- Page 1 QUICK START GUIDE BODY Update Version 2.0 May 2020 PIRED PIRED UNTOLD UNTOLD SHARE YOUR STORY. SAIL WITH US MAX QUICK START GUIDE...
- Page 2 CONGRATULATIONS WHAT’S IN THE BOX? ON YOUR NEW SAILMON MAX! MAX IS MADE FOR INDUCTIVE CHARGER AND CABLE SAILING SO WE WANT STANDARD MAX MOUNT YOU TO GET ON THE CARRYING CASE WATER ASAP! QUICK START GUIDE IF YOU WANT TO LEARN MORE PLEASE GO TO SAILMON.
- Page 3 STEP 1: STEP 2: LET’S GET STARTED! CREATE AN ACCOUNT Download the Sailmon App and relive, analyse and Follow the on-screen instructions and choose share every sailing trip. Connect with friends and your preferred way to register. Already a member? competitors to compare your results.
- Page 4 STEP 3: TURN MAX ON TO THE INTERNET As shown on the image below, MAX has 5 buttons. MAX is all about connectivity. Connect MAX to the Hold the top middle button to turn it on. Once internet to log every trip in the Sailmon App and turned on, the functionalities of the buttons are keep your device updated with the latest software.
- Page 5 NETWORKS (VIA WIFI) BLUETOOTH INTERNET Select the available network in the area you want to Connect MAX to the internet via a phone. Make sure connect. Set the password. internet connection sharing on the device is enabled so MAX can discover the bluetooth connection.
- Page 6 Sailmon App. - Race Finish: log the race finish during your trip 5. Follow the on-screen instructions on MAX - Turn on MAX and go to Menu > System > for easy retrieval in the Sailmon App. Attach to Account - Set course axis: fill in the course axis by entering - Press on your phone ‘connect to MAX’.
- Page 7 Select or add the page you want to configure. here you can find the MAX serial number, current software version, if your MAX is online or not and 1. Change the lay-out: hold the top middle button. how much data your device still needs to send to 2 Choose the value in the lay-out you want to the server.
- Page 8 SENSORS > WIND SET COMPASS OFFSET: CONNECT WIND SENSOR: if your MAX is mounted in an angle, fill in a value in connect the bluetooth wind sensor to MAX. degrees between -180 and 180 here. Your sailing Please check out the wind sensor manual for data will keep accurate.
- Page 9 NETWORKS: add a NMEA transmitter and connect existing find an overview of all available networks in the sensors to MAX. Fill in the UDP input port number area. Connect or forget a network as you wish. and press save. BLUETOOTH INTERNET: NO GPS MODE: connect MAX to the internet via Bluetooth.
- Page 10 MENU > SYSTEM > ADVANCED CHECK FOR UPDATES DIAGNOSTICS: Check out if your MAX is running the latest software review the status of your MAX sensors in depth. update. Make sure your MAX is connected to the internet. Please notice MAX will automatically give a SIMPLE START PAGE: notificationn if there is a new software update.
- Page 11 MENU > TURN OFF Fill in your target angles to receive the best VMG to Turn off MAX after sailing. Your data is always make sure you’re on the right track while sailing. stored, so you can switch it off anytime.
- Page 12 MOUNT MAX Make sure your MAX is calibrated every time you Slide MAX into the mount on the side until you hear go sailing. Calibration needs to be done in two a click. Make sure you lanyard MAX with a 2mm line steps, right before the moment you mount MAX to by using the lanyard hole on the back.
- Page 13 OPEN THE SAILMON APP SAILING As soon as you get off the water your trip will be sent to the cloud as soon as MAX has an internet connection. Relive, analyse and share your sailing trip. Connect with friends and competitors to compare your results! Track your performances.
- Page 14 CHARGE MAX Turn off MAX after sailing. Go to Menu > Turn off > Are you sure: Yes. Nobody likes low battery levels, so make sure to charge it before your next use. Plug the Sailmon charger into the power plug and place MAX on top of the Sailmon logo until the blue light slowly flashes.
- Page 15 NEED SUPPORT? Simplified EU Declaration of Conformity: We, Sailmon BV, declare under our sole responsibility that the product MAX, to which this declaration relates, is in conformity with 2014/90/EU. We further declare that the product meets the essential requirement of the above Directives.
- Page 16 HELLINGWEG 9-B 2583 DZ DEN HAAG THE NETHERLANDS INFO@SAILMON.COM +31 (0)70 20 075 33 WWW.SAILMON.COM INSP INSP BY U BY U MAX QUICK START GUIDE...
