- Page 1 A160 Temp/RH/CO Data Logger PRODUCT MANUAL Item # 3611A...
-
Page 2: Table Of Contents
For customer support, or to place an order, call Spectrum Technologies at (800)248-8873 or (815)436-4440 between 7:30 am and 5:30 p.m. CST, FAX at (815)436-4460, or E-mail at in- fo@specmeters.com. Spectrum Technologies, Inc 3600 Thayer Ct. Aurora, IL 60504 www.specmeters.com... -
Page 3: Lcd Display
Thank you for purchasing a WatchDog Model A160 A-Series Data Logger. This manual describes how to use your WatchDog Logger and keep it working accurately for many years. Read this manual thoroughly in order to get effective performance from your data logger. The A160 logger also has a comprehensive LCD display with controls. -
Page 4: Control Buttons
Control Buttons Installation and Operation Power On/Off Plug in the adaptor and the meter turns on automatically with a short beep, then displays current CO , temperature, and humidity readings on the LCD. The LED will flash a bAt symbol if the bat- tery level is low. - Page 5 Alarm An audible alarm can sound when CO concentration exceeds user-set limits. The logger beeps and displays fan icon on the LCD when the CO level goes over the upper limit. The sound can be stopped by pressing any button. Setup In normal mode, hold down the SET button for at least 3 seconds to enter setup mode.
- Page 6 P3.0 Real Time Clock From the P1.0 display, press “LOG” twice to change to the P3.0 screen. Press SET to enter “P3.1” to set the real time clock. The year will be blinking. Press “LOG” or “MIN/MAX” to set the year. Press the SET button to save the setting, or ESC to exit without saving.
-
Page 7: Connecting To The Computer
Connecting to the Computer NOTE: The A160 logger requires SpecWare version 9.03 or above. If you are already running a version of SpecWare 9, an update to the latest version is available as a free download SpecWare update page www.specmeters.com. The A160 and other A-Series loggers do not use the standard gray PC interface cable that accompanies SpecWare Software. -
Page 8: Specware Software
SpecWare Software SpecWare software version 9.03, and above support the Watch- Dog A160 logger. Previous builds of SpecWare 9 can be updated via the free downloads available at www.specmeters.com. The software version can be checked by selecting “About SpecWare” from the Help menu. Complete details on the software are included in the SpecWare Software manual which is available as a pdf document on the installation CD (and accessible via the Help menu). - Page 9 clicking the icon on the SpecWare toolbar, or from the WatchDog Manager screen. Select the logging interval (ranging from 1 to 120 minutes), and ensure all channels are enabled before clicking “Ok” to launch the logger. IMPORTANT! The A160 does not begin logging until you press and hold the “LOG”...
-
Page 10: Troubleshooting
Troubleshooting The A160 logger will not power on. - Check that the AC adapter is plugged in to an outlet and the A160. - Use a paper clip or toothpick to press “reset” on the base of the logger. The readings on the LCD don’t change. Check to see if the display is in maximum or minimum mode. - Page 11 Code Problem Solution The download of Press and hold the “ESC” button for two sec- logged data has suc- onds to return to the normal display. cessfully completed. (alternating with the If you want to stop logging, press and hold value) The A160 the “ESC”...
-
Page 12: Spectrum Technologies, Inc
RMA number or for the loss of the package by any shipping company. This equipment has been manufactured for Spectrum Technologies, Inc. 3600 Thayer Ct. Aurora, IL 60585 USA The Manufacturer’s DECLARATION OF CONFORMITY is on file at the above...
