Summary of Contents for Quanta Computer CTL GQE10C Series
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS ............2 SAFETY ................4 COPYRIGHT ................. 6 PRODUCT OVERVIEW ............7 Package contents .................. 7 Front view..................8 Rear View ....................9 Status indicators .................. 10 Specifications ..................11 GETTING STARTED ..............13 Connecting the AC power .............. - Page 3 OPERATING THE CTL MEET COMPUTE SYSTEM ....23 Navigating the desktop ................ 23 Managing apps................. 23 Wireless connections ................24 Connecting to a wireless access point ............24 Connecting to Bluetooth devices ..............25 Adjusting volume ................. 25 Configuring CTL Meet Compute System settings ........ 26 Finding help ..................
-
Page 4: Safety
SAFETY Your CTL Meet Compute System is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system Read and follow all instructions in the documentation before you •... - Page 5 • Clean only with a soft cloth. If needed, dampen the cloth slightly before cleaning. Never use abrasives or cleaning solutions. • Always disconnect the device from an electrical outlet and power off before cleaning the device. • Do not handle the device with wet hands while it is being charged.
-
Page 6: Copyright
COPYRIGHT Wi-Fi and the Wi-Fi CERTIFIED logo are registered trademarks of the Wireless Fidelity Alliance. SD™ is a trademark of SD Card Association. All products use in this device and trademarks mentioned herein are trademarks or registered trademarks of their respective owners. ©... -
Page 7: Product Overview
PRODUCT OVERVIEW Package contents Please take a moment to check if all the necessary items are included in the package. If anything is missing or damaged, please contact your dealer immediately. • CTL GQE10C CTL Meet • VESA mounting Plate & Compute System screw set •... -
Page 8: Front View
Front view GQE10C model Description Description Power LED » NOTE: *Supports battery charging. PRODUCT OVERVIEW... -
Page 9: Rear View
Rear View GQE10C model Description Description Power button (5) USB3.0 ports ** Audio jack (3.5mm) LAN port* DC-in jack /USB type-C port Kensington lock port HDMI port Reset hole » NOTE: *CTL Meet Compute System models without HDD support single LAN port and models with HDD support dual LAN port. -
Page 10: Status Indicators
Status indicators Indicator Color Status Description Power button CTL Meet Compute System is Power LED White switched on. CTL Meet Compute System is switched off. LAN port Flashing Activity on the link. Orange No activity on the link. LAN port Active link connection. -
Page 11: Specifications
Specifications Item Description • CPU Intel Core i7-8550U Quad Core 1.86GHz BGA Processor 8MBL3 UHD 620 Operating system Google Chrome OS Memory 4G DDR4, 2 slots Memory type 2133 DDR4 SODIMM (DDR4-2133), Graphics Intel HD120 Graphics VGA Intel CPU integrated Graphics Storage Storage capacity 128G (upgradable to 256G) - Page 12 Item Description Connectors Front: Rear: • Audio jack (3.5mm) • LAN port • (5) USB3.0 ports • HDMI port • DC-in jack • USB type-C port Temperature 32°F to 95°F (0°C to 35°C) Humidity 30-80% VESA mounting 187 x 111 mm Dimensions Unit model: •...
-
Page 13: Getting Started
GETTING STARTED Connecting the AC power adapter to your system To connect your CTL Meet Compute System to the power outlet, do the following: 1. Connect one end of the power cord to the AC adapter and the other end to the power outlet. 2. -
Page 14: Connecting A Display Device
Connecting a display device You can connect a display panel or projector to your system that has the following connectors: • HDMI connector • DisplayPort (USB Type-C™) To establish the HDMI connection, you need to use an HDMI cable (not supplied). 1. -
Page 15: Connecting Audio Components
Performing additional connections Connecting audio components Connect the audio component into the audio jack of your CTL Meet Compute System. Connecting to local area network (LAN) 1. Connect one end of the RJ-45 cable to the LAN port of your CTL Meet Compute System. - Page 16 GETTING STARTED...
