Summary of Contents for Dametric K-DDRS1
- Page 1 K-DDRS1 dametric K-DDRS1 VAL0122855 / SKC9315710 ROTATING CABLE TO RMS-DD USERS MANUAL K-DDRS1 EN.docx Nov. 15, 2016 / DW 1(4)
- Page 2 6-pole with bayonet, LE-2S-ISO + LE-2E-KABM Cable: 6 leads with teflon isolation, 0.75 mm2 Protection: Flexible stainless steel tube Length: 3.79 m CONNECTION DIAGRAM white white brown brown green green yellow yellow grey grey K-DDRS1 EN.docx Nov. 15, 2016 / DW 2(4)
- Page 3 Place the cable in the cable guide inside the rotating transformer, and mount the locking screw. Mount the TVD-TA1 transducer. Mount the Safeset clutch. K-DDRS1 EN.docx Nov. 15, 2016 / DW 3(4)
- Page 4 CONTACT Sales, development, production and service: dametric Dametric AB Jägerhorns Väg 19, SE 141 75 Kungens Kurva, Sweden Phone: +46-8 556 477 00 Telefax: +46-8 556 477 29 E-Mail: service@dametric.se Website: www.dametric.se K-DDRS1 EN.docx Nov. 15, 2016 / DW 4(4)
