Kia MOHAVE 2014 Owner's Manual

page of 417

/ 417
Bookmarks

Quick Links

E2JO-EE3OA (L)

Owner's Manual

Supplement

This supplement has information on seat belt warning for the Owner's Manual.

Summary of Contents for Kia MOHAVE 2014

Page 1 E2JO-EE3OA (L) Owner’s Manual Supplement This supplement has information on seat belt warning for the Owner’s Manual.
Page 3 SEAT BELTS Seat belt warning If the driver's seat belt is not fastened ■ ■ Type B when the ignition switch is turned ON As a reminder to the driver, the driv- or if it is unfastened after the ignition er’s seat belt warning lights will illu- switch is ON, the seat belt warning minate for approximately 6 seconds...
Page 4 Kia Motors is dedicated to providing you with a customer service experience that exceeds your expectations. At all of our Kia dealerships you will be treated with warmth, hospitality and professionalism by people who care based on our “Family-like Care”...
Page 5 Thank you for choosing a KIA vehicle. The information and specifications provided in this man- ual were accurate at the time of printing. KIA reserves When you require service, remember that your dealer the right to discontinue or change specifications or design knows your vehicle best.
Page 6 Introduction Your vehicle at a glance Safety features of your vehicle Features of your vehicle Driving your vehicle table of contents What to do in an emergency Maintenance Specifications & Consumer information Index...
Page 7 Introduction How to use this manual / 1-2 Fuel requirements / 1-2 Vehicle handling instructions / 1-5 Vehicle break-in process / 1-5 Indicator symbols on the instrument cluster / 1-6...
Page 8 These WARNINGs were prepared to Unleaded cle. Your Owner’s Manual can assist you enhance your personal safety.You should Your new Kia vehicle is designed to use in many ways. We strongly recommend carefully read and follow ALL procedures only unleaded fuel having an Octane that you read the entire manual.
Page 9 3. Leaded fuel or leaded gasohol. lems that are caused by the use of ask an authorized Kia dealer whether fuels containing methanol or fuels leaded gasoline in your vehicle is avail- CAUTION containing MTBE (Methyl Tertiary able or not.
Page 10 Fuel Additives (if equipped with DPF) this will increase wear and cause dam- Kia recommends that you use good qual- age to the engine and fuel system. The It is recommended to use the regu- ity gasolines meet Europe Fuel stan-...
Page 11 Introduction VEHICLE HANDLING VEHICLE BREAK-IN PROCESS INSTRUCTIONS Biodiesel (for New Zealand) A030000AUN A090000AEN Commercially supplied Diesel blends of No special break-in period is needed. By As with other vehicles of this type, failure no more than 7% biodiesel, commonly following a few simple precautions for the to operate this vehicle correctly may known as "B7 Diesel"...
Page 12 Introduction INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER A050000AHM-EE ESP indicator* DBC indicator* Door ajar warning light ESP OFF indicator* ALS indicator* Door open position indicator Parking brake & Brake fluid Tailgate open warning light Cruise indicator* warning light Engine oil pressure warning light Seat belt warning light Cruise SET indicator* High beam indicator...
Page 13 Your vehicle at a glance Interior overview / 2-2 Instrument panel overview / 2-3 Engine compartment / 2-4...
Page 14 Your vehicle at a glance INTERIOR OVERVIEW 1. Door lock/unlock button ....4-15 2. Outside rearview mirror folding button*..........4-46 3. Outside rearview mirror control switch ..........4-45 4. Central door lock switch....4-15 ■ Type A 5. Power window lock button ....4-23 6. Power window switches ....4-20 7.
Page 15 Your vehicle at a glance INSTRUMENT PANEL OVERVIEW 1. Instrument cluster......4-47 2. Steering wheel audio controls* ..4-125 3. Light control / Turn signals ....4-71 4. Horn ..........4-39 5. Auto cruise controls* ......5-44 6. Wiper/Washer switch......4-77 7. Driver’s front air bag......3-48 8.
Page 16: Table Of Contents
Your vehicle at a glance ENGINE COMPARTMENT Gasoline Engine (3.8L) ■ ■ 1. Engine coolant reservoir ....7-20 2. Engine oil filler cap......7-18 3. Brake fluid reservoir ......7-22 4. Air cleaner........7-26 5. Fuse box .........7-45 6. Negative battery terminal....7-32 7. Positive battery terminal ....7-32 Gasoline Engine (4.6L) ■...
Page 17 Your vehicle at a glance Diesel Engine (3.0L) ■ ■ 1. Engine coolant reservoir....7-20 2. Engine oil filler cap ......7-18 3. Fuel filter..........7-25 4. Brake fluid reservoir......7-22 5. Air cleaner ........7-26 6. Fuse box ..........7-45 7. Negative battery terminal ....7-32 8.
Page 18 Seats / 3-2 Seat belts / 3-21 Child restraint system / 3-33 Air bag - supplemental restraint system / 3-42 Safety features of your vehicle...
Page 19 Safety features of your vehicle SEATS Front seat (1) Forward and backward (2) Seatback angle (3) Seat cushion height (Driver’s seat) (4) Lumbar support (Driver’s seat)* (5) Seat warmer* (6) Climate control seat (Driver’s seat)* (7) Headrest Manual seat 2nd row seat (8) Forward and backward (9) Seatback angle and folding (10) Walk-in seat...
Page 20 Safety features of your vehicle (Continued) WARNING - WARNING Uprighting • In order to avoid unnecessary seat Do not use a sitting cushion that and perhaps severe air bag reduces friction between the seat When you return the seatback to its injuries, always sit as far back as and passenger.
Page 21 Safety features of your vehicle (Continued) WARNING • No passenger should ride in the • Do not adjust the seat while wear- cargo area or sit or lie on folded ing seat belts. Moving the seat seatbacks while the vehicle is cushion forward cause...
Page 22 Safety features of your vehicle OHM038003 OHM038004 OHM038048N C010102AHM C010103APB C010104AHM Seatback angle Seat height (for driver’s seat) Headrest To recline the seatback: To change the height of the seat, push The driver's and front passenger's seats are equipped with a headrest for the the lever upwards or downwards.
Page 23 Safety features of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes.
Page 24 Safety features of your vehicle ■ Type A ■ Type A WARNING NEVER allow anyone to ride in a seat with the headrest removed. OHM033202 OHM033203 ■ Type B ■ Type B OHM033200 OHM033201 Removal Reinstall To remove the headrest: To reinstall the headrest : 1.
Page 25 Safety features of your vehicle WARNING Always make sure the headrest locks into position after reinstalling and adjusting it properly. HNF2041-1 OHM038008 C010105AHM Active headrest (if equipped) Lumbar support (for driver’s seat) The active headrest is designed to move forward and upward during a rear impact. The lumbar support can be adjusted by This helps prevent the driver's and front moving the lever.
Page 26 Safety features of your vehicle ✽ ✽ NOTICE WARNING - Seat warmer With the seat warmer switch in the ON burns position, the heating system in the seat turns off or on automatically depending Passengers should use extreme on the seat temperature. caution when using seat warmers due to the possibility of excess heating or burns.
Page 27 If there is OFF→HIGH( )→MIDDLE( )→LOW( no change, have your vehicle Seat warmer (Passenger’s seat) inspected by an authorized Kia ■ dealer. • Do not change the seat cover. It may damage the seat warmer or airventilation system.
Page 28 Safety features of your vehicle C010200AHM Type A ■ WARNING Front seat adjustment - power (if equipped) Passengers should use extreme caution when using the climate The front seat can be adjusted by using control seat to warm due to the the control switches located on the out- possibility of excess heating or side of the seat cushion.
Page 29 Safety features of your vehicle CAUTION • The power seat is driven by an electric motor. Stop operating once the adjustment is complet- ed. Excessive operation may damage the electrical equipment. • When in operation, the power seat consumes a large amount of electrical power.
Page 30 Safety features of your vehicle OHM038013L OHM038014 OHM038015 C010203AHM Rear seat adjustment C010204AHM Seat height (for driver’s seat) Lumbar support C010301AHM Pull the front portion of the control switch (for driver’s seat, if equipped) Forward and backward (2nd row seat) up to raise or down to lower the front part The lumbar support can be adjusted by To move the seat forward or backward:...
Page 31 Safety features of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes.
Page 32 Safety features of your vehicle WARNING Make sure the headrest locks in position after adjusting it to proper- ly protect the occupants. OHM038017 OHM038018N Adjusting the height up and down Removal To raise the headrest, pull it up to the To remove the headrest, raise it as far as desired position (1).
Page 33 Safety features of your vehicle ✽ ✽ NOTICE With the seat warmer switch in the ON state, the heating system in the seat turns off or on automatically depending on the seat temperature. CAUTION • When cleaning the seats, do not use an organic solvent such as thinner, benzene, alcohol and gasoline.
Page 34 Safety features of your vehicle After getting in or out, slide the 2nd row C010307AHM seat to the farthest rearward position and Folding the rear seat pull the seatback firmly backward until it The rear seatbacks can be folded to facil- clicks into place.
Page 35 Safety features of your vehicle To fold down the rear seatback: 2nd row seat 2nd row seat ■ ■ 1. Insert the rear seat belt buckle in the pocket between the rear seatback and cushion, and insert the rear seat belt webbing in the guide to prevent the seat belt from being damaged.
Page 36 Safety features of your vehicle WARNING WARNING Uprighting seat When you return the rear seatback to its upright position after being When you return the seatback to its folded down: upright position, hold the seatback and return it slowly. If the seatback Be careful not to damage the seat is returned without holding it, the belt webbing or buckle.
Page 37 Safety features of your vehicle CAUTION - Rear seat belts WARNING - Cargo When returning the rear (2nd and/or Cargo should always be secured to 3rd row) seatbacks to the upright prevent it from being thrown about position, remember to return the rear the vehicle in a collision and caus- shoulder belts to their proper posi- ing injury to the vehicle occupants.
Page 38 Safety features of your vehicle SEAT BELTS C020100CHM (Continued) (Continued) Seat belt restraint system • Never wear a seat belt over frag- A slack belt will greatly reduce the ile objects. If there is a sudden protection afforded to the wearer. WARNING stop or impact, the seat belt can Care should be taken to avoid con-...
Page 39 Safety features of your vehicle WARNING • No modifications or additions should be made by the user which will either prevent the seat belt adjusting devices from oper- ating to remove slack, or prevent the seat belt assembly from being adjusted to remove slack.
Page 40 Safety features of your vehicle To raise the height adjuster, pull it up (1). ✽ ✽ NOTICE Front seat To lower it, push it down (3) while press- If you are not able to pull out the safety ing the height adjuster button (2). belt from the retractor, firmly pull the Release the button to lock the anchor belt out and release it.
Page 41 Safety features of your vehicle B200A02NF OHM038028N B210A01NF-1 When using the rear center seat belt, the To release the seat belt: buckle with the “CENTER” mark must be WARNING The seat belt is released by pressing the used. (if equipped) release button (1) in the locking buckle.
Page 42 Safety features of your vehicle OHM039105N B220A04NF OHM038028L C020103AHM When using the rear center seat belt, the Lap belt (if equipped) buckle with the “CENTER” mark must be used. To fasten your seat belt: Too high To fasten a 2-point static type belt, insert the metal tab (1) into the locking buckle (2).
Page 43 Safety features of your vehicle 2nd row seat 2nd row seat ■ ■ OHM038031 OHM038029L 3rd row seat 3rd row seat ■ ■ B210A02NF-1 To release the seat belt: When you want to release the seat belt, press the button (1) in the locking buckle. WARNING OHM038032 The center lap belt latching mecha-...
Page 44 Safety features of your vehicle If the system senses excessive seat belt tension on the driver or passenger's seat belt when the pre-tensioner activates, the load limiter inside the pre-tensioner will release some of the pressure on the affected seat belt. (if equipped) ✽...
Page 45 This must be done • When the pre-tensioner seat belts are switch is turned ON, or if it remains by an authorized Kia dealer. activated, a loud noise may be heard illuminated after illuminating for • Do not strike the pre-tensioner...
Page 46 Always use a vehicle may damage the pre-tension- child restraint appropriate for your er seat belt system. Therefore, we child's height and weight. recommend that the system be serv- iced by an authorized Kia dealer. 3 29...
Page 47 Safety features of your vehicle C020301AHM ✽ ✽ NOTICE Larger children WARNING - Shoulder belts Small children are best protected from on small children Children who are too large for child injury in an accident when properly restraint systems should always occupy •...
Page 48 Safety features of your vehicle C020302BUN C020303AUN C020305AHM Pregnant women Injured person Do not lie down The use of a seat belt is recommended A seat belt should be used when an To reduce the chance of injuries in the event for pregnant women to lessen the chance injured person is being transported.
Page 49 This should be done even if no damage is visible. Additional questions concern- ing seat belt operation should be directed to an authorized Kia dealer.
Page 50 Safety features of your vehicle CHILD RESTRAINT SYSTEM (IF EQUIPPED) C030000CHM Children riding in the vehicle should sit in WARNING WARNING the rear seat and must always be properly • A child restraint system must be To reduce the chance of serious or restrained to minimize the risk of injury in placed in the rear seat.
Page 51 Forward-facing child restraint system two persons, to use the same • After an accident, have an author- seat belt. ized Kia dealer check the child • Children often squirm and repo- restraint system, seat belt, tether sition themselves improperly. anchor and lower anchor.
Page 52 C030101AHM the system checked immediately Installing a child restraint system by your authorized Kia dealer. with a lap belt (on the center rear • Failure to observe this manual's seat) (if equipped) - Except Europe...
Page 53 Safety features of your vehicle E2MS103005 OEN036101 OEN036104 2. Fasten the lap/shoulder belt latch into 3. Buckle the seat belt and allow the seat C030102AHM the buckle. Listen for the distinct “click” belt to take up any slack. After installa- Installing a child restraint system sound.
Page 54 Safety features of your vehicle C030105AHM Child seat restraint suitability for seat position using the seat belt - For Europe Use child safety seats that have been officially approved and are appropriate for your children. When using the child safety seats, refer to the following table. Seating position Age group Front...
Page 55 Safety features of your vehicle WARNING WARNING - Child restraint check A child can be seriously injured or killed in a collision if the child Check that the child restraint sys- restraint is not properly anchored tem is secure by pushing and to the car and the child is not prop- pulling it in different directions.
Page 56 Safety features of your vehicle ISOFIX Anchor Position Indicator ISOFIX Anchor OUN036101L OHM038045N OHM038046N C030104BHM-EE There is a child restraint symbol located On each side of the rear seat, between Securing a child restraint system on the lower portion of each side of the the cushion and backrest, are located a with “ISOFIX”...
