Summary of Contents for RCA SmarTVirtuoso RNSM3203-D
- Page 2 This product has been manufactured and sold under the responsibility of Curtis International Ltd. RCA, the RCA logo, the two dogs (Nipper and Chipper) logo, are registered trademarks or trademarks of Technicolor (S.A.) or itsaffiliates and are used under license by Curtis International Ltd.
- Page 5 Safety Information INDUSTRY CANADA NOTICE This device complies with Industry Canada Iicense-exempt RSS standard(s). Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, including interference that may cause undesired operation of the device.
- Page 6 Safety Information Servicing is required when the apparatus has been damaged in any way, such as power- supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
- Page 7 Important Safety Instructions and Maintenance Important Safety Instructions High Voltage Do not open CAUTION Risk of electronic shock, do not open.Do not If the following problems occur: attempt to service this product yourself as Turn off the TV set and unplug the AC power opening or removing covers may expose you cord immediately if any of the following to dangerous voltage or other hazards.
- Page 8 Important Safety Instructions and Maintenance Important Safety Instructions An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power When not in use circuits, or where it can If you will not be using the TV set for several fall into such power days, the TV set should be disconnected from lines or circuits.
- Page 9 Important Safety Instructions and Maintenance Installation When the TV being moved in from cold place, it needs some right time for dew inside unit evaporating fully before turn on the unit; Move To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.
-
Page 10: Table Of Contents
Important Information If a television is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as: • Using cabinets or stands recommended by the manufacturer os the television. •... -
Page 11: Accessories
Accessories Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer. Owner’s Remote Control Instructions Stand x 2 Screws x 4 AAA Batteries for Remote x 2 Top 5 Tips... -
Page 12: Introduction
Introduction Features TV adopts 32" TFT LED display screen Zero X radiation complies to green environment protection requirement Connect to computer directly to realize TV/monitor combo. USB 2.0 16:9 wide screen Auto tuning and fine tuning HDMI input Programmable sleep timer Wide range voltage input Basic Functions Input terminals used for external equipment connection... -
Page 13: Specifications
Introduction Specifications RNSM3203-D 32” Diagonal(max.) 1366X768 Digital: ATSC Analog: PAL-M/ PAL-N/ NTSC-M Digital: 7-69 Analog: Antenna: 2-69 Cable: 1-135 731.8x185.3x491mm 731.8x91.3x435mm 4.3 kg 4.23 kg 0 C-40 C NOTES: • Design and specifications are subject to change without notice. • Weight and Dimension shown are approximate. -
Page 14: Stand And Wall-Mounting Instructions (Optional)
Stand and Wall-mounting Instructions (optional) How to assemble the stand If you need to remove or assemble the stand please read the following instructions. - Before attaching/detaching the stand, make sure to turn off the TV. - Before performing work, spread cushioning over the base area to lay the LED TV on. This will prevent it from being damaged. - Page 15 Stand and Wall-mounting Instructions (optional) Wall mounting instructions: Your LED TV is able to accommodate wall mounting with the use of a wall mount bracket (not supplied with LED TV, please contact your local hardware store) and the mounting holes on the back of the unit. We recommend removing the TV stand prior to wall mounting the TV.
-
Page 16: General Description
General Description Overview of Front Panel (32") The buttons on the lower-right panel control your TV’s basic features, including the on-screen menu. To use the more advanced features, you must use the remote control. Red light indicates the TV is in standby mode. POWER(power on / key function) Green light indicates the TV is on. -
Page 17: Overview Of Back Panel
General Description General Description General Description Overview of back panel Overview of back panel Overview of Back Panel You can connect the TV with video devices such as DVD/VCD player, VCR and video camera to enjoy the high quality picture. DVD player Blu-ray disc player Camcorder... -
Page 18: Overview Of Remote Control
General Description Overview of Remote Control Loading batteries: 1) Remove the lid of the battery compartment. 2) Insert 2 size AAA batteries with polarities as indicated inside the compartment. 3) Replace the lid. Note: 1) A loading of batteries should be last one year under normal use. 2) If you don't intend to use the remote control for a long period of time, remove batteries to avoid damage due to leakage. - Page 19 General Description Overview of Remote Control POWER : Turn the TV on and off. INPUT : This button is used to switch among different sources, Select a source and press ENTER button to confirm. Digital Buttons(0-9, •) : Directly select channel with digital buttons.
- Page 20 General Description Overview of Remote Control MUTE : Press this button to cut off the sound of the TV set temporarily, press again to resume. COLOR BUTTONS : It's used in Apps. IGITAL EDIA LAYER CONTROL BUTTON Include play/pause, stop, previous, next, backward, forward is used in USB mode.
-
Page 21: Installing Batteries In The Remote Control
General Description Installing Batteries in the Remote Control Installing Batteries Open the battery compartment cover on the back side. Insert two 1.5V AAA size batteries in correct polarity. Don´t mix old or used batteries with new ones. INPUT Point the remote towards the remote control Closed the cover. - Page 22 VCR Rear Panel AUDIO OUT ANT ANT OUT S-VIDEO VIDEO OUT TV Rear Panel RF Cable (Not supplied) Audio Cable (Not supplied) Yellow Yellow Yellow White White Follow the instructions in Viewing a VCR or Camcorder Tape to view your VCR tape. Each VCR has a different back panel configuration.
- Page 23 The rear panel jacks on your TV make it easy to connect a camcorder to your TV. They allow you to view the camcorder tapes without using a VCR. Each Camcorder has a different back panel configuration. When connecting a Camcorder or DVD, match the color of the connection terminal to the cable. TV Rear Panel Video Yellow...
