- Page 1 Model K10 O O w w n n e e r r ’ ’ s s G G u u i i d d e e...
-
Page 2: Limited Lifetime Consumer Warranty
Warranty shall be limited to the repair or replacement of the product, at the sole discretion of Clarion. If it becomes necessary to send the product or any defective part to Clarion, the product must be shipped in its original carton or equivalent carton, fully insured, with shipping charges prepaid. - Page 3 ALSO HAVE THE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE. Should you have any difficulties with the performance of this product during warranty, please call: 1-800-GO-CLARION or visit your local Ungo Pro Security dealer. You may also contact the National Service Manager at the following address below for additional service help you may need.
-
Page 4: Table Of Contents
table of contents limited lifetime consumer warranty .......i standard remote configuration ........2 what is included . -
Page 5: Standard Remote Configuration
standard remote configuration controls the Arm function. controls the Disarm function. controls Silent Arm/Disarm and an Auxiliary Output. controls the Panic function. pressed together control an Auxiliary Output. -
Page 6: What Is Included
what is included The control module Superhet receiver A pair of four-button remotes The blue status LED indicator light A push-button override switch Starter Kill Relay important information Congratulations on the purchase of your alarm/keyless entry system. Due to the complexity of this system, it must be installed by an autho- rized dealer only. -
Page 7: Fcc/Id Notice
fcc/id notice This device complies with Part 15 of FCC rules. Operation is subject to the following conditions: (1) This device may not cause harmful inter- ference, and (2) This device must accept any interference received, including interference that may cause undesirable operation. Changes or modifications not expressly approved by the party respon- sible for compliance could void the user's authority to operate this device. - Page 8 Button The unlocking/disarming function is controlled by pressing this button for one second. Button Silent Arm/Disarm and an optional auxiliary function are controlled by this button. (An optional auxiliary function, such as trunk release, can be controlled by pressing this button for 1.5 seconds.) The auxiliary output controls __________________________.
-
Page 9: Using Your System
using your system locking/arming Pressing for one second arms the system by activating the starter kill and locking the doors (if connected). The horn will honk (if con- nected) and the parking lights will flash once to confirm arming of the system. -
Page 10: Unlocking/Disarming
unlocking/disarming Pressing for one second disarms the system and unlocks the doors (if connected). The horn will honk twice (if connected) and the parking lights will flash twice to confirm disarming of the system. The optional Starter Kill will be deactivated. The status LED will turn off, unless the system is programmed for Passive Mode. -
Page 11: Disabling The System Without A Remote
disabling the system without a remote If your remote is lost or damaged, you can manually override the sys- tem. To do this, you must have the vehicle's ignition key and know where the Override switch is located. Be sure to check with the installer for the location of the Override switch. -
Page 12: Override Mode
override mode You can prevent your system from automatically activating the Starter Kill and locking the doors by using override mode. This is very useful when washing the vehicle or having it serviced. In override mode, the starter kill cannot be activated, even with the remote, but all convenience functions (door locks, trunk release, etc.) will continue to work normally. -
Page 13: Individual Recognition
individual recognition Individual recognition is a feature available. Using the Pro Security Programmer, a hand-held programming tool, your dealer can program many of the system settings. The programmer makes it possible to pro- gram different settings for each remote that is used with the system. Then, whenever a specific remote is used, the system will recall the set- tings assigned to that remote. -
Page 14: Programming Options
programming options Programming options control your system's normal, operational set-up. Most options do not require additional parts, but some may require additional installation labor. This system's programming options are list- ed below, with the factory default settings in bold: Passive Mode or Active Mode. In Passive Mode the Starter Kill will automatically activate 30 seconds after the ignition has been turned off. -
Page 15: Glossary Of Terms
glossary of terms Control Unit: The “brain” of your system. Usually hidden under the dash area of the vehicle. It houses the microprocessor that monitors your vehicle and controls all system functions. LED: A blue light mounted at a discretionary location inside the vehi- cle. - Page 16 Domelight Supervision: The domelight will illuminate for 30 seconds each time the system is disarmed using the remote. This is useful for seeing inside the vehicle at night prior to entering it. Power Door Lock Control: Your system is capable of controlling many types of power door lock systems;...
-
Page 18: Quick Reference Guide
QUICK REFERENCE GUIDE To lock/arm using your remote To arm the system press for one second. The doors will lock (if connected). The LED will begin to flash. The Starter Kill will prevent the vehicle’s starter from cranking if it has been installed. The vehicle’s horn (if connected) will honk and the parking lights will flash once to confirm arming of the system. - Page 19 Get Started Get Protected Ungo Pro Security 661 W. Redondo Beach Blvd. Gardena, Ca. 90247 800-GO-CLARION © 2003 Directed Electronics, Inc. - All rights reserved GK10 11-03...