Page 57 Safety features of your vehicle To secure the child restraint seat (Continued) WARNING 1. To engage the child restraint seat to In a crash, the child restraint seat the ISOFIX anchor, insert the child Install the child restraint seat fully ISOFIX attachments may not be restraint seat latch into the ISOFIX rearward against the seatback with...
Page 58 Safety features of your vehicle C030106AHM Child seat restraint suitability for vehicle ISOFIX positions - For Europe vehicle ISOFIX positions Mass Group Size Class Fixture 2nd Outboard 2nd Outboard Front Passenger 2nd Center (Driver side) (Passenger side) ISO/L1 Carrycot ISO/L2 0 : UP to 10kg ISO/R1 ISO/R1...
Page 59 Before scraping a vehicle, we rec- ommend that you contact an authorized Kia dealer. • Keep the SRS parts and wirings away from water or any liquid. If the SRS components are inoper-...
Page 60 Safety features of your vehicle C040900CHM • Air bag deployment depends on a num- • There even circumstances How does the air bag system ber of factors including vehicle speed, under which contact with the steer- angles of impact and the density and ing wheel air bag can cause fatal operate stiffness of the vehicles or objects which...
Page 61 Safety features of your vehicle Never place a rear-facing child restraint C040902AHM ■ Type A in the front passenger’s seat. If the air Noise and smoke bag deploys, it would impact the rear-fac- When the air bags inflate, they make a ing child restraint, causing serious or loud noise and they leave smoke and fatal injury.
Page 62 SRS air bag warning light should go out. If any of the following conditions occurs, this indicates a malfunction of the SRS. W7-147 OHM039100L Have an authorized Kia dealer inspect C041000AEN C040100BHM the air bag system as soon as possible. Air bag warning light SRS components and functions •...
Page 63 Safety features of your vehicle Driver’s front air bag (1) Driver’s front air bag (2) Driver’s front air bag (3) B240B01L B240B02L B240B03L The front air bag modules are located Upon deployment, tear seams molded A fully inflated air bag, in combination both in the center of the steering wheel directly into the pad covers will separate with a properly worn seat belt, slows the...
Page 64 If this occurs, have your vehi- cle, do not place it near the cle immediately inspected by an instrument cluster nor on the authorized Kia dealer. instrument panel surface. (Continued) It may become a dangerous pro- jectile and cause injury if the pas- senger's air bag inflates.
Page 65 Safety features of your vehicle The indications of the system's presence Driver’s front air bag letters "SRS BAG" WARNING embossed on the air bag pad cover on Always use seat belts and child the steering wheel and the passenger's restraints – every trip, every time, side front panel pad above the glove box.
Page 66 Kia dealer inspect the air bag system as soon as possible. • You and your passengers should never sit or lean unnecessarily •...
Page 67 Safety features of your vehicle (Continued) (Continued) • A child restraint system must • Sitting improperly or out of posi- never be placed in the front seat. tion can result in serious or fatal The infant or child could be injury in a crash.
Page 68 • If the seat or seat cover is dam- is in motion. The air bags deploy (Continued) aged, have the vehicle checked only in certain side impact or and repaired by an authorized Kia rollover* conditions severe dealer because your vehicle is...
Page 69 OHM032070 only be done by an authorized bags to provide the best protec- ❈ The actual air bags in the vehicle may dif- Kia dealer. tion, front seat occupants and fer from the illustration. Failure to follow the above instruc-...
Page 70 Safety features of your vehicle C040800DHM Why didn’t my air bag go off in a collision? (Inflation and non-infla- tion conditions of the air bag) There are many types of accidents in which the air bag would not be expect- ed to provide additional protection.
Page 71 Have the result in serious personal injury vehicle checked and repaired by or death. an authorized Kia dealer. • If the installation location or • Your vehicle has been designed angle of the sensors is altered in...
Page 72 Safety features of your vehicle ✽ ✽ NOTICE - Except Middle East and China Also, the side impact and curtain air bags are designed to inflate when a rollover is detected by a rollover sensor. Although the front air bags (driver’s and front passenger’s air bags) are designed to inflate only in frontal collisions, they also may inflate in other types of colli-...
Page 73 Safety features of your vehicle OUN036087 OVQ036018N 1VQA2089 • Air bags are not designed to inflate in • Front air bags may not inflate in side • In an angled collision, the force of rear collisions, because occupants are impact collisions, because occupants impact may direct the occupants in a moved backward by the force of the move to the direction of the collision,...
Page 74 Safety features of your vehicle 1VQA2090 1VQA2091 1VQA2092 • Just before impact, drivers often brake • Front air bags may not inflate in • Air bags may not inflate if the vehicle heavily. Such heavy braking lowers the rollover accidents because front air collides with objects such as utility front portion of the vehicle causing it to bag deployment would not provide...
Page 75 Kia dealer. Improper handling of the SRS observed. An authorized Kia • No objects should be placed over system may result in serious personal dealer knows these precautions or near the air bag modules on injury.
Page 76 Safety features of your vehicle C041300AUN • Keep occupants away from the air Additional safety precautions bag covers. All occupants should sit WARNING upright, fully back in their seats with • Never let passengers ride in the • Sitting improperly or out of posi- their seat belts on and their feet on the cargo area or on top of a folded- tion can cause occupants to be...
Page 77 Safety features of your vehicle * : if equipped OHM038043 C041200AHM Air bag warning label Air bag warning labels are attached on sunvisors to alert the driver and passengers of the potential risk of the air bag system. Note that these government warnings focus on the risk of children.
Page 78 Keys / 4-3 Smart key / 4-6 Remote keyless entry / 4-9 Theft-alarm system / 4-12 Door locks / 4-14 Tailgate / 4-18 Windows / 4-20 Hood / 4-24 Features of your vehicle Fuel filler lid / 4-26 Sunroof / 4-29 Driver position memory system / 4-33 Power adjustable pedals / 4-36 Steering wheel / 4-37...
Page 79 Automatic climate control system / 4-99 Windshield defrosting and defogging / 4-110 Storage compartment / 4-113 Interior features / 4-116 Exterior feature / 4-124 Audio system / 4-126 Features of your vehicle...
Page 80 Should you lose key) is dangerous even if the key is your keys, we recom- mend that you contact an authorized Kia not in the ignition or start button is dealer. Remove the key code tag and ACC or ON position. Children copy store it in a safe place.
Page 81 Features of your vehicle To deactivate the immobilizer sys- ✽ ✽ NOTICE tem: When starting the engine, do not use the Insert the ignition key into the key cylin- key with other immobilizer keys around. der and turn it to the ON position. Otherwise the engine may not start or may stop soon after it starts.
Page 82 ✽ ✽ NOTICE CAUTION If you need additional keys or lose your Do not change, alter or adjust the keys, consult an authorized Kia dealer. immobilizer system because it could cause the immobilizer sys- CAUTION tem to malfunction and should only...
Page 83 Features of your vehicle SMART KEY (IF EQUIPPED) OXM049001 OXM049200 OHM048002 D040000AHM Smart key operation D040101BHM With a smart key, you can lock or unlock Locking To remove the mechanical key, press and a door (and tailgate) and even start the Pressing the button of the front outside hold the release button (1) and remove engine without inserting the key.
Page 84 Features of your vehicle Even though you press the button, the D040102BHM D040103AHM doors will not lock and the chime sounds Unlocking Tailgate unlocking 3 times if any of the following occurs: Pressing the button of the front outside If you are within 0.7~1 m (28~40 in.) from •...
Page 85 OXM049200 authorized Kia dealer to protect it distance between the two devices. D040400AHM from potential theft. Restrictions in handling keys •...
Page 86 Features of your vehicle REMOTE KEYLESS ENTRY (IF EQUIPPED) Remote keyless entry system D020104AHM Type A ■ Tailgate unlock (3) (if equipped) operations The tailgate is unlocked if the button is D020101BHM-EE pressed for more than 1 second. Lock (1) The hazard warning lights will blink twice All doors (and tailgate) are locked if the to indicate that the tailgate is unlocked.
Page 87 If the keyless entry For transmitter replacement, see an an airport which can interfere with system is inoperative due to authorized Kia dealer to reprogram the normal operation of the transmitter. changes modifications transmitter.
Page 88 3. Install the battery in the reverse order ture or static electricity. If you are of removal. unsure how to use or replace the battery, contact an authorized Kia dealer. • Using the wrong battery can OEN046004 cause the transmitter or smart Type C ■...
Page 89 ✽ ✽ NOTICE D030100BHM-EE Armed stage The theft-alarm system by the key can be Park the vehicle and stop the engine. activated by an authorized Kia dealer. Arm the system as described below. Armed If you want this feature, consult an stage 1.
Page 90 After the doors are unlocked, the hazard serviced by an authorized Kia deal- warning lights will blink twice to indicate that the system is disarmed. Malfunctions caused by improper...
Page 91 Features of your vehicle DOOR LOCKS ✽ ✽ NOTICE • In cold and wet climates, door lock and door mechanisms may not work properly due to freezing conditions. • If the door is locked/unlocked multi- ple times in rapid succession with either the vehicle key or door lock switch, the system may stop operating Unlock...
Page 92 Features of your vehicle • If the inner door handle of the driver’s Driver’s door (or front passenger’s) door is pulled when the door lock button is in the lock position, the button will unlock and the door will open. (if equipped) •...
Page 93 Features of your vehicle • When pressing the front portion (1) of the switch, all vehicle doors will lock. WARNING - WARNING Doors Unlocked vehicles • When pressing the rear portion (2) of • The doors should always be fully the switch, all vehicle doors will unlock.
Page 94 (2) until the rear door child safety lock is unlocked ( D050400AHM-EE ✽ ✽ NOTICE WARNING - Rear door An authorized Kia dealer can activate locks deactivate some auto door lock/unlock features as follows;...
Page 95 Features of your vehicle TAILGATE ✽ ✽ NOTICE D070200BHM Closing the tailgate In cold and wet climates, door lock and To close the tailgate, lower and push door mechanisms may not work proper- down the tailgate to the first detent. Then ly due to freezing conditions.
Page 96 Features of your vehicle WARNING WARNING Exhaust fumes • For emergencies, be fully aware of the location of the emergency If you drive with the tailgate tailgate safety release lever in the opened, you will draw dangerous vehicle and how to open the tail- exhaust fumes into your vehicle gate if you are accidentally which can cause serious injury or...
Page 97 Features of your vehicle WINDOWS D080000AHM-EE (1) Driver’s door power window switch (2) Front passenger’s door power win- dow switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing (6) Automatic power window up*/down (Driver’s window) (7) Power window lock switch * : if equipped...
Page 98 Features of your vehicle D080100BHM-EE Power windows The ignition switch must be in the ON position for power windows to operate. Each door has a power window switch that controls the door's window. The driv- er has a power window lock button which can block the operation of passenger windows.
Page 99 Features of your vehicle ✽ ✽ NOTICE The automatic reverse feature for the driver’s window is only active when the “auto up” feature is used by fully pulling up the switch. The automatic reverse feature will not operate if the window is raised using the halfway posi- tion on the power window switch.
Page 100 Features of your vehicle CAUTION WARNING - Windows • To prevent possible damage to • NEVER leave the keys in your the power window system, do not vehicle with unsupervised chil- open or close two windows or dren when the engine is running. more at the same time.
Page 101 Features of your vehicle HOOD D090200AHM Closing the hood 1. Before closing the hood, check the fol- lowing: • All filler caps in the engine compart- ment must be correctly installed. • Gloves, rags or any other com- bustible material must be removed from the engine compartment.
Page 102 Features of your vehicle WARNING WARNING • Before closing the hood, ensure • Always double check to be sure that all obstructions are removed that the hood is firmly latched from the hood opening. Closing before driving away. If it is not the hood with an obstruction latched, the hood could open present in the hood opening may...
Page 103 Features of your vehicle FUEL FILLER LID D100200AUN Closing the fuel filler lid 1. To install the cap, turn it clockwise until it “clicks”. This indicates that the cap is securely tightened. 2. Close the fuel filler lid and push it light- ly and make sure that it is securely closed.
Page 104 Features of your vehicle (Continued) (Continued) WARNING - Refueling dan- Use only approved portable plas- • Do not get back into a vehicle gers tic fuel containers designed to once you have begun refueling Automotive fuels are flammable carry and store gasoline. since you can generate static materials.
Page 105 1. • If the fuel filler cap requires replacement, use only a genuine Kia cap or the equivalent speci- fied for your vehicle. An incorrect fuel filler cap can result in a seri- ous malfunction of the fuel sys- OHM048023N tem or emission control system.
Page 106 Features of your vehicle SUNROOF (IF EQUIPPED) ✽ ✽ NOTICE ✽ ✽ NOTICE • In cold and wet climates, the sunroof • The sunroof cannot slide when it is in may not work properly due to freez- the tilt position nor can it be tilted ing conditions.
Page 107 Features of your vehicle To open the sunroof automatically: Pull the sunroof control lever backward to the second detent position and then release it. The sunroof will slide open automatically but will not open all the way. If you would like to completely open the sunroof, pull the lever once more.
Page 108 Features of your vehicle WARNING - Sunroof • Be careful that no head, hands and body parts are obstructed by a closing sunroof. • Do not extend the face, neck, arms or body outside the sunroof while driving. • Make sure your hands and head are safely out of the way before closing a sunroof.
Page 109 Features of your vehicle D110500AHM-EE 5. Push the sunroof control lever upward Resetting the sunroof (about 6 seconds) until the sunroof operates as follows; Whenever the vehicle battery is discon- nected or discharged, you must reset TILT DOWN → SLIDE OPEN → your sunroof system as follows: SLIDE CLOSE 1.
Page 110 The buzzer sounds 10 times if the mem- ory system malfunctions. Have the driv- D120101AHM-EE er position memory system checked by Storing driver’s seat positions an authorized Kia dealer. 1. Shift the transmission shift lever into P (Park) while the ignition switch is ON. WARNING 2. Adjust...