-
Page 17: Mounting The Chromebox
Installation Instructions: Mount Kit for Meeting Computer System GQE10C Installing Wall Mount/Installation support ATTENTION: The equipment shall not be mounted higher than 2m from the floor or shall not be mounted higher than 75cm from a flat surface. ● Screw wall mount onto wall (Screw is self-tapping M3.5 24mm long, flat countersunk head) NOTE: Make sure your display device supports VESA mounting. - Page 18 Mount Kit for Meeting Computer System GQE10C Installing Stand Mount/Installation ● Find the ‘Pill Shape’ marking to orientate the box so that the exhaust/fan faces upwards ● Align ‘Pill Shape’ mounting features and bring the device closer to the mount ●...
- Page 19 Mount Kit for Meeting Computer System GQE10C Caution: Pulling or pushing on the Meeting Computer System may cause the device to fall. Warning: Do not install your mount kit while your Meeting Computer System is turned on. This may result in personal injury from electric shock GETTING STARTED (mounting)
- Page 20 GETTING STARTED (Mounting)
-
Page 21: Powering On Your Ctl Meet Compute System
Powering on your CTL Meet Compute System To power on your CTL Meet Compute System, press the Power button on the front panel. The Power button LED lights solid white. After you power on the CTL Meet Compute System for the first time, you are asked to configure some device’s basic settings, such as set the language, configure accessibility options, connect to the network, and finally sign in to your CTL Meet Compute System. - Page 22 GETTING STARTED...
-
Page 23: Operating The Ctl Meet Compute System
OPERATING THE CTL MEET COMPUTE SYSTEM Navigating the desktop After the initial setup is configured, you will see the desktop. Click on any of the following items: Launcher: Manage installed apps and perform search. • App launcher: Access most frequently used apps quickly. •... -
Page 24: Wireless Connections
2. Do any of the following: • Search for installed apps by typing the app name in the search bar (Search your device, apps, web...). • Review recently accessed apps (appear below search bar). • Click on to review and access all apps installed on your CTL Meet Compute System. -
Page 25: Connecting To Bluetooth Devices
Connecting to Bluetooth devices 1. Click anywhere on the Status tray to open the tray. 2. Click on next to the Bluetooth icon. 3. Enable Bluetooth function. Your CTL Meet Compute System starts to look for available Bluetooth devices automatically. 4. -
Page 26: Configuring Ctl Meet Compute System Settings
Configuring CTL Meet Compute System settings 1. Click anywhere on the Status tray to open the tray. 2. Click on . The Settings page opens. 3. Configure any of the following: • Network > Ethernet: LAN connection parameters. » NOTE: Make sure your CTL Meet Compute System is connected to the LAN. -
Page 27: Finding Help
• Appearance > Show Home button: Configure displaying Home button settings. • Appearance > Show bookmarks bar: Enable or disable displaying bookmarks bar on web browser. • Appearance > Font size: Set the font size. • Appearance > Customise fonts: Click to customise fonts. •... - Page 28 OPERATING THE CTL MEET COMPUTE SYSTEM...
-
Page 29: Troubleshooting
TROUBLESHOOTING If you experience a problem with your CTL Meet Compute System, refer to the following troubleshooting guide. If a problem persists, contact the service center. The power is switched on, but CTL Meet Compute System does not start: • Make sure that the AC adapter is properly plugged into the DC-in jack of the CTL Meet Compute System and to the power outlet. -
Page 30: Ctl Contact Information
Pontevedra nº8, Piso 1, Oficina 6 36202 Vigo, Pontevedra, Espania Teléfono: 986 11 74 73 Email: atencionalcliente@ctl.net Web Site: http://es.ctl.net Manufacturer: CTL/Quanta Computer Address: ： No. 211, Wenhua 2nd Rd., Guishan Dist., Taoyuan City 333, Taiwan Tel：+886-3-327-2345 Fax：+886-3-327-8855 Authorized representative in CTL Spain S.L Europe Pontevedra nº8, Piso 1, Oficina 6...
