SERVICE MANUAL
This service manual shows only the differences between
the model EC720E and the original model 6720FDE.
All other information is described in the service manual
of the model 6720FDE.
20" COLOR
TV/DVD/VCR
EC720E
Different parts from original model (6720FDE)
Ref. No.
A1X
A1-1
A1-2
A1-3
A1-4
A1-7
A3#
A4
S1
X2#
X3
X5
Description
FRONT CABINET ASSEMBLY T1008UJ
FRONT CABINET T1008UJ
CONTROL PLATE T1008UJ
BRAND BADGE T9010UL"ESA"
CASSETTE DOOR T1008UJ
TRAY PANEL T1008UJ
RATING LABEL T1008UJ
Not Used
CARTON T1008UJ
OWNER'S MANUAL T1008UJ
REMOTE CONTROL NE230UD 151/ECNX501/NE230UD
SHEET RETURN STOP T5510UL
SUPPLEMENT
Part No.
1ESA10162
1EM120034
1EM220031
1EM420160
1EM420198
1EM420197
----------
1EM420196
1EMN20069
NE230UD
1EM420161