Page 111 Features of your vehicle D120102AHM-EE D120300AHM Recalling positions from memory WARNING Easy access function (if equipped) 1. Shift the transmission shift lever into P Use caution when recalling adjust- (Park) under one of the followings: ment memory while sitting in the With the shift lever in P (Park) position, vehicle.
Page 112 Features of your vehicle To deactivate or activate the easy access Neutral : When the remote control out- function side rearview mirror switch is placed in the middle position, 1. Shift the transmission shift lever into P the outside rearview mirrors (Park) while the ignition switch is ON.
Page 113 Features of your vehicle POWER ADJUSTABLE PEDALS (IF EQUIPPED) D310100AHM Setting the adjustable pedal posi- WARNING tion • Adjust the pedals after parking the vehicle on level ground. 1. Be sure the parking brake is engaged. Never attempt to adjust the ped- 2.
Page 114 Kia dealer. is first started. This is caused by increased fluid viscosity due to the cold WARNING...
Page 115 Features of your vehicle Type A ■ OXM043012 Type B ■ OHM048034N OHM048035N D130301AHM D130302AHM-EE Manual type (if equipped) Electric type (if equipped) To change the steering wheel angle, Adjust the steering wheel angle (2) and adjust the steering wheel to the desired position (3) with the control switch (1).
Page 116 Features of your vehicle ✽ ✽ NOTICE CAUTION The heated steering wheel will turn off Do not strike the horn severely to automatically approximately 30 minutes operate it, or hit it with your fist. Do after the heated steering wheel is turned not press on the horn with a sharp- pointed object.
Page 117 Features of your vehicle MIRRORS D140100BHM D140102AHM-EE Inside rearview mirror Electric chromic mirror (ECM) (if equipped) Adjust the rearview mirror so that the The electric rearview mirror automatical- center view through the rear window is Night ly controls the glare from the headlights seen.
Page 118 Features of your vehicle To operate the compass: Type A ■ The vehicle compass displays the direc- tion the vehicle is heading. • Press the COMPASS button (2) to turn the compass function on. Press the COMPASS button to turn the compass function off.
Page 119 Features of your vehicle Calibration procedure If the zone number is different from your current location, set the correct zone The compass may not indicate the cor- number referring to "Setting the compass rect compass direction if the electronic zone" and perform the "Calibration pro- compass has not been calibrated cor- cedure"...
Page 120 Features of your vehicle 4. If the desired zone number is selected, release the button (2). After about 3 seconds, the "ZONE" will disappear and a compass direction will show in the display. 5. If the new compass zone is set, per- form the "Calibration procedure".
Page 121 Features of your vehicle Compass zone map OUN046101L...
Page 122 Features of your vehicle D140200AHM CAUTION Outside rearview mirror Do not scrape ice off the mirror Be sure to adjust the mirror angles face; this may damage the surface before driving. of the glass. If ice should restrict Your vehicle is equipped with both left- the movement of the mirror, do not hand and right-hand outside rearview force the mirror for adjustment.
Page 123 Features of your vehicle CAUTION • The mirrors stop moving when they reach the maximum adjust- ing angles, but the motor contin- ues to operate while the switch is pressed. Do not press the switch longer than necessary, the motor may be damaged.
Page 124 Features of your vehicle INSTRUMENT CLUSTER Gasoline Engine Type A ■ ■ 1. Tachometer 2. Turn signal indicators 3. Speedometer 4. Engine temperature gauge 5. Warning and indicator lights 6. Shift position indicator 7. Odometer 8. Trip computer* Type B ■...
Page 125 Features of your vehicle Diesel Engine Type A ■ ■ 1. Tachometer 2. Turn signal indicators 3. Speedometer 4. Engine temperature gauge 5. Warning and indicator lights 6. Shift position indicator 7. Odometer 8. Trip computer* Type B ■ ■ 9.
Page 126 Features of your vehicle Instrument cluster control Type A ■ WARNING Never adjust the instrument cluster while driving. This could result in loss of control and lead to an acci- dent that may cause death, serious injury, or property damage. OHM048045/OHM048045N Type B ■...
Page 127 Features of your vehicle When the door is opened, or if the engine ype A Type B Type A ype A ■ ■ ■ ■ is not started within 1 minute, the • Gasoline • Diesel tachometer pointer may move slightly in the ON position with the engine OFF.
Page 128 Features of your vehicle ype A ype B ype A ype B ■ ■ ■ ■ WARNING WARNING - Fuel gauge Never remove the radiator cap Running out of fuel can expose when the engine is hot. The engine vehicle occupants to danger. coolant is under pressure and You must stop and obtain addition- could cause severe burns.
Page 129 Features of your vehicle The odometer is always displayed until Type A ■ the display is turned off. Press the TRIP button for less than 1 second to select tripmeter, distance to empty, average speed, driving time, aver- age fuel consumption or instant fuel con- sumption function as follows: Type B ■...
Page 130 Features of your vehicle Type A Type A Type A ■ ■ ■ Type B Type B Type B ■ ■ ■ OHM048051 OHM048054L OHM048057L Tripmeter (km or mi.) Distance to empty (if equipped) Average speed (if equipped) (km or mi.) (km/h or MPH) TRIP A : Tripmeter A This mode indicates the estimated dis-...
Page 131 Features of your vehicle Type A Type A Type A ■ ■ ■ Type B Type B Type B ■ ■ ■ OHM048058L OHM048236L OHM048237L Elapsed time (if equipped) Average fuel consumption (if equipped) Instant fuel consumption (if equipped) (l/100 km or MPG) (l/100 km or MPG) This mode indicates the total time trav- eled since the last driving time reset.
Page 132 Any light that does not illuminate approximately 6 seconds each time you The trip computer may not register should be checked by an authorized Kia turn the ignition switch to the ON posi- additional fuel if less than 6 liters (1.6 dealer.
Page 133 If this occurs, have your vehicle checked If both ABS and brake warning Seat belt warning chime by an authorized Kia dealer as soon as lights are on and stay on, your vehi- If the driver's seat belt is not fastened possible.
Page 134 Light on indicator engine should be checked by an (if equipped) CAUTION authorized Kia dealer before the If the engine is not stopped imme- vehicle is driven again. The indicator illuminates when the tail diately after the engine oil pressure lights or headlights are ON.
Page 135 Kia dealer. Have the vehicle towed to any author- ized Kia dealer for a brake system inspection and necessary repairs.
Page 136 ON position to start the engine. charging system. Have an authorized ignition switch in any position. At this time, you can start the engine. The Kia dealer correct the problem as soon indicator goes out after the engine is run- as possible. ning.
Page 137 Refill the the ACC position without the smart key authorized Kia dealer and have the sys- washer fluid as soon as possible. in the vehicle, the indicator blinks for a tem checked.
Page 138 If you continue to drive with the some error related to the injection malfunction indicator light blinking Take your vehicle to an authorized Kia quantity adjustment occurs which for a long time, the DPF system can dealer and have the system checked.
Page 139 (-/SET or RES/+) is tem is on. cle checked by an authorized Kia dealer. pushed. When driving down a steep hill at a The cruise SET indicator does not illumi-...
Page 140 Kia dealer as soon driving, check the system by an as possible. authorized Kia dealer as soon as possible.
Page 141 If the smart key is not in the vehicle, onds. The 4WD LOW indicator illumi- authorized Kia dealer as soon as possi- the indicator will blink, and if all doors are nates when the transfer shift knob is set ble.
Page 142 Features of your vehicle D150400AHM Key is not detected Press brake pedal to start engine LCD display warning (if equipped) If the smart key is not in the vehicle or is If the ENGINE START/STOP button not detected and you press the ENGINE changes to the ACC position twice by Key is not in vehicle START/STOP button, the warning illumi-...
Page 143 ENGINE START/STOP button, nates on the LCD display, the warning If the steering wheel does not lock nor- take your vehicle to an authorized Kia “Insert key” illuminates for about 10 sec- mally when the ENGINE START/STOP dealer and have the system checked.
Page 144 Features of your vehicle REAR PARKING ASSIST SYSTEM (IF EQUIPPED) WARNING The rear parking assist system is a supplementary function only. The operation of the rear parking assist system can be affected by several factors (including environmental conditions). It is the responsibility of the driver to always check the area behind the vehicle before and while backing up.
Page 145 Features of your vehicle Operation of the rear parking D170200AEN The detecting range may decrease Non-operational conditions of when: assist system rear parking assist system 1. The sensor is stained with foreign mat- D170101AEN ter such as snow or water. (The sens- The rear parking assist system may Operating condition ing range will return to normal when...
Page 146 If this occurs, have your vehicle • The rear parking assist system may Always visually check behind the vehi- checked by an authorized Kia dealer as malfunction if the vehicle bumper cle when backing up. soon as possible.
Page 147 Features of your vehicle REARVIEW CAMERA (IF EQUIPPED) HAZARD WARNING FLASHER Type B The rearview camera may be turned off by pressing the ON/OFF button (1) when the rearview camera is activated. To turn the camera on again, press the ON/OFF button (1) again when the igni- tion switch is ON and the shift lever in R (Reverse) position.
Page 148 2) Turn the parking lights OFF and ON The light switch has a Headlight and a ized Kia dealer as soon as possible. again using the light switch on the Parking light position. steering column.
Page 149 Features of your vehicle OHM048065L OHM048066L OHM048067L D190401AHM D190402AHM D190403AHM Parking light position ( Headlight position ( Auto light position (if equipped) When the light switch is in the parking When the light switch is in the headlight When the light switch is in the AUTO light light position (1st position), the tail, position (2nd position), the head, tail, position, the taillights and headlights will...
Page 150 Features of your vehicle CAUTION • Never place anything over the sensor (1) located on the instru- ment panel. This will ensure bet- ter auto-light system control. • Don’t clean the sensor using a window cleaner. The cleaner may leave a light film which could interfere with sensor operation.
Page 151 Features of your vehicle To signal a lane change, move the turn signal lever slightly and hold it in position (B). The lever will return to the OFF posi- tion when released. If an indicator stays on and does not flash or if it flashes abnormally, one of the turn signal bulbs may be burned out and will require replacement.
Page 152 Features of your vehicle Daytime running light (if equipped) Daytime Running Lights (DRL) can make it easier for others to see the front of your vehicle during the day. DRL can be help- ful in many different driving conditions, and it is especially helpful after dawn and before sunset.
Page 153 Features of your vehicle Listed below are the examples of proper ✽ ✽ NOTICE switch settings. For loading conditions • Check the headlight washers periodi- other than those listed below, adjust the cally to confirm that the washer fluid switch position so that the beam level is being sprayed properly onto the may be the nearest as the condition headlight lenses.
Page 154 Features of your vehicle WIPERS AND WASHERS Front windshield wiper and washer Type A Type C ■ ■ A : Wiper speed control · (MIST) – Single wipe · OFF (0) – Off · INT (---) – Intermittent wipe --- / INT / AUTO* - Auto control wipe AUTO*...
Page 155 Type B ■ tion. In this case, have your vehicle release it with the lever in checked by an authorized Kia dealer the OFF position. The wipers will operate continu- as soon as possible. Rain sensor ously if the lever is pushed •...
Page 156 Features of your vehicle To vary the speed setting, turn the speed D200200BSA CAUTION control knob (1). Windshield washers When washing the vehicle, set the If the wiper switch is set in AUTO mode In the OFF (0) position, pull the lever wiper switch in the OFF (O) position when the ignition switch is ON, the wiper gently toward you to spray washer fluid...
Page 157 Features of your vehicle D200300AEN-EE Type A ■ Rear window wiper and washer WARNING switch (if equipped) Do not use the washer in freezing temperatures without first warming D : Rear wiper/washer control the windshield with the defrosters; the washer solution could freeze on ·...
Page 158 Features of your vehicle INTERIOR LIGHT D210000BEN CAUTION Do not use the interior lights for extended periods when the engine is not running. It may cause battery discharge. WARNING Do not use the interior lights when OHM048077 OHM048079 driving in the dark. Accidents could D210100AHM D210200AHM-EE happen because the view may be...
Page 159 Features of your vehicle If a door is opened with the ignition switch in the ACC or LOCK position, the light stays on for about 20 minutes. However, if a door is opened with the ignition switch in the ON position, the light stays on continuously.
Page 160 Features of your vehicle OHM049082 OHM048083 D210500AUN D210600AUN Glove box lamp (if equipped) Vanity mirror lamp (if equipped) The glove box lamp comes on when the Opening the lid of the vanity mirror will glove box is opened. automatically turn on the mirror light. The parking lights or headlights must be ON for the glove box lamp to function.
Page 161 Features of your vehicle DEFROSTER To activate the rear window defroster, Type A D220000AUN ■ press the rear window defroster button located in the center facia switch panel. CAUTION The indicator on the rear window To prevent damage to the conduc- defroster button illuminates when the tors bonded to the inside surface of defroster is ON.
Page 162 Features of your vehicle The front wiper deicer automatically Type A ■ turns off after 20 minutes or when the ignition switch is turned off. To turn off the deicer, press the front wiper deicer but- ton again. OHM040086N Type B ■...
Page 163 Features of your vehicle MANUAL CLIMATE CONTROL SYSTEM (IF EQUIPPED) Type A ■ ■ • Front climate control 1. Fan speed control switch 2. Air intake control button 3. Air conditioning button 4. Mode selection knob 5. Front wiper deicer button* 6.
Page 164 Features of your vehicle Type B ■ ■ 1. Fan speed control switch 2. Front blower ON/OFF button 3. Mode selection knob 4. Air conditioning button 5. Temperature control switch 6. Recirculated air position button 7. Outside (fresh) air position button 8.
Page 165 Features of your vehicle D230100AEN Heating and air conditioning 1. Start the engine. 2. Set the mode to the desired position. For improving the effectiveness of heating and cooling; - Heating: - Cooling: 3. Set the temperature control to the desired position.
Page 166 Features of your vehicle MAX A/C-Level (B, C, D, E, F) Floor-Level (C, A, D, E) Air flow is directed toward the upper body Most of the air flow is directed to the and face. floor, with a small amount of the air being In this mode, the air conditioning and the directed to the windshield and side win- recirculated air position will be selected...
Page 167 Features of your vehicle OHM048092 OHM048093L OHM048093 D230102AHM Type B, C : Pull up ( ▲ ) the switch for Instrument panel vents Temperature control warm and hot air (H), or push The outlet vents can be opened or closed down ( ▼...
