draw an offset line 0.25 inch (0.64 cm) from scribeline on new CAPS cover, and trim to off- set line to facilitate trimming and fitting.
  • Page 25 Note: To prevent cover deformation and generation of air pockets in adhesive, tape CAPS cover to fuselage with two people working on either side of air- plane. For RH and LH sides, cut 10, two-foot strips of filament tape and make ready for quick-use by lightly hanging each piece to the leading edge of horizontal stabilizer.
  • Page 26 Utilizing Heated Air Cure methods, fully cure adhesive for 1 hour at 140° F (60° C). (Refer to AMM 51-20) Fill, seal, and paint CAPS cover enclosure. (Refer to AMM 53-30) Install CAPS cover placard. (Refer to AMM 11-20) 95-01...
  • Page 27 Figure 95-016 CAPS Cover Installation 95-01 12128-001 15 Sept 2002 Page 19...

  • Page 28: Caps Rocket Assembly

    Any Source Facilitate Rocket Removal Remove CAPS handle access cover and install CAPS handle safety pin Remove bulkhead 222 (BH 222) trim panel and carpet. Remove access panel CB7 from BH 222. To prevent debris and components from falling into bottom of empennage, place catch cloth below rocket and parachute assembly.

  • Page 29: Installation - Caps Rocket Assembly

    12” x 12” Any Source Facilitate Rocket Removal Ensure CAPS handle safety pin is installed. Record rocket serial number in airplane log book. Note: To prevent rocket assembly from snagging on parachute, place cardboard between rocket assembly and parachute during installation.
  • Page 30 Figure 95-017 CAPS Rocket Assembly (Sheet 1 of 2) 95-01 12128-001 Page 22 15 Sept 2002...
  • Page 31 Figure 95-017 CAPS Rocket Assembly (Sheet 2 of 2) 95-01 12128-001 15 Sept 2002 Page 23...

  • Page 32: Caps Parachute Assembly

    For lifting, use 1-inch-wide retaining strap handles sewn to top of parachute assembly. Lift parachute assembly from CAPS enclosure and place on saddle, laying assembly with three point shackles facing up, and top of pack facing aft. Remove spacers, bolts, washers, and nuts securing forward harness straps to parachute assembly three-point shackles.

  • Page 33: Caps Activation Handle And Cable Assembly

    Install nuts on inboard side of shackles. Torque nuts to 95- 105 in-lbs (10.5 - 11.5 Nm). Lower parachute assembly into CAPS enclosure. Route parachute assembly retaining straps into upper slots of CAPS enclosure to facilitate installation. CAUTION: Ensure retaining straps are not twisted during installation.

  • Page 34: Installation - Caps Activation Handle And Cable Assembly

    If applicable, slit tape securing LH headliner to door frame. Remove LH B-pillar trim. (Refer to AMM 25-10) Gently pull LH portion of cabin headliner down from ceiling to gain access to CAPS activa- tion cable. Remove CAPS Rocket Assembly. (Refer to 95-01) Remove grommet securing activation cable to cable pass-through hole in CAPS bucket.

  • Page 35: Operational Check - Caps Activation Handle And Cable Assembly

    Install spiral wrap to aft portion of activation cable behind BH 222 so that cable will not chafe on static lines or BH 222 cable pass-through hole. Perform Operational Check - Caps Activation Handle & Cable Assembly. (Refer to 95-01) Install CAPS Rocket Assembly. (Refer to 95-01) Position cabin headliner to ceiling and install CAPS handle recess trim.
  • Page 36 If power unit reads red, verify activation cable is properly connect to test fixture and routing is correct and clear of other components. Re-check CAPS Activation Cable. If power unit reads red a second time, contact Cirrus Design for disposition. Otherwise, remove test fixture from airplane. Install CAPS handle safety pin.
  • Page 37 Figure 95-018 CAPS Activation System 95-01 12128-001 15 Sept 2002 Page 29...
  • Page 38 Figure 95-019 (Sheet 1 of 2) CAPS Test Fixture 95-01 12128-001 Page 30 15 Sept 2002...
  • Page 39 Figure 95-019 (Sheet 2 of 2) CAPS Test Fixture 95-01 12128-001 15 Sept 2002 Page 31...
  • Page 40 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 41: Illustrated Parts List

    ILLUSTRATED PARTS LIST 1. GENERAL Procedures and parts listed in this manual are reflective of Cirrus Design SR20 airplanes serial numbers 1195 and subsequent, SR22 airplanes serial numbers 0210 and subsequent, and all prior airplanes incor- porating Service Bulletin SB 20-95-05 or SB 22-95-05 respectively.

  • Page 42: Sr2X Caps Installation (Sheet 1 Of 3)

    Figure 01 SR2X CAPS Installation (Sheet 1 of 3) 95-01 12128-001 Page 34 15 Sept 2002...

  • Page 43: Sr2X Caps Installation (Sheet 2 Of 3)

    Figure 01 SR2X CAPS Installation (Sheet 2 of 3) 95-01 12128-001 15 Sept 2002 Page 35...

  • Page 44: Sr2X Caps Installation (Sheet 3 Of 3)

    Figure 01 SR2X CAPS Installation (Sheet 3 of 3) 95-01 12128-001 Page 36 15 Sept 2002...
  • Page 45 1005 PRT OF ITEM 6 ••LINE CUTTERS 1005 PRT OF ITEM 6 A ••NYLON STRING 1005 12600-003 •CAPS HANDLE COVER ASSEMBLY 1196 69 SJ3571 A •LOOP TAPE V1LF36 1005 ORDER CIRRUS P/N 50457-001 69 SJ3572 A •HOOK TAPE V1LF36 1005...
  • Page 46 22AF1250 ••ADJUSTABLE BUSHING, V13764 1196 ORDER CIRRUS P/N 51192-125 91F7326 ••GROMMET, FLEXIBLE V02927 1005 ORDER CIRRUS P/N 50892-001 15045-001 •PLACARD, CAPS ROUTING 1196 LLP-250-100 •LOOM V58961 1196 ORDER CIRRUS P/N 50943-025 MS3367-1-9 A ••STRAP EFFECTIVITY: SR20 SERIALS 1195 AND SUBSEQUENT...
  • Page 47 0002 PRT OF ITEM 6 ••LINE CUTTERS 0002 PRT OF ITEM 6 A ••NYLON STRING 0002 14264-002 •CAPS HANDLE COVER ASSEMBLY 0210 69 SJ3571 A •LOOP TAPE V1LF36 0002 ORDER CIRRUS P/N 50457-001 69 SJ3572 A •HOOK TAPE V1LF36 0002...
  • Page 48 22AF1250 ••ADJUSTABLE BUSHING, V13764 0210 ORDER CIRRUS P/N 51192-125 91F7326 ••GROMMET, FLEXIBLE V02927 0002 ORDER CIRRUS P/N 50892-001 15045-001 •PLACARD, CAPS ROUTING 0219 LLP-250-100 •LOOM V58961 0169 ORDER CIRRUS P/N 50943-025 MS3367-1-9 A ••STRAP EFFECTIVITY: SR22 SERIALS 0210 AND SUBSEQUENT...
