Electro Tool V2.00
The Electro Tool sample dump utility is the program to use when you want to download new piano
instrument samples and when you want to rearrange the piano configuration in your Nord Electro or Nord
Electro 2. The functionality of the Electro Tool is very straight-forward and intuitive.

Setting up the connection with the Nord Electro/Nord Electro 2

To be able to use the Electro Tool sample dump utility with your Nord Electro/Nord Electro 2 you must first
download and install the USB driver to your computer. Consult your computer manual for information on
how to install a USB driver. Note that the USB driver installation is not necessary if you upgraded your
Nord Electro to V2.0 on the same computer. After the USB driver installation, connect a USB cable
between your computer and your Nord Electro/Nord Electro 2. Note that the USB cable must support 'Full
speed 1.1 data transfer'. In practice this means that the shorter the USB cable, the better (preferably not
longer than 3 meters).

The Electro Tool program window

Double-click on the Electro Tool icon to start the program. The following window will appear:
Disk content
window
Piano files
"Up one level"
button
Connection status
Tranfering and replacing a piano sound in the Nord Electro
1. Select the new piano sound you want to send to the Electro by highlighting it in the "Disk content
window".
2. Click on a position in the "Nord Electro content window". The LED for the selected location lights up.
3. Click the "Send button". The following alert is displayed:
Here you are requested to verify that you want to delete the sound currently in the selected piano location to
make room for the new piano instrument.
Send button
Erase button
Internal memory
indicator
Progress bar
Nord Electro
content window
Exit button