Page 168 Features of your vehicle Outside temperature conversion Recirculated air position WARNING You can switch the temperature mode With the recirculated air between Centigrade to Fahrenheit as fol- position selected, air from • Continue using the climate con- lows: the passenger compart- trol system in the recirculated air ment will be drawn through While pressing the air intake control...
Page 169 Features of your vehicle Front ■ OHM040112L Rear ■ OHM048095 OHM048096N D230104AHM D230105AHM Fan speed control Air conditioning (if equipped) The ignition switch must be in the ON Press the A/C button to turn the air con- position for fan operation. ditioning system on (indicator light will illuminate).
Page 170 Features of your vehicle To turn on the rear climate control sys- • If you operate the rear temperature or mode on the rear climate control panel, the corresponding rear temperature or 1. Press the rear blower ON/OFF button mode will operate independently located on the front and rear climate regardless of the front climate control control panel (indicator light will illumi-...
Page 171 Features of your vehicle • : Rear air blows from the upper Ceiling ■ vents on the rear ceiling. • : Rear air blows from the upper vents on the rear ceiling and the lower vents. • : Rear air blows from the lower vents.
Page 172 Features of your vehicle System operation Front ■ D230501AUN Ventilation 1. Set the mode to the position. 2. Set the air intake control to the outside (fresh) air position. 3. Set the temperature control to the Rear ■ desired position. 4.
Page 173 • To keep dust or unpleasant fumes from entering the vehicle through the venti- 1. Set the mode to the position. Kia Air Conditioning Systems are filled lation system, temporarily set the air with environmentally friendly R-134a 2. Set the air intake control to the outside intake control to the recirculated air refrigerant.
Page 174 Features of your vehicle Air conditioning system operation tips • When using the air conditioning sys- ✽ ✽ NOTICE tem, you may notice clear water drip- • If the vehicle has been parked in direct • When using the air conditioning sys- ping (or even puddling) on the ground sunlight during hot weather, open the tem, monitor the temperature gauge...
Page 175 • When the air flow rate suddenly Therefore, if abnormal operation is Blower decreases, the system should be found, have the system inspected by an checked at an authorized Kia dealer. Climate control air filter Heater core authorized Kia dealer. Evaporator core OHM048209 ✽...
Page 176 Features of your vehicle AUTOMATIC CLIMATE CONTROL SYSTEM (IF EQUIPPED) Type A ■ ■ 1. A/C display 2. Front fan speed control switch • Front climate control 3. Driver's temperature control switch 4. AUTO (automatic control) button 5. Front blower OFF button 6.
Page 177 Features of your vehicle Type B ■ ■ 1. A/C display • Front climate control 2. Front fan speed control switch 3. Driver's temperature control switch 4. AUTO (automatic control) button 5. Front blower OFF button 6. Air conditioning button* 7.
Page 178 Features of your vehicle OHM040102 OHM048106 OHM048103 D240100BHM 2. Set the temperature switch to the ✽ ✽ NOTICE Automatic heating and air condi- desired temperature. Never place anything over the sensor tioning located on the instrument panel to 1. Press the AUTO button. ✽...
Page 179 Features of your vehicle D240200AHM Manual heating and air condition- Face-Level (B, C, D, E, F) Air flow is directed toward the upper body The heating and cooling system can be and face. Additionally, each outlet can be controlled manually by pressing buttons controlled to direct the air discharged other than the AUTO button.
Page 180 Features of your vehicle OHM040105 OHM048092 OHM048106 D240202AHM Defrost-Level (A, D) Instrument panel vents Temperature control Most of the air flow is directed to the The outlet vents can be opened or closed windshield with a small amount of air separately using the thumbwheel.
Page 181 Features of your vehicle Adjusting the driver and passenger side D240203AEN Air intake control temperature equally 1. Press the DUAL button again to deac- This is used to select the outside (fresh) tivate DUAL mode. The passenger air position or recirculated air position. side temperature will be set to the To change the air intake control position, same temperature as the driver side.
Page 182 Features of your vehicle Recirculated air position ✽ ✽ NOTICE WARNING With the recirculated air Prolonged operation of the heater in the position selected, air from • Continue using the climate control recirculated air position (without air the passenger compart- system in the recirculated air posi- conditioning selected) may cause fog- ment will be drawn through...
Page 183 Features of your vehicle OHM048109 OHM040110 OHM040111 D240205AHM D240206AUN D240208AHM-EE Fan speed control Air conditioning OFF mode The fan speed can be set to the desired Press the front blower OFF button to turn Press the A/C button to turn the air con- speed by operating the fan speed control off the front air climate control system.
Page 184 Features of your vehicle To turn on the rear climate control sys- • If you operate the rear temperature or Front ■ mode on the rear climate control panel, the corresponding rear temperature or 1. Press the rear blower ON/OFF button mode will operate independently located on the front and rear climate regardless of the front climate control...
Page 185 Features of your vehicle • : Rear air blows from the upper Ceiling ■ vents on the rear ceiling. • : Rear air blows from the upper vents on the rear ceiling and the lower vents. • : Rear air blows from the lower vents.
Page 186 Features of your vehicle Front ■ Rear ■ OHM048116 OHM048117 OHM048118 D240302AHM D240303AHM Rear vents Rear temperature control Rear fan speed control The vent can be adjusted by rotating the blade. To change the air temperature in the rear To change the fan speed, pull up ( ▲ ) the passenger compartment, pull up ( ▲...
Page 187 Features of your vehicle WINDSHIELD DEFROSTING AND DEFOGGING D250000AHM • For maximum defrosting, set the tem- perature control to the extreme right/hot position and the fan speed WARNING Windshield control to the highest speed. heating • If warm air to the floor is desired while Do not use the position defrosting or defogging, set the mode...
Page 188 Features of your vehicle OHM048120L OHM048121 OHM048122 D250102AHM Automatic climate control system D250202AHM To defrost outside windshield To defrost outside windshield D250201AHM 1. Set the fan speed to the highest posi- 1. Set the fan speed to the highest posi- To defog inside windshield tion.
Page 189 Features of your vehicle D250300AHM Defogging logic To reduce the possibility of fogging up the inside of the windshield, the air intake or air conditioning are controlled auto- matically according to certain conditions such as position. To cancel or return to the defogging logic, do the fol- lowing.
Page 190 Features of your vehicle STORAGE COMPARTMENT D270000AHM These compartments can be used to store small items. CAUTION • To avoid possible theft, do not leave valuables in the storage compartment. • Always keep the storage com- partment covers closed while driving.
Page 191 Features of your vehicle For improving the effectiveness of the cool box, do as follows; 1. Set the temperature to the hot (extreme right) position for warm air or to the cold (extreme left) position for cool air. Turn on the air conditioning system for cooler air.
Page 192 Features of your vehicle WARNING • Do not keep objects except sun- glasses inside the sunglass hold- er. Such objects can be thrown from the holder in the event of a sudden stop or an accident, pos- sibly injuring the passengers in the vehicle.
Page 193 “ready” position. If it is necessary to replace the cigarette lighter, use only a genuine Kia replace- To open the cover, press the cover and it ment or its approved equivalent. will slowly open. To clean the ashtray, the...
Page 194 Features of your vehicle D280300BHM Front Center ■ ■ Cup holder WARNING Hot liquids • Do not place uncovered cups of hot liquid in the cup holder while the vehicle is in motion. If the hot liquid spills, you may burn your- self.
Page 195 Features of your vehicle Front ■ CAUTION - Vanity mirror lamp (if equipped) Close the vanity mirror cover securely and return the sunvisor to its original position after use. If the vanity mirror is not closed securely, the lamp will stay on and could result in battery discharge and pos- sible sunvisor damage.
Page 196 Features of your vehicle The power outlet is designed to provide Type A ■ power for mobile telephones or other WARNING devices designed to operate with vehicle Do not put a finger or a foreign ele- electrical systems. The devices should ment (pin, etc.) into a power outlet draw less than 10 amps with the engine and do not touch with a wet hand.
Page 197 Features of your vehicle Minute (2) • The outside temperature on the display Type A ■ may not change immediately like a Press the M button to advance the time general thermometer to prevent the displayed by one minute. driver from being inattentive. Hold the M button to advance the hour reading more rapildy.
Page 198 Kia recom- WARNING Floor mat anchor(s) (if equipped) mends that only the Kia floor mat Do not hang other objects except designed for use in your vehicle be When using a floor mat on the front floor clothes.
Page 199 Use the cargo security screen to hide area, you can use the holders located in items stored in the cargo area. the cargo area to attach the luggage net. If necessary, contact your authorized Kia dealer to obtain a luggage net.
Page 200 Features of your vehicle When not in use, place the cargo securi- ty screen on the lower portion of the cargo area. WARNING • Do not place objects on the cargo security screen. Such objects may be thrown about inside the vehicle and possibly injure vehi- cle occupants during an accident or when braking.
Page 201 • When carrying large objects on starts, braking, sharp turns, be obtained from an authorized Kia dealer. the roof rack, make sure they do abrupt maneuvers or high speeds not exceed the overall roof length that may result in loss of vehicle or width.
Page 202 Features of your vehicle (Continued) • Always drive slowly and turn cor- ners carefully when carrying items on the roof rack. Severe wind updrafts, caused by passing vehicles or natural causes, can cause sudden upward pressure on items loaded on the roof rack. This is especially true when carry- ing large, flat items such as wood panels or mattresses.
Page 203 Features of your vehicle AUDIO SYSTEM ✽ ✽ NOTICE CAUTION • If you install an after market HID • Before entering a place with a low head lamp, your vehicle’s audio and height clearance or a car wash, electronic device may malfunction. remove the antenna by rotating it •...
Page 204 Features of your vehicle D300203AHM CDC mode SEEK/PRESET ( ) (2) It will function as the TRACK UP/DOWN button. The SEEK/PRESET button has different functions base on the system mode. For the following functions the button should D300202AHM be pressed for 0.8 seconds or more. MODE (3) Press the button to select Radio, CD RADIO mode...
Page 205 Features of your vehicle FM reception AM(MW, LW) reception OHM048151 JBM001 JBM002 D300600AHM-EE D300800AHM AM(MW, broadcasts Aux, USB and iPod port How vehicle audio works received at greater distances than FM broadcasts. This is because AM(MW, (if equipped) AM(MW, LW) and FM radio signals are LW) radio waves are transmitted at low broadcast from transmitter towers locat- If your vehicle has an aux and/or...
Page 206 Features of your vehicle FM radio station JBM003 JBM004 JBM005 FM broadcasts are transmitted at high • Fading - As your vehicle moves away • Station Swapping - As a FM signal frequencies and do not bend to follow the from the radio station, the signal will weakens, another more powerful sig- earth's surface.
Page 207 Features of your vehicle Using a cellular phone or a two-way Care of discs • Keep CDs in their cases after use to radio protect them from scratches or dirt. • If the temperature inside the vehicle is When a cellular phone is used inside the •...
Page 208 Features of your vehicle RADIO, SET UP, VOLUME CONTROL Type A ■ ■ • For countries not using Europe frequency 1. FM/AM Selection Button 2. Power ON/OFF Button and Volume Control Knob 3. Automatic Channel Selection Button 4. AST Play Button •...
Page 209 Features of your vehicle Type B ■ ■ • For countries not using Europe frequency 1. FM/AM Selection Button 2. Power ON/OFF Button and Volume Control Knob 3. Automatic Channel Selection Button 4. AST Play Button • For countries using Europe frequency 5.
Page 210 Features of your vehicle How to Activate RADIO, 3. Automatic Channel Selection 5. Preset Selection Button Button • Press [1]~[6] buttons less than 0.8 sec- SET UP, VOLUME Control ond to play the station saved in each • When the [TRACK ] is pressed, it button.
Page 211 Features of your vehicle 7. MUTE Selection Button (CDP ONLY) Sound Setup MODE ■ ■ (if equipped) For example: To adjust FADER Press and Rotate [AUDIO] repeatedly to ❈ choose the desired mode. Press [MUTE] to stop the sound and •...
Page 212 Features of your vehicle 1. CD Loading Slot 2. CD Eject Button 3. RANDOM Play Button 4. Automatic Track Selection Button 5. REPEAT Play Button 6. SCROLL Play Button (if equipped) 7. CD Indicator 8. CD Selection Button 9. SCAN Selection Button 10.
Page 213 Features of your vehicle CD CHANGER 1. CD Loading Slot 2. CD Eject Button 3. RANDOM Play Button 4. Automatic Track Selection Button 5. REPEAT Play Button 6. SCROLL Play Button (if equipped) 7. CD Indicator 8. CD Selection Button 9.
Page 214 Features of your vehicle How to Activate 3. RANDOM Play Button 5. REPEAT Play Button Press this button for less than 0.8 second Press this button for less than 0.8 second CDP/CD CHANGER to activate 'RDM' mode and more than to activate 'RPT' mode and more than 0.8 0.8 second to activate 'ALL RDM' mode.
Page 215 Features of your vehicle 10. Track(File) Search Knob and 13. DISC UP/DOWN Button • After the CD is inserted, the rest of the ENTER Button (CDC ONLY) empty CD slots' number blink. • Turn the knob clockwise to display the Disc is moved up or down from the cur- •...
Page 216 Features of your vehicle (Continued) (Continued) CAUTION - Using USB • Depending on the condition of • If you disconnect the external device the external USB device, the con- USB device during playback in • To use the external USB device, nected external USB device can USB mode, the external USB make sure the device is not con-...
Page 217 Features of your vehicle (Continued) (Continued) • If you use devices such as a USB • The data in the USB memory may hub you purchased separately, get lost while using this AUDIO. It the vehicle’s audio system may is recommended to back up impor- not recognize the USB device.
Page 218 Features of your vehicle ® USB MEMORY/AUX/iPod Type A ■ ■ 1. RANDOM Play Button 2. Automatic Track Selection Button 3. REPEAT Play Button 4. SCROLL Play Button (if equipped) 5. USB/AUX/iPod Selection Button 6. INFORMATION Button 7. File Search Knob and ENTER Button 8.
Page 219 Features of your vehicle Type B ■ ■ 1. RANDOM Play Button 2. Automatic Track Selection Button 3. REPEAT Play Button 4. SCROLL Play Button (if equipped) 5. USB/AUX/iPod Selection Button 6. INFORMATION Button 7. File Search Knob and ENTER Button 8.
