PILOT4 Owner's Manual
Owner's Manual
PILOT4
This manual has been compiled to help you to operate your craft with safety and
pleasure. It contains details of the craft, the equipment supplied or fitted, its systems,
and information on its operation and maintenance. Please read it carefully and
familiarise yourself with the craft before using it.
If this is your first craft, or you are changing to a type of craft you are not familiar with, for
your own comfort and safety, please ensure that you obtain handling and operating
experience before assuming command of the craft. Your dealer or national boating
association will be pleased to advise you of local sea schools or competent instructors.
PLEASE KEEP THIS MANUAL IN A SECURE PLACE AND HAND IT OVER TO THE
NEW OWNER WHEN YOU SELL YOUR CRAFT.
Westport Marine, Unit2 Connaught Lane, Plymouth, Devon, UK, PL4 7BZ
T: 07944 466160, e: sales@westportmarine.co.uk, www.westportmarine.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PILOT4 and is the answer not in the manual?

Questions and answers

Related Manuals for Westport PILOT4

Summary of Contents for Westport PILOT4

  • Page 1 PLEASE KEEP THIS MANUAL IN A SECURE PLACE AND HAND IT OVER TO THE NEW OWNER WHEN YOU SELL YOUR CRAFT. Westport Marine, Unit2 Connaught Lane, Plymouth, Devon, UK, PL4 7BZ T: 07944 466160, e: sales@westportmarine.co.uk, www.westportmarine.co.uk...

  • Page 2: Table Of Contents

    Outboard Engine (C)...................... 10 Cleaning (C) ........................10 Winter Storage (C) ......................10 Electrical System (W) ....................10 Additional Manuals (C) ....................10 WESTPORT MARINE WARRANTY ................11 Registration ........................11 Use ..........................11 Limitation......................... 11 Claims ..........................11 Page 2 of 12...

  • Page 3: Declaration Of Conformity

    PILOT4 Owner’s Manual Recreational Craft Directive 2013/53/EU DECLARATION OF CONFORMITY Craft Identification Number GB-WPBP4_ _ _ _ _ _ _ Manufacturer Westport Marin Brand Name PILOT4 Type of Craft Outboard Powered Open Decked Motorboat Construction Material Fibre Reinforced Plastic Maximum Design Category...

  • Page 4: Abbreviations

    PILOT4 Owner’s Manual GENERAL NOTES Abbreviations The following abbreviations have been used: (D): DANGER (W): WARNING (C): CAUTION Design Category C (D) This craft has a design category ‘C’ designated “Inshore”: Craft designed for voyages in coastal waters, large bays, estuaries, lakes and rivers, where conditions up to and including wind force 6 and significant wave heights up to and including 2m may be experienced.

  • Page 5: General Information

    PILOT4 Owner’s Manual GENERAL INFORMATION Length 4.05 m Design Category Beam 1.86 m Max. No. People Draught 0.35 m Max. Load 686 Kg Max. Power 37.5 kw Boat Mass 290 Kg (excl. engine) 50.0 hp Trailering Mass Max. Speed 30.0 knots...

  • Page 6: Regular Inspection (W)

    PILOT4 Owner’s Manual REGULAR INSPECTION (W) Regular inspections should be carried out prior to use and should include at least the following:  Ensure transom & deck drains are closed, secure and in good condition.  Ensure cuddy is securely fastened and that all four safety clips are correctly fitted.

  • Page 7: Craft Mass (C)

    PILOT4 Owner’s Manual CRAFT MASS (C) A maximum total load has been used for assessing stability and buoyancy comprising: Crew mass (5) Provisions & personal effects Outboard engine Portable fuel tank and fuel Stores, spares, tools Optional equipment Miscellaneous Maximum total load...

  • Page 8: Risk Of Fire (D)

    PILOT4 Owner’s Manual RISK OF FIRE (D) Fuel and electrics onboard small boats present an inherent fire risk. Always remove the portable fuel tank from the boat and fill in a well ventilated area, away from the risk of ignition.

  • Page 9: Mooring, Anchoring & Towing (W)

    PILOT4 Owner’s Manual flushing the system with a hose prior to launching the boat. If the problem persists then the system should be examined by an experience marine engineer. Mooring, Anchoring & Towing (W) During mooring and anchoring operations access to the fore deck with the cuddy fitted is via the foredeck access hatch in the cuddy top.

  • Page 10: Outboard Engine (C)

    PILOT4 Owner’s Manual Outboard Engine (C) Refer to the engine manual. Always flush the cooling system with fresh water after use. Cleaning (C) Use as few cleaning agents as possible, do not discharge waste agents into the water, and: ...

  • Page 11: Westport Marine Warranty

    Registration 1. On completion of the sale of a new Westport Marine boat a Product & Warranty Registration Form must be completed & returned to Westport Marine Ltd, including Boat model, Hull number, Outboard model and frame number, full customer & Dealer details, date of sale, type of usage, etc.
  • Page 12 PILOT4 Owner’s Manual Westport Marine Product & Warranty Registration Form This form must be completed & returned to Westport Marine as a condition of the boat warranty. Product Details Boat Model & Accessories fitted Hull Identification Number (found on transom) Main Outboard - Model &...