Page 220 Features of your vehicle How to Activate USB MEMORY 3. REPEAT Play Button 6. INFORMATION Button Displays the information of the current Press this button for less than 0.8 second CD TRACK(FILE) as below when the to activate 'RPT' mode and more than 1.
Page 221 Features of your vehicle ® 4. SCROLL Play Button (if equipped) For example : Searching by Composers How to Activate iPod Device ❈ File names are scrolled for 5 seconds on • Press [FOLDER ] or turn [ENTER] the display. to activate the Menu Select mode.
Page 222 Features of your vehicle ✽ ✽ NOTICE ® iPod to AUDIO Buttons - Using iPod device ❈ (Continued) (It is displayed once at the beginning of • Some iPod models might not support • When connecting the device with iPod mode) the communication protocol and the iPod cable, push in the jack fully files will not be played.
Page 223 Features of your vehicle ® RADIO, SET UP, VOLUME CONTROL (with Bluetooth wireless technology) Type A ■ ■ • For countries not using Europe frequency 1. FM/AM Button 2. POWER Button & VOLUME Knob 3. SEEK Button 4. AST(AUTO STORE) Button 5.
Page 224 Features of your vehicle Type B ■ ■ • For countries not using Europe frequency 1. FM/AM Button 2. POWER Button & VOLUME Knob 3. SEEK Button 4. AST(AUTO STORE) Button 5. PRESET Buttons • For countries using Europe frequency 6.
Page 225 Features of your vehicle Using RADIO, SETUP, VOLUME and 4. AST(AUTO STORE) Button 6. TUNE Knob & ENTER Button AUDIO CONTROL • When AST is pressed, the frequency is If the knob is turned clockwise/counter- stored on the preset memory [1]~[6] clockwise, the frequency will increase/ 1.
Page 226 Features of your vehicle Sound Setup mode Rotate the knob clockwise by one notch speaker sound will be attenuated). ■ ■ to increase frequency from current fre- When the control knob is turned counter- • Push the AUDIO CONTROL(TUNE quency. Rotate the knob counterclock- clockwise, front speaker sound will be knob) button to enter SETUP mode.
Page 227 Features of your vehicle ® CD (CD Player : PA910HMGB) (with Bluetooth wireless technology) 1. CD Slot 2. CD Eject Button 3. RANDOM Button 4. TRACK Button 5. REPEAT Button 6. SCROLL Button 7. CD Indicator 8. CD Button 9. SCAN Button 10.
Page 228 Features of your vehicle ® (CD Changer : PA960HMGB) (with Bluetooth wireless technology) 1. CD Slot 2. CD Eject Button 3. RANDOM Button 4. TRACK Button 5. REPEAT Button 6. SCROLL Button 8. CD Button 9. SCAN Button 10. TUNE Knob & ENTER Button 11.
Page 229 Features of your vehicle Using CD Player 3. RANDOM Button 5. REPEAT Button Press this button for less than 0.8 second Press this button for less than 0.8 second to activate 'RDM' mode and more than to activate 'RPT' mode and more than 0.8 1.
Page 230 Features of your vehicle 10. TUNE Knob & ENTER Button 13. DISC Button(CD Changer :PA 960) • After the CD is inserted, the rest of the empty CD slots' number blink. • Turn the knob clockwise to display the Disc is moved up or down from the cur- •...
Page 231 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
Page 232 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • Please avoid using USB memory logical drives, only the music files products which can be used as on the highest-priority drive are key chains or cellular phone recognized by car audio.
Page 233 Features of your vehicle ® ® USB / AUX / iPod (CD Player : PA910HMGB) (with Bluetooth wireless technology) 1. RANDOM Button 2. TRACK Button 3. REPEAT Button 4. SCROLL Button 5. AUX/USB Button 6. INFO Button 7. TUNE Knob & ENTER Button 8.
Page 234 Features of your vehicle ® ® USB / AUX / iPod (CD Changer : PA960HMGB) (with Bluetooth wireless technology) 1. RANDOM Button 2. TRACK Button 3. REPEAT Button 4. SCROLL Button 5. AUX/USB Button 6. INFO Button 7. TUNE Knob & ENTER Button 8.
Page 235 Features of your vehicle Using USB device 3. REPEAT Button 6. INFO(INFORMATION) Button Displays the information of the current Press this button for less than 0.8 second CD TRACK(FILE) as below when the to activate 'RPT' mode and more than 1.
Page 236 Features of your vehicle 4. SCROLL Button Using ® For example : Searching by Composers iPod ❈ • Press [FOLDER ] or turn [ENTER] File names are scrolled for 5 seconds on to activate the Menu Select mode. the display. 1.
Page 237 ® DEVICE the system can be switched to • Some iPod models might not sup- • The Kia iPod Power Cable is AUX mode even without iPod port the communication protocol needed in order to operate iPod device and may cause noise.
Page 238 Features of your vehicle BLUETOOTH ® WIRELESS TECH- NOLOGY PHONE OPERATION General Features Phone Setup ■ ■ (IF EQUIPPED) ® ® • This audio system supports Bluetooth All Bluetooth -related operations can be hands-free and stereo-headset fea- performed in PHONE menu. tures.
Page 239 Features of your vehicle ✽ ✽ NOTICE • Pairing a phone • Changing Priority ® Before using Bluetooth features, the If several phones are paired with the If the phone is paired with two or more phone must be paired (registered) with audio system, the system attempts to vehicles of the same model, some phones the audio system.
Page 240 Features of your vehicle Talking on the Phone • Deleting Phone 3. When driving on a rough road. ■ The paired phone can be deleted. 4. When driving at high speeds. When talking on the phone, “Active Calls” 5. When the window is open. message and the other party’s phone 6.
Page 241 Features of your vehicle ✽ ✽ NOTICE (continued) CAUTION IN USING • Not only MP3 files, all the sounds that • Do not place the phone near or ® BLUETOOTH WIRELESS the phone supports can be heard by inside metallic objects, otherwise TECHNOLOGY CELLU- the audio system.
Page 242 Before driving / 5-3 Key positions / 5-4 ENGINE START/STOP button / 5-6 Starting the engine / 5-8 Automatic transmission / 5-12 Four wheel drive (4WD) / 5-18 Brake system / 5-28 Locking differential / 5-40 Air leveling system / 5-41 Cruise control system / 5-44 Economical operation / 5-48 Driving your vehicle...
Page 243 Kia dealer. • Do not run the engine in an enclosed area.
Page 244 Driving your vehicle BEFORE DRIVING E020100AUN E020300BHM Before entering vehicle Before starting WARNING - Driving under the influence of alcohol or • Be sure that all windows, outside mir- • Close and lock all doors. ror(s), and outside lights are clean. drugs •...
Page 245 Driving your vehicle KEY POSITIONS (IF EQUIPPED) WARNING • When you intend to park or stop the vehicle with the engine on, be careful not to depress the accel- erator pedal for a long period of time. It may overheat the engine or exhaust system and cause fire.
Page 246 Driving your vehicle E030202AHM E030204APB (Continued) ACC (Accessory) START • Never reach for the ignition switch, The steering wheel is unlocked and elec- Turn the ignition switch to the START or any other controls through the trical accessories are operative. position to start the engine.
Page 247 Try locking the without depressing the brake pedal steering wheel again. If the problem is by pressing the ENGINE START/STOP not solved, have it checked by an author- button with the shift lever in the N ized Kia dealer. (Neutral) position.
Page 248 Driving your vehicle E030202AHM E030704AHM ACC(Accessory) START/RUN WARNING • Never press ENGINE START/STOP button while the vehicle is in motion. This would result in loss of directional con- Orange indicator Not illuminated trol and braking function, which could cause an accident. Press the ENGINE START/STOP button To start the engine, depress the brake while it is in the OFF position without...
Page 249 Driving your vehicle STARTING THE ENGINE E040000BUN-EU 3. Turn the ignition switch to START and CAUTION hold it there until the engine starts (a maximum of 10 seconds), then • Do not engage the starter for WARNING release the key. more than 10 seconds.
Page 250 Driving your vehicle Starting and stopping the engine for tur- bocharger intercooler Glow indicator light 1. Do not race or accelerate the engine immediately after starting. If the engine is cold, idle for several seconds before sufficient lubrication is ensured in the turbocharger unit. 2.
Page 251 Driving your vehicle Diesel engine ✽ ✽ NOTICE • Even if the smart key is in the vehicle, if it is far away from you, the engine To start the diesel engine when the If the ENGINE START/STOP button is may not start.
Page 252 Driving your vehicle ✽ ✽ NOTICE (Continued) • When the stop lamp fuse is blown, you If the ENGINE START/STOP button is can't start the engine normally. pressed once more while the engine is Replace the fuse with a new one. If it pre-heating, the engine may start.
Page 253 Driving your vehicle AUTOMATIC TRANSMISSION E060100CHM Automatic transmission operation The automatic transmission has 5 (6 or 8) forward speeds and one reverse speed. The individual speeds are select- ed automatically, depending on the posi- tion of the shift lever. ✽ ✽ NOTICE The first few shifts on a new vehicle, if the battery has been disconnected, may be somewhat abrupt.
Page 254 Driving your vehicle For smooth operation, depress the brake E060101BHM CAUTION pedal when shifting from N (Neutral) to a Transmission ranges forward or reverse gear. • To avoid damage to your trans- The indicator in the instrument cluster mission, do not accelerate the displays the shift lever position when the engine in R (Reverse) or any for- ignition switch is in the ON position.
Page 255 Driving your vehicle N (Neutral) CAUTION The wheels and transmission are not The transmission may be damaged engaged. The vehicle will roll freely even if you shift into P (Park) while the on the slightest incline unless the parking vehicle is in motion. brake or service brakes are applied.
Page 256 4. Have your vehicle inspected by an is better for smooth driving on a slip- position to avoid inadvertent motion authorized Kia dealer immediately. pery road. Push the shift lever to the - of the vehicle which could injure (down) side to shift back to the 1st gear.
Page 257 Driving your vehicle Ignition key interlock system E060200AHM • Always use the parking brake. Do not (if equipped) Good driving practices depend on placing the transmission in P (Park) to keep the vehicle from moving. The ignition key cannot be removed •...
Page 258 Driving your vehicle E060203AHM WARNING WARNING Moving up a steep grade from a stand- ing start • Always buckle-up! In a collision, If your vehicle becomes stuck in To move up a steep grade from a stand- an unbelted occupant is signifi- snow, mud, sand, etc., then you ing start, depress the brake pedal, shift cantly more likely to be seriously...
Page 259 Driving your vehicle FOUR WHEEL DRIVE (4WD) (IF EQUIPPED) E170000AHM E170201AHM CAUTION Engine power can be delivered to all front Tight corner brake effect and rear wheels for maximum traction. • Do not select four wheel drive on 4WD is useful when extra traction is flat and normal roads.
Page 260 Driving your vehicle E170800AHM Part-Time 4WD (if equipped) Transfer mode Shift knob Indicator light Description 4 4 W W D D 4 4 W W D D H H I I L L O O W W This mode is used when driving on normal roads and highway. (Rear-wheel drive) (not illuminated) This mode is used when driving on slippery roads such as...
Page 261 Driving your vehicle ✽ ✽ NOTICE If the mode is not shifted like the previ- ous instructions, it will not transfer into the selected mode and the correspon- ding indicator light will continuously blink. CAUTION - • Always check the 4WD shift knob and cluster to see if the system has been activated unintentional- OHM058010N...
Page 262 Driving your vehicle E170900AHM Full-Time 4WD Operation (if equipped) Transfer mode Shift knob Indicator light Description 4 4 W W D D 4 4 W W D D This mode is used when driving on normal roads and highway. AUTO H H I I L L O O W W The engine power is distributed to all four wheels automatical-...
Page 263 Driving your vehicle ✽ ✽ NOTICE If the mode is not shifted like the previ- ous instructions, it will not transfer into the selected mode and the correspon- ding indicator light will continuously blink. CAUTION - • Always check the 4WD shift knob and cluster to see if the system has been activated unintentional- OHM058012N...
Page 264 Driving your vehicle E170300AHM For safe four-wheel drive opera- tion WARNING Four-wheel driving The conditions of on-road or off- road that demand four-wheel drive mean all functions of your vehicle are exposed to extreme stress than under normal road conditions. Slow down and be ready for changes in HILL1 HILL2...
Page 265 Driving your vehicle • You must consciously take the effort to learn how to corner in a 4WD vehicle. WARNING Wind danger Do not rely on your experience in con- If you are driving in heavy wind, the ventional 2WD vehicles in choosing vehicle's higher center of gravity safe cornering speed in 4WD mode.
Page 266 Driving your vehicle ✽ ✽ NOTICE E170800AHM CAUTION - Mud or snow Reducing the risk of a rollover • Do not drive in water if the level is If one of the front or rear wheels higher than the bottom of the vehicle. This multi-purpose passenger vehicle is begins to spin in mud, snow, etc.
Page 267 • Avoid sharp turns or abrupt not recommended by Kia for off maneuvers. road driving, you should not use • In a rollover crash, an unbelted these tires for highway driving.
Page 268 Driving your vehicle E170700AHM • Full-time 4WD vehicles must be tested WARNING - Dynamometer on a special four wheel chassis testing dynamometer. Keep away from the front of the Part-time 4WD vehicles must be tested vehicle while the vehicle is in gear on a 2WD roll tester with the transfer on the dynamometer.
Page 269 Driving your vehicle BRAKE SYSTEM E070100BUN E070101AUN (Continued) Power brakes In the event of brake failure • When descending a long or steep If service brakes fail to operate while the Your vehicle has power-assisted brakes hill, shift to a lower gear and vehicle is in motion, you can make an that adjust automatically through normal avoid continuous application of...
Page 270 Driving your vehicle E070102AHM CAUTION Disc brakes wear indicator • Driving with the parking brake When your brake pads are worn and new applied will cause excessive pads are required, you will hear a high- brake pad and brake rotor wear. pitched warning sound from your front brakes or rear brakes.
Page 271 If the brake warning light remains on after checked by an authorized Kia dealer. the parking brake is released while the engine is running, there may be a mal- function in the brake system. Immediate attention is necessary.
Page 272 Driving your vehicle E070300AHM-EE The ABS continuously senses the speed (Continued) Anti-lock brake system (ABS) of the wheels. If the wheels are going to • On roads where the road surface lock, the ABS system repeatedly modu- is pitted or has different surface lates the hydraulic brake pressure to the WARNING height.
Page 273 • Always slow down when cornering. lem with the ABS. Contact an The anti-lock brake system cannot pre- CAUTION authorized Kia dealer as soon as vent accidents resulting from exces- • If the ABS warning light is on and possible.
Page 274 Driving your vehicle The Electronic Stability Program (ESP) WARNING system is an electronic system designed to help the driver maintain vehicle control Never drive too fast according to under adverse conditions. It is not a the road conditions or too quickly substitute for safe driving practices.
Page 275 Driving your vehicle E070501AUN-EE When operating E070502AUN-EE ESP operation ESP operation off When the ESP is in operation, ESP indicator light blinks. ESP ON condition ESP OFF state • When the Electronic Stability • When the ignition is turned • To cancel ESP operation, Program is operating proper- ON, ESP and ESP OFF indi- press the ESP OFF button...
Page 276 Driving your vehicle ■ ESP indicator light (blinks / comes on) CAUTION WARNING Driving with varying tire or wheel The Electronic Stability Program sizes may cause the ESP system to system is only a driving aid; use malfunction. When replacing tires, precautions for safe driving by make sure they are the same size as slowing down on curved, snowy, or...
Page 277 Driving your vehicle E070504AEN-EE E070505AHM-EE ESP OFF usage WARNING Hill-start assist control (HAC) (if equipped) When driving Never press the ESP OFF button while ESP is operating. • The ESP turned on for daily driving A vehicle has the tendency to slip back whenever possible.
Page 278 Driving your vehicle Indicator light Mode Description Type A Type B Press the DBC button when the vehicle speed is under 40km/h (25mph). The DBC system will turn ON and enter the standby mode. Standby The system does not turn ON if the vehicle illuminated illuminated speed is over 40km/h (25mph).
Page 279 Kia dealer for assis- which can injure occupants or tance. pedestrians.
Page 280 Driving your vehicle • Don't coast down hills with the vehicle • If your vehicle is equipped with an • Under some conditions your parking out of gear. This is extremely haz- automatic transmission, don't let your brake can freeze in the engaged posi- ardous.
Page 281 Driving your vehicle LOCKING DIFFERENTIAL (IF EQUIPPED) E080000AHM The following procedures can be used to CAUTION A locking differential, if equipped, is for confirm that the locking differential is the rear wheel differential only. The fea- functioning properly: • Never start the engine with the tures of this locking differential are gearshift lever placed in the for- 1.
Page 282 Driving your vehicle AIR LEVELING SYSTEM (ALS) (IF EQUIPPED) OHM058026 OHM058027 OHM058025 E180000AHM E180100AHM E180200AHM The Air Leveling System improves driv- N (Normal) - Ordinary driving mode HI (High) - Off road driving mode ing stability and riding comfort with con- The normal height of the vehicle is main- The rear part of the vehicle is lifted to tinuous maintenance of vehicle height...
Page 283 Driving your vehicle ✽ ✽ NOTICE To go to the N (Normal) mode, press the bottom part of the switch. Also, if the The ALS will adjust the rear height of vehicle speed is over 60 km/h (38mph) or the vehicle according to the load and drives over 10 seconds at the speed of number of passengers when the ignition about 45 km/h (28mph), the vehicle will...
Page 284 (Continued) CAUTION • Have the vehicle checked by an • Always check if there is anything authorized Kia dealer if all the under the rear part of the vehicle lights of the ALS indicator is illu- before adjusting the ALS.
Page 285 Driving your vehicle CRUISE CONTROL SYSTEM (IF EQUIPPED) ✽ ✽ NOTICE WARNING • During normal cruise control opera- • If the cruise control is left on tion, when the SET switch is activated (CRUISE indicator light in the or reactivated after applying the instrument cluster illuminated), brakes, the cruise control will ener- cruise...
Page 286 Driving your vehicle OHM058043N OHM058046N OHM058044N E090100AHM 3. Push the -/SET switch, and release it at E090200BHM To set cruise control speed: the desired speed. The SET indicator To increase cruise control set light in the instrument cluster will illumi- speed: 1.
Page 287 Driving your vehicle E090400AUN To temporarily accelerate with the cruise control on: If you want to speed up temporarily when the cruise control is on, depress the accelerator pedal. Increased speed will not interfere with cruise control operation or change the set speed. To return to the set speed, take your foot off the accelerator.
Page 288 Driving your vehicle Each of these actions will cancel cruise E090700AHM control operation (the SET indicator light To turn cruise control off, do one in the instrument cluster will go off), but it of the following: will not turn the system off. If you wish to •...
Page 289 Driving your vehicle ECONOMICAL OPERATION E100000AHM • Don't "ride" the brake pedal. This can • Keep your vehicle in good condition. Your vehicle's fuel economy depends increase fuel consumption and also For better fuel economy and reduced mainly on your style of driving, where you increase wear on these components.
Page 290 Therefore, have an authorized Kia speed. loss of vehicle steering which dealer perform scheduled inspections could cause serious injury or and maintenance.
Page 291 Driving your vehicle SPECIAL DRIVING CONDITIONS • When braking with non-ABS brakes E110200BHM pump the brake pedal with a light up- Rocking the vehicle and-down motion until the vehicle is If it is necessary to rock the vehicle to free stopped.
Page 292 Driving your vehicle WARNING - Spinning tires Do not spin the wheels, especially at speeds more than 56 km/h (35 mph). Spinning the wheels at high speeds when the vehicle is station- ary could cause a tire to overheat which could result in tire damage that may injure bystanders.
Page 293 Driving your vehicle Driving off-road • Adjust your mirrors to reduce the glare E110500AUN from other driver's headlights. Driving in the rain Drive carefully off-road because your • Keep your headlights clean and prop- Rain and wet roads can make driving vehicle may be damaged by rocks or erly aimed on vehicles not equipped dangerous, especially if you’re not pre-...
Page 294 Driving your vehicle Fuel, engine coolant and engine oil WARNING High speed travel consumes more fuel than urban motoring. Do not forget to • Underinflated overinflated check both the engine coolant and tires can cause poor handling, engine oil. loss of vehicle control, and sud- den tire failure leading to acci- dents, injuries, and even death.
Page 295 Driving your vehicle WINTER DRIVING E120100AUN E120101AUN Snowy or icy conditions Snow tires If you mount snow tires on your vehicle, To drive your vehicle in deep snow, it may make sure they are radial tires of the be necessary to use snow tires or to same size and load range as the original install tire chains on your tires.
Page 296 Driving your vehicle When using tire chains, install them on Chain installation the rear tires only. When installing chains, follow the manu- facturer's instructions and mount them as tightly as you can. Drive slowly with CAUTION chains installed. If you hear the chains •...
Page 297 • Stop driving and retighten the 7. The level of charge in your battery can chains any time you hear them be checked by an authorized Kia dealer hitting the vehicle. or a service station.
Page 298 Window washer anti-freeze is Under some conditions, snow and ice available from an authorized Kia dealer can build up under the fenders and inter- and most auto parts outlets. Do not use fere with the steering. When driving in...
Page 299 Ask an are all within the limits. authorized Kia dealer for further details before towing. ✽ ✽ NOTICE - Your vehicle can tow a trailer. To identify...
Page 300 • The bumpers on your vehicle are not intended for hitches. Do not attach rental hitches or other bumper-type hitches. Use only a frame-mounted hitch that does not attach to the bumper. • Kia trailer hitch accessory is available at an authorized Kia dealer. 5 59...
Page 301 Driving your vehicle Trailer brakes Driving with a trailer Following distance Stay at least twice as far behind the vehi- If your trailer is equipped with a braking Towing a trailer requires a certain cle ahead as you would when driving system, make sure it conforms to your amount of experience.
Page 302 Do not connect a trailer lighting system directly to your vehicle’s lighting system. Use only an approved trailer wiring harness. An authorized Kia dealer can assist you in installing the wiring harness. 5 61...
Page 303 Driving your vehicle Parking on hills 5. Start the vehicle, hold the brakes, shift When you are ready to leave after park- to neutral, release the parking brake ing on a hill Generally, if you have a trailer attached to and slowly release the brakes until the 1.
Page 304 • When towing a trailer, be sure to con- your trip. with an air conditioner, you sult an authorized Kia dealer for further should install a condenser fan to Don’t forget to also maintain your trailer information on additional requirements...
Page 305 Driving your vehicle The trailer tongue should weigh a maxi- mum of 10% of the total loaded trailer weight, within the limits of the maximum trailer tongue load permissible. After you've loaded your trailer, weigh the trailer and then the tongue, separately, to see if the weights are proper.
Page 306 Driving your vehicle Trailer light connector (if equipped) A service connector is equipped in your vehicle for the towing brake controller as Your vehicle is equipped with a wire har- shown. Link the connector to the towing ness stored in the rear end underbody. brake controller with the sub wire har- Use it to connect and operate the trailer ness stored in the glove box.
Page 307 Driving your vehicle VEHICLE WEIGHT E160000AUN E160400AUN E160800AHM GAW (Gross axle weight) Overloading This section will guide you in the proper This is the total weight placed on each loading of your vehicle and/or trailer, to axle (front and rear) - including vehicle keep your loaded vehicle weight within its WARNING - Vehicle weight...
Page 308 Road warning / 6-2 In case of an emergency while driving / 6-2 If the engine will not start / 6-3 Emergency starting / 6-4 If the engine overheats / 6-6 If you have a flat tire / 6-7 Towing / 6-16 Emergency commodity / 6-20 What to do in an emergency...
Page 309 What to do in an emergency IN CASE OF AN EMERGENCY ROAD WARNING WHILE DRIVING It should be used whenever emergency repairs are being made or when the vehi- F020100AUN-EU cle is stopped near the edge of a road- If the engine stalls at a crossroad way.
Page 310 4. If the engine still does not start, call an a straight line. Move cautiously off the 4. Check the starter connections to be authorized Kia dealer or seek other road to a safe place. sure they are securely tightened.
Page 311 What to do in an emergency EMERGENCY STARTING F040100BHM Jumper Cables Jump starting WARNING - Battery • Keep all flames or sparks away Jump starting can be dangerous if done from the battery. The battery pro- incorrectly. Therefore, to avoid harm to duces hydrogen gas which may yourself or damage to your vehicle or explode if exposed to flame or...
Page 312 (for example, the engine not apparent, you should have your vehi- lifting bracket) away from the battery cle checked by an authorized Kia dealer. (4). Do not connect it to or near any part that moves when the engine is...
Page 313 If over- heating happens again, call an author- 2. Place the gear shift lever in P (Park) ized Kia dealer for assistance. and set the parking brake. If the air WARNING conditioning is on, turn it off.
Page 314 What to do in an emergency IF YOU HAVE A FLAT TIRE F070101CHM Jacking instructions WARNING - Changing tires The jack is provided for emergency • Never attempt vehicle repairs tire changing only. in the traffic lanes of a public road or highway.
Page 315 What to do in an emergency (Continued) • Be sure to use the correct front and rear jacking posi- tions on the vehicle; never use the bumpers or any other part of the vehicle for jacking support. • The vehicle can easily roll off jack causing serious...
Page 316 What to do in an emergency OHM068005 OHM068006 1VQA4022 4. After the spare tire reaches the To store the spare tire: F070300BHM Changing tires ground, continue to turn the 1. Lay the tire on the ground with the wrench counterclockwise, and 1.
Page 317 What to do in an emergency WARNING - Changing a tire • To prevent vehicle movement while changing a tire, always set the parking brake fully, and always block the wheel diagonally opposite the wheel being changed. • We recommend that wheels of the vehicle be blocked, and that no person...
Page 318 What to do in an emergency 9. Loosen the wheel nuts and remove them with your fingers. Slide the wheel off the studs and lay it flat so it cannot roll away. To put the wheel on the hub, pick up the spare tire, line up the holes with the studs and slide the wheel onto them.
Page 319 Then double-check each nut for tightness. After changing wheels, have an authorized Kia deal- er tighten the wheel nuts to their proper torque as soon as possible. Wheel nut tightening torque:...
Page 320 Adjust it to the for thread style before installing specified pressure, if necessary. aftermarket lug nuts or wheels. Refer to “Tires and wheels” in If in doubt, consult an author- section 8. ized Kia dealer. 6 13...
Page 321 What to do in an emergency F070301AHM When using a compact spare tire, Important - use of compact spare tire WARNING observe the following precautions: (if equipped) The compact spare tire is for • Under no circumstances should Your vehicle is equipped with a com- emergency use only.
Page 322 What to do in an emergency • Do not take this vehicle through an • The compact spare tire should not automatic car wash while the com- be used on any other wheels, nor pact spare tire is installed. should standard tires, snow tires, wheel covers or trim rings be used •...
Page 323 When being towed by a commercial tow equipment. ized Kia dealer or a commercial tow-truck truck and wheel dollies are not used, the • Do not tow the vehicle forward service. Proper lifting and towing proce-...
Page 324 • Avoid towing a vehicle heavier than the Kia dealer or a commercial tow truck vehicle doing the towing. service. • The drivers of both vehicles should...
Page 325 Attach a white or red cloth tinue the towing. Contact an • Before emergency towing, check that authorized Kia dealer or a com- (about 30 cm (12 inches) wide) in the the hook is not broken or damaged.
Page 326 What to do in an emergency F080301AHM CAUTION - Automatic Emergency towing precautions transmission • Turn the ignition switch to ACC so the steering wheel isn’t locked. • If the car is being towed with all four wheels on the ground, it can •...
Page 327 What to do in an emergency EMERGENCY COMMODITY (IF EQUIPPED) F110000AUN F110200AUN F110400AHM There are some emergency commodities First aid kit Tire pressure gauge in the vehicle to help you respond to the (If equipped) There are some items such as scissors, emergency situation.
Page 328 Engine compartment / 7-2 Maintenance services / 7-4 Owner maintenance / 7-6 Scheduled maintenance service / 7-8 Explanation of scheduled maintenance items / 7-15 Engine oil / 7-18 Engine coolant / 7-19 Brake fluid / 7-22 Power steering fluid / 7-23 Washer fluid / 7-24 Parking brake / 7-24 Fuel filter / 7-25...
Page 329: Engine Oil Filler Cap
Maintenance ENGINE COMPARTMENT Gasoline Engine (3.8L) ■ ■ 1. Engine coolant reservoir 2. Engine oil filler cap 3. Brake fluid reservoir 4. Air cleaner 5. Fuse box 6. Negative battery terminal 7. Positive battery terminal 8. Radiator cap Gasoline Engine (4.6L) ■...
Page 330 Maintenance Diesel Engine (3.0L) ■ ■ 1. Engine coolant reservoir 2. Engine oil filler cap 3. Fuel filter 4. Brake fluid reservoir 5. Air cleaner 6. Fuse box 7. Negative battery terminal 8. Positive battery terminal 9. Radiator cap 10. Engine oil dipstick 11.
Page 331 We recommend you have your vehicle maintained and repaired by an author- ized Kia dealer. An authorized Kia dealer meets Kia’s high service quality stan- dards and receives technical support from Kia in order to provide you with a high level of service satisfaction.
Page 332 Kia dealer. proper tools and equipment to do nerve system. the work, have it done by an •...
Page 333 Never work on the injection system When you stop for fuel: the owner or an authorized Kia dealer at with the engine running or within • Check the engine oil level. the frequencies indicated to help ensure 30 seconds after shutting off the •...
Page 334 Maintenance G030102AHM G030103AHM G030105AHM While operating your vehicle: At least monthly: At least once a year: • Note any changes in the sound of the • Check the coolant level in the engine • Clean the body and door drain holes. exhaust or any smell of exhaust fumes coolant reservoir.
Page 335 Maintenance SCHEDULED MAINTENANCE SERVICE If your vehicle is operated under the G040000AHM Follow the Normal Maintenance Schedule above conditions, you should inspect, if the vehicle is usually operated where replace or refill more frequently than the none of the following conditions apply. If following Normal Maintenance Schedule.
Page 336 : If good quality gasolines meet Europe Fuel standards (EN228) or equivalents including fuel additives is not available, one bottle of additive is recommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives.
Page 337 : For your convenience, it can be replaced prior to it's interval when you do maintenance of other items. : Inspect for excessive valve noise and/or engine vibration and adjust if necessary. An authorized Kia dealer should perform the operation.
Page 338 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) MAINTENANCE Number of months or driving distance, whichever comes first INTERVALS Months Miles×1,000 MAINTENANCE Km×1,000 ITEM At first, replace at 210,000 km (120,000 miles) or 120 months: For Europe after that, replace every 30,000 km (20,000 miles) or 24 months * Engine coolant * At first, replace every 200,000 km (120,000 miles) or 120 months: Except Europe...
Page 339 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) MAINTENANCE Number of months or driving distance, whichever comes first INTERVALS Months Miles×1,000 MAINTENANCE Km×1,000 ITEM Steering gear rack, linkage and boots Driveshaft and boots Tire (pressure & tread wear) Front suspension ball joints Bolt and nuts on chassis and body Air conditioner refrigerant (if equipped) Air conditioner compressor (if equipped) Climate control air filter (if equipped)
Page 340 Maintenance G040200DHM-EE MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Maintenance intervals MAINTENANCE ITEM...
Page 341 Maintenance Maintenance MAINTENANCE ITEM Maintenance intervals Driving condition operation Inspect more frequently Disc brakes and pads, calipers and rotors C, D, E, G, H depending on the condition Inspect more frequently Parking brake C, D, G, H depending on the condition Inspect more frequently Driveshaft and boots C, D, E, F, H...
Page 342 Have being driven in severe conditions, more issues such as hard starting. If an exces- an authorized Kia dealer replace any frequent oil and filter changes are sive amount of foreign matter accumu- damaged or leaking parts immediately.
Page 343 Vapor hose and fuel filler cap Air cleaner filter Coolant The vapor hose and fuel filler cap should A Genuine Kia air cleaner filter is recom- The coolant should be changed at the be inspected at those intervals specified mended when the filter is replaced.
Page 344 8.) to refer to the Kia web site. excessive wear, oiliness and proper ten- sion. Replace or adjust it if necessary. (http://brakemanual.kia.co.kr)
Page 345 Maintenance ENGINE OIL 5. Pull the dipstick out again and check the level. The level should be between F and L. CAUTION • Do not overfill the engine oil. It may damage the engine. • Do not spill engine oil, when adding or changing engine oil.
Page 346 Checking the coolant level reservoir filled with year round antifreeze Have engine oil and filter changed by an coolant. The reservoir is filled at the fac- authorized Kia dealer according to the WARNING tory. Maintenance Schedule at the beginning Removing radiator Check the antifreeze protection and of this section.
Page 347 Bring the coolant temperature decreases, the level to F, but do not overfill. If frequent electric motor will automatically additions are required, see an authorized shut off. This is a normal condition. Kia dealer for a cooling system inspection.
Page 348: Radiator Cap
Maintenance For mixture percentage, refer to the fol- G070200AHM lowing table. Changing the coolant Have the coolant changed by an author- ized Kia dealer according to the Mixture Percentage (volume) Maintenance Schedule at the beginning Ambient of this section. Temperature...
Page 349 Before removing the reservoir cap and an authorized Kia dealer. guaranteed. It should be properly adding brake fluid, clean the area around disposed. Don't put in the wrong the reservoir cap thoroughly to prevent kind of fluid.
Page 350: Power Steering Fluid Reservoir
Check the connections for oil leaks, dam- vehicle should be inspected by an age and twists in the power steering authorized Kia dealer. hose before driving. CAUTION OHM078006N • To avoid damage to the power...
Page 351 Serious less than specified, have the parking available. However, use washer solvent injury or death could occur. brake adjusted by an authorized Kia with antifreeze characteristics in cold cli- dealer. mates to prevent freezing. Stroke : 4~5 notch...
Page 352 G150200AUN damages to the major parts such as Fuel filter cartridge replacement the fuel system can be caused by ✽ ✽ NOTICE water permeation in the fuel filter. When replacing the fuel filter cartridge, use Kia genuine parts. 7 25...
Page 353 Maintenance AIR CLEANER OHM078011N OHM078009N OHM078010N G160100AAM 1. Loosen the air cleaner cover attaching Filter replacement clips and open the cover. It must be replaced when necessary, and should not be washed. You can clean the filter when inspecting the air cleaner element. Clean the filter by using compressed air.
Page 354 1. Open the glove box and remove the does not enter the air intake, or support rod (1). damage may result. • Use a Kia genuine part. Use of non-genuine parts could damage the air flow sensor or turbocharg- 7 27...
Page 355 Maintenance OHM079015 OHM078016 OHM078017 2. With the glove box open, remove the 3. Remove the climate control air filter 4. Replace the climate control air filter. stoppers on both sides to allow the case by pulling out both sides of the 5.
Page 356 Maintenance WIPER BLADES Contamination of either the windshield or G180200AUN the wiper blades with foreign matter can Blade replacement reduce the effectiveness of the wind- When the wipers no longer clean ade- shield wipers. Common sources of con- quately, the blades may be worn or tamination are insects, tree sap, and hot cracked, and require replacement.
Page 357 Maintenance OHM078059 OHM078060 OHM078061 G180201AHM 2. Lift up the wiper blade clip. Then pull 3. Install the new blade assembly in the Front windshield wiper blade down the blade assembly and remove reverse order of removal. 1. Raise the wiper arm. CAUTION Do not allow the wiper arm to fall against the windshield, since it may...
Page 358 1. Raise the wiper arm and pull out the wiper blade assembly. 3. Make sure the blade assembly is installed firmly by trying to pull it slight- To prevent damage to the wiper arms or other components, have an authorized Kia dealer replace the wiper blade. 7 31...
Page 359 Keep batteries out of the en the cell caps. We recommend that you • Keep the battery securely mounted. reach of children because contact an authorized Kia dealer. • Keep the battery top clean and dry. batteries contain highly corrosive SULFURIC ACID.
Page 360 Battery capacity label use unauthorized devices. health. Dispose the battery (see the example) according to your local 1. CMF60L-BCI : The Kia model name of law(s) or regulation. battery • When lifting a plastic-cased bat- 2. 12V : The nominal voltage tery, excessive pressure on the 3.
Page 361 Maintenance G190200AUN G190300AHM (Continued) Battery recharging Reset items • Watch the battery during charg- Your vehicle has a maintenance-free, Items should be reset after the battery ing, and stop or reduce the charg- calcium-based battery. has been discharged or the battery has ing rate if the battery cells begin been disconnected.
Page 362 If a recommended for your vehicle. tire frequently needs refilling, have it checked by an author- G200200AUN ized Kia dealer. Recommended cold tire inflation • Overinflation produces OHM088005N pressures...
Page 363 Maintenance G200300AUN CAUTION CAUTION - Tire pressure Checking tire inflation pressure • Warm tires normally exceed Always observe the following: Check your tires once a month or recommended cold tire pres- • Check tire pressure when the more. Also, check the tire pressure of sures by 28 to 41 kPa (4 to 6 tires are cold.
Page 364 • Remember to check the pres- Refer to “Tire and wheels” in section sure of your spare tire. Kia recommends that you check the spare every time you check the pressure of the other tires on your vehicle.
Page 365 Maintenance ✽ ✽ NOTICE G200500AUN Without a spare tire Wheel alignment and tire balance Rotate radial tires that have an asymmetric tread pattern only from The wheels on your vehicle were front to rear and not from right to aligned and balanced carefully at the left.
Page 366 WARNING - Replacing Tire replacement tires • Wheels that do not meet Kia’s If the tire is worn evenly, a tread wear specifications may fit poorly To reduce the chance of serious indicator will appear as a solid band...
Page 367 Maintenance G200601AUN G200700AUN G200800AHM Compact spare tire replacement Tire traction Wheel replacement (if equipped) Tire traction can be reduced if you When replacing the metal wheels for A compact spare tire has a shorter drive on worn tires, tires that are any reason, make sure the new tread life than a regular size tire.
Page 368 Maintenance G201002AHM T - Speed Rating Symbol. See the 2. Tire size designation speed rating chart in this section A tire’s sidewall is marked with a tire for additional information. size designation. You will need this information when selecting replace- Wheel size designation ment tires for your vehicle.
Page 369 Maintenance DOT : XXXX XXXX OOOO G1201004AEN Speed 4. Tire ply composition and material The front part of the DOT means a Rating Maximum Speed The number of layers or plies of rub- plant code number, tire size and Symbol ber-coated fabric in the tire.
Page 370 Maintenance G201006AUN Tread wear Traction - AA, A, B & C 6. Maximum load rating The traction grades, from highest to The tread wear grade is a compara- This number indicates the maximum lowest, are AA, A, B and C. Those tive rating based on the wear rate of load in kilograms and pounds that grades represent the tire’s ability to...
Page 371 50, are provided tire condition or contact an heat and its ability to dissipate heat for sporty looks. authorized Kia dealer. when tested under controlled condi- Because the low aspect ratio tires - To prevent damage to the tire,...
Page 372 Avoid using CAUTION the system involved and immediately Do not use a screwdriver or any consult an authorized Kia dealer. other metal object to remove fuses Three kinds of fuses are used: blade type because it may cause a short circuit for lower amperage rating, cartridge type, and damage the system.
Page 373 5. Push in a new fuse of the same rating, G210100AHM and make sure it fits tightly in the clips. Inner panel fuse replacement If it fits loosely, consult an authorized Kia 1. Turn the ignition switch and all other dealer. switches off.
Page 374 Maintenance ✽ ✽ NOTICE If the headlights or other electrical com- ponents do not work and the fuses are • If the memory fuse is pulled out from OK, check the fuse panel in the engine the fuse panel, the warning chime, compartment.
Page 375 Engine compartment fuse replacement ✽ ✽ NOTICE 1. Turn the ignition switch and all other If the main fuse is blown, consult an switches off. authorized Kia dealer. 2. Remove the fuse panel cover by pressing the tab and pulling the cover...
Page 376 Maintenance G210300BHM Fuse/relay panel description Inside the fuse/relay panel covers, you can find the fuse/relay label describing fuse/relay name and capacity. Inner fuse panel Engine compartment fuse panel ✽ ✽ NOTICE Not all fuse panel descriptions in this manual may be applicable to your vehi- cle.
Page 377 Maintenance Inner fuse panel (Instrument panel) Description Fuse rating Protected component AUDIO Audio, Rear Monitor MEMORY 7.5A Front A/C Control Module, Rear A/C Control Module, Instrument Cluster(IND.), RF Receiver, FAM, RAM, Driver Door Module, Assistant Door Module, Tilt & Telescopic Module, IMS Control Module S/TILT &...
Page 378 Maintenance Description Fuse rating Protected component FRT CIGAR Cigarette Lighter START 7.5A Burglar Alarm Relay, Start Relay AIR BAG IND. 7.5A Instrument Cluster(Air Bag IND.) 7.5A ABS Control Module, ESP Control Module, DBC Relay, Steering Angle Sensor, Crash Pad Switch LH IGN 1 7.5A PDM, Rheostat, Instrument Cluster(MICOM), Smart Key Control Module,...
Page 379 Maintenance Inner fuse panel (Luggage compartment) FUSE Fuse rating Circuit Protected RR DEFOG RR Defog Relay, Rear Defogger (+) T/G POWER LATCH Tail Gate Control Module RR WIPER Rear Wiper Motor Relay (+), Rear Wiper Motor DOOR LOCK Rear Door Lock Actuator LH/RH, Rear Door Lock/Unlock Relay CTR P/OUT Console Power Outlet RR P/OUT...
Page 380 Maintenance Engine compartment main fuse panel Description Fuse rating Protected component FRT/RR WASHER Front/Rear Washer Motor Relay, Washer Motor STOP LAMP Stop Lamp Switch, DBC Relay KEY SW 1 Ignition Switch, PDM Relay Box(IG1 Relay , ACC Relay ) STOP SIGNAL 7.5A ABS Control Module, ESP Control Module, ECM, Smart Key Control Module A/C COMP...
Page 381 Maintenance Description Fuse rating Protected component ABS 2 ABS Control Module, ESP Control Module ABS 1 ABS Control Module, ESP Control Module FRT WIPER Front Wiper ON Relay, Front Wiper HI/LO Relay KEY SW 2 Start Relay #1, Ignition Switch, PDM Relay Box(IG2 Relay) RAM 1 RAM(CTR P/OUT FUSE 15A, RR P/OUT FUSE 15A, FUEL DR FUSE 15A, RR P/WIN-LH FUSE 20A, RR P/WIN-RH FUSE 20A, LUGGAGE FUSE 7.5A)
Page 382 WARNING - Working on the correct bulbs and the expertise, the lights consult an authorized Kia dealer. In Prior to working on the light, firmly many cases, it is difficult to replace apply the parking brake, ensure vehicle light bulbs because other...
Page 383 Maintenance (Continued) • If a bulb becomes damaged or cracked, replace it immediately and carefully dispose of it. • Wear eye protection when chang- ing a bulb. Allow the bulb to cool down before handling it. OHD076046 OEN076051 G220101BUN 1. Open the hood. Headlight bulb 2.
Page 384 HID lamps do not fail in the same If the light bulb does not operate, have manner as halogen incandescent lamps. the vehicle checked by an authorized Kia If a headlamp goes out after a period of OHM078032 dealer.
Page 385 Maintenance Type A ■ OHM078033 OHM078046N OHM078044N Type B ■ OHM078065 OHM078045N OHM078047N Outside light G220300AHM-EE 4. Remove the socket from the assembly Rear combination light bulb by turning the socket counterclockwise Type A until the tabs on the socket align with replacement 1.
Page 386 OHM078049 If the light bulb does not operate, have Inside light 5. Insert a new bulb by inserting it into the vehicle checked by an authorized Kia the socket and rotating it until it locks 1. Open the tailgate. dealer.
Page 387 1. Loosen the lens retaining screws with If the light does not operate, have the a philips head screwdriver. vehicle checked by an authorized Kia dealer. 2. Remove the lens. 3. Remove the bulb by pulling it straight out.
Page 388 Maintenance Map lamp Luggage lamp G220600AHM Interior light bulb replacement 1. Using a flat-blade screwdriver, gently pry the lens from the interior light housing. 2. Remove the bulb by pulling it straight out. WARNING Prior to working on the Interior Lights, ensure that the “OFF”...
Page 389 Maintenance APPEARANCE CARE Exterior care After washing, rinse the vehicle thor- oughly with lukewarm or cold water. Do G230101AUN not allow soap to dry on the finish. Exterior general caution It is very important to follow the label CAUTION directions when using any chemical cleaner or polish.
Page 390 Maintenance Waxing G230103AUN G230104AUN Finish damage repair Bright-metal maintenance Wax the vehicle when water will no longer bead on the paint. Deep scratches or stone chips in the • To remove road tar and insects, use a painted surface must be repaired tar remover, not a scraper or other Always wash and dry the vehicle before promptly.
Page 391 Maintenance G230105APB G230106BUN Underbody maintenance WARNING Aluminum or chrome wheel mainte- nance Corrosive materials used for ice and After washing the vehicle, test the snow removal and dust control may col- The aluminum or chrome wheels are brakes while driving slowly to see if lect on the underbody.
Page 392 Maintenance G230107AHM High-corrosion areas Moisture breeds corrosion Corrosion protection If you live in an area where your vehicle Moisture creates the conditions in which is regularly exposed to corrosive materi- corrosion is most likely to occur. For Protecting your vehicle from corrosion als, corrosion protection is particularly example, corrosion is accelerated by By using the most advanced design and...
Page 393 Maintenance Keep your vehicle clean Keep your garage dry Don't neglect the interior The best way to prevent corrosion is to Don't park your vehicle in a damp, poorly Moisture can collect under the floor mats keep your vehicle clean and free of corro- ventilated garage.
Page 394 Maintenance Interior care G230202AUN G230203AUN Cleaning the upholstery and interior Cleaning the lap/shoulder belt web- G230201CHM trim bing Interior general precautions Clean the belt webbing with any mild Vinyl Prevent chemicals such as perfume, cos- soap solution recommended for cleaning Remove dust and loose dirt from vinyl metic oil, sun cream, hand cleaner and upholstery or carpet.
Page 395 System is designed to prevent fuel ommended that you have your vehicle vapors from escaping into the atmos- inspected and maintained by an author- phere. ized Kia dealer in accordance with the maintenance schedule in this manual.
Page 396 Maintenance G270201AUN G270300AUN G270302AUN Canister 3. Exhaust emission control Engine exhaust gas precautions (carbon monoxide) system Fuel vapors generated inside the fuel tank are absorbed and stored in the • Carbon monoxide can be present with The Exhaust Emission Control System is onboard canister.
Page 397 All inspections and adjustments not seal the bottom of the vehicle must be made by an authorized Kia or do not coat the vehicle for cor- dealer. rosion control. It may present a •...
Page 398 If the malfunction indicator light contin- ues to be blinked in spite of the proce- The Diesel Particulate Filter (DPF) sys- dure, please visit an authorized Kia deal- tem removes the soot emitted from the er and then check the DPF system.
Page 399 Dimensions / 8-2 Bulb wattage / 8-2 Tires and wheels / 8-3 Recommended lubricants and capacities / 8-4 Vehicle identification number (VIN) / 8-7 Vehicle certification label / 8-7 Tire specification and pressure label / 8-8 Engine number / 8-8 Air conditioner compressor label / 8-9 Declaration of conformity / 8-9 Specifications &...
Page 400 Specifications & Consumer information BULB WATTAGE DIMENSIONS I010000BHM-EE I030000AHM-EE Item mm (in) Light Bulb Wattage Headlights (Low) 55 or 35 (HID) Overall length 4880 (192.1) Headlights (High) Overall width 1915 (75.4) Front turn signal lights Overall height 1765 (69.5) / 1810 (71.3)* Position lights Front tread 1630 (64.2)*...
Page 401 Specifications & Consumer information TIRES AND WHEELS I020000AHM Inflation pressure Tire Wheel lug nut torque bar (psi, kPa) Wheel size Item size Maximum load kg•m (lb•ft, N•m) Normal load Front Rear Front Rear 245/70R17 7.0J×17 Full size tire 265/60R18 7.5J×18 (32, 220) (32, 220) (32, 220) (32, 220) 9~11 (65~79, 88~107)
Page 402 Specifications & Consumer information RECOMMENDED LUBRICANTS AND CAPACITIES I040000GHM-EE To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy. These lubricants and fluids are recommended for use in your vehicle.
Page 403 Specifications & Consumer information Lubricant Volume Classification Brake fluid 0.7~0.8 l (0.7~0.8 US qt.) FMVSS116 DOT-3 or DOT-4 Front 1.3~1.4 l (1.4~1.5 US qt.) HYPOID GEAR OIL Differential oil SAE 90, API GL-5 Rear 1.7~1.9 l (1.9~2.0 US qt.) Part-time ATF DEXRON III or equivalent Transfer case oil (4WD) 1.5~1.7 l (1.6~1.8 US qt.)
Page 404 Specifications & Consumer information I040100DUN Engine oil viscosity (thickness) has an When choosing an oil, consider the range Recommended SAE viscosity effect on fuel economy and cold weather of temperature your vehicle will be oper- operating (engine start and engine oil number ated in before the next oil change.
Page 405 Specifications & Consumer information VEHICLE CERTIFICATION VEHICLE IDENTIFICATION LABEL NUMBER (VIN) Frame number VIN label (if equipped) OHM088004 OHM088008N OHM088002N Frame number (if equipped) The VIN is also on a plate attached to H020000AUN the top of the dashboard. The number The vehicle certification label attached on the plate can easily be seen through on the driver’s (or front passenger’s) side...
Page 406 Specifications & Consumer information TIRE SPECIFICATION AND ENGINE NUMBER PRESSURE LABEL Gasoline engine (3.8L) Diesel engine (3.0L) ■ ■ OHM088006N OHM088005N OHM088003 Gasoline engine (4.6L) ■ H04000AUN H030000APB The engine number is stamped on the The tires supplied on your new vehicle engine block as shown in the drawing.
Page 407 Directive ber, production number, refrigerant (1) 1995/5/EC. and refrigerant oil (2). Further information including the manu- facturer's declaration of conformity is available on Kia web site as follows; http://www.kia-hotline.com...
Page 408 Index...
Page 409 Index Automatic transmission ··················································5-12 Shift lock system ·······················································5-15 Sports mode·······························································5-14 Air bags···········································································3-42 Air bag warning label..........3-60 Air bag warning light ..........3-45 Curtain air bag ............3-52 Battery·············································································7-32 Driver's and passenger's front air bag ......3-48 Battery saver function ·····················································4-71 Side impact air bag............3-50 Before driving ···································································5-3 Air cleaner·······································································7-26 Bottle holders, see cup holders ·····································4-117...
Page 410 Index Side repeater light bulb replacement·························7-57 Climate control system (Manual) ··································4-86 Turn signal light bulb replacement ···························7-55 Air conditioning ·······················································4-92 Bulb wattage ·····································································8-2 Heating and air conditioning·····································4-88 Button start/stop, see engine start/stop button ··················5-6 Cigarette lighter ····························································4-116 Climate control air filter ········································4-98, 7-27 Clock (Digital) ·····························································4-119 Clothes hanger ······························································4-121 Capacities (Lubricants) ·····················································8-4...
Page 411 Index Defroster (Rear window) ···············································4-84 Emergency towing ·························································6-17 Defrosting (Windshield) ··············································4-110 Emergency while driving ·················································6-2 Digital clock ·································································4-119 Emergency commodity ··················································6-20 Dimensions ······································································8-2 Emission control system ················································7-68 Displays, see instrument cluster ····································4-47 Crankcase emission control system ·························7-68 Display illumination, see instrument panel illumination ···4-49 Evaporative emission control system ·······················7-68 Door courtesy lamp bulb replacement····························7-60 Exhaust emission control system ·····························7-69...
Page 412 Index Jack and tools ·····························································6-7 Removing and storing the spare tire ··························6-8 Floor mat anchor(s) ·····················································4-121 Hazard warning flasher ··················································4-70 Fluid Hazardous driving conditions ········································5-50 Washer fluid ·····························································7-24 Headlight bulb replacement ·································7-55, 7-57 Brakes fluid ······························································7-22 Headlight leveling device ··············································4-75 Power steering fluid ··················································7-23 Headlight washer ····························································4-76 Folding the rear seat ······················································3-17...
Page 413 Index Speedometer ·····························································4-49 Tachometer ·······························································4-50 Trip computer ···························································4-52 Key positions ···································································5-4 Warning and indicators ············································4-55 Keys ·················································································4-3 Instrument panel illumination ········································4-49 Instrument panel overview ···············································2-3 Interior care ····································································7-67 Interior features ····························································4-116 Label Ashtray ···································································4-116 Air bag warning label ···············································3-60 Aux, USB and iPod ················································4-128 Air conditioner compressor label································8-9 Cargo security screen ··············································4-122 Tire sidewall labeling ···············································7-41...
Page 414 Index Lighting ··········································································4-71 Mirrors ···········································································4-40 Battery saver function ··············································4-71 Day/night rearview mirror ·······································4-40 Rescue mode function ···············································4-71 Electric chromic mirror (ECM) ·······························4-40 Locking differential ························································5-40 Electric chromic mirror (ECM) with compass ········4-41 Lubricants and capacities ·················································8-4 Inside rearview mirror ··············································4-40 Luggage box ·································································4-115 Outside rearview mirror ···········································4-45 Luggage net (holder) ····················································4-122...
Page 415 Index Road warning ···································································6-2 Rocking the vehicle ·······················································5-50 Roof rack ·····································································4-124 Panorama sunroof ··························································4-29 Parking brake inspect ·····················································7-24 Parking brake ·································································5-29 Passenger's front air bag ················································3-48 Scheduled maintenance service ·······································7-8 Position light bulb replacement ····························7-55, 7-57 Normal maintenance schedule ····································7-9 Power adjustable pedals··················································4-36 Maintenance under severe usage conditions·············7-13 Power brakes ··································································5-28...
Page 416 Index Side impact air bag ························································3-50 Storage compartment ···················································4-113 Side repeater light bulb replacement ·····························7-57 Center console storage ···········································4-113 Side step········································································4-125 Cool box ··································································4-113 Smart key ·········································································4-6 Glove box ·······························································4-114 Smooth cornering ···························································5-51 Luggage box····························································4-115 Snow tires ······································································5-54 Multi box·································································4-115 Spare tire Sunglass holder ······················································4-114 Compact spare tire ···················································6-14...
Page 417 Index Tire sidewall labeling ···············································7-41 Tire traction ······························································7-40 Wheel alignment and tire balance ····························7-38 Washer fluid ···································································7-24 Wheel replacement ···················································7-40 Waste tray, see ashtray ·················································4-116 Towing ···········································································6-16 Warnings and indicators ················································4-55 Emergency towing ····················································6-17 Weight ············································································5-66 Tie-down hook (for flatbed towing) ·························6-19 Base curb weight ······················································5-66 Trailer towing ····························································5-58 Cargo weight ····························································5-66...

Kia MOHAVE 2014 Owner's Manual

Quick Links

Related Manuals for Kia MOHAVE 2014

Summary of Contents for Kia MOHAVE 2014

Page 16: Table Of Contents

Page 329: Engine Oil Filler Cap

Page 348: Radiator Cap

Page 350: Power Steering Fluid Reservoir