- Page 24 External Connection Connecting DVD Player/Set-Top Box via HDMI This connection can only be made if there is a HDMI Output connector on the external device. USB2 USB1 HDMI3 HDMI2 HDMI1(ARC) SPDIF AV IN 500mA 500mA HDMI Cable (Not supplied) What is HDMI? HDMI, or high-definition multimedia interface, is a next-generation interface that enables the transmission of digital audio and video signals using a single cable without compression.
- Page 25 External Connection Connecting Digital Audio System The rear panel jacks on your TV make it easy to connect a Digital Audio System to your TV. TV Rear Panel Digital Audio System (Black) Optical Cable (Not supplied) HDMI3 HDMI2 USB2 USB1 HDMI1(ARC) SPDIF AV IN...
- Page 26 Supporting Signals Input Mode Digital ATSC Analog PAL-M/PAL-N/NTSC M CVBS PAL/NTSC Vertical Input Resolution Frequency 480p 60Hz 720p 50/60Hz HDMI 1080i 50/60Hz 1080p 50/60Hz...
-
Page 27: Basic Operation
Basic Operation Menu Operation Input Setup Press INPUT key on the remote control to enter "INPUT SOURCE" menu. key to select a input source and press ENTER key to confirm. Home HDMI 1 HDMI 2 HDMI 3 Channels Selection There are four ways to select channel: 1) Using number keys and “... - Page 28 Basic Operation Menu Operation To increase the volume, press VOL + key; To decrease the volume, press VOL - key; Mute Press “ MUTE” and the sound cuts off. The MUTE icon will appear in the lower-right corner of the screen.
-
Page 29: Menu System Instruction
Menu System Instruction Picture 1. Press MENU key to display the main menu on the screen. 2. Press key to select "Picture" option. 3. Press key to enter "Picture" submenu. Picture Picture Sharpness Adjusts the outline of objects to either Picture Mode Standard sharpen them or make them more dull. -
Page 30: Sound
Menu system instruction Menu System Instruction Sound 1. Press MENU key to display the main menu on the screen. 2. Press key to select "Sound" option. 3. Press key to enter "Sound" submenu. Sound Sound Mode Picture You can select the type of the special sound effect to be used when watching a given broadcast. - Page 31 Menu system instruction Menu System Instruction Sound Digital Output Type Sound This is used to set digital audio output. Picture 1. Press key to select "Digital Output Type” option. Balance Sound 2. Press key to select a digital output type in DTV or HDMI mode.
-
Page 32: Setting
Menu system instruction Menu System Instruction Setting 1. Press MENU key to display the main menu on the screen. 2. Press key to select "Setting" option. Setting 3. Press key to enter “Setting" submenu. Picture Language 1. Press key to select “ OSD Language "... - Page 33 Menu system instruction Menu System Instruction Setting Off Time In "Off Time” item, press button or ENTER Setting button to enter the submenu, set the day & time to turn off the TV set. Picture Time On Time Auto Sync Sound In "On Time”...
- Page 34 Menu system instruction Menu System Instruction Lock The "Lock" feature automatically locks out programming that is deemed inappropriate for children. The user must first enter a Password before any of the lock restrictions can be set up or changed. 1. Press MENU key to display the main menu on the screen.
-
Page 35: Program
Menu System Instruction Program 1. Press MENU key to display the main menu on the screen. 2. Press key to select " rogram" option. Program 3. Press key to enter " rogram" submenu. Picture Auto Tuning Press ▲/▼ key to select "Auto Tuning" option. The CABLE Antenna Mode Sound... - Page 36 Menu System Instruction Program Signal Information ( Used only in DTV 1. Press key to select “Signal Information" option. 2. Press “ ENTER ”or key, you can see the information of the DTV channel. NOTE: Signal Quality/Signal Strength (DTV Only): Unlike analogue channels, which can vary in reception quality, digital channels must have perfect reception quality or you will not receive them at all.
-
Page 37: Lock
Menu System Instruction Network 1. Press MENU key to display the main menu on the screen. 2. Press key to select "Network" option. Network 3. Press key to enter "Network" submenu. Picture Wi-Fi Wi-Fi Not Connected Sound When the W -F i i wireless network is going to be... -
Page 38: About
Menu System Instruction About 1. Press MENU key to display the main menu on the screen. 2. Press key to select "About" option. About 3. Press key to enter "About" submenu. Picture Netflix Netflix Netflix Deactive Netfilx Deactive Sound 1.Press key to select “Netflix Deactive”... - Page 39 Menu System Instruction About System information 1.Press key to select "System information" option. 2.Press or "ENTER" key to display system information. NetReady Information 1.Press key to select "NetReady Information" option. 2.Press or "ENTER" key to display netready information. Software Update(USB) When the TV need to be updated, please copy the new software to a USB storage to TV, then operating by following steps.
-
Page 40: Home Operation
Home Operation Setup wizard Press “HOME” key to enter home interface. 1. SOURCE setup Press arrow key to select a input source and press ENTER key to confirm. Home HDMI 1 HDMI 2 HDMI 3 2. APP setup Apps 1)NETFLIX Use arrow key to Select icon, then press “ENTER”... - Page 41 Home Operation APP Setup 2)Youtube Use arrow key to select YouTube icon, then press “ENTER” key to enter Youtube. Use arrow button to select one video and press “ENTER” key to play. Press “MENU” key to exit playing. Press key to open or close control menu when playing 3) AMAZON PRIME VIDEO Use arrow key to Select "prime video"...
- Page 42 Home Operation APP Setup 5)Facebook Use arrow key to select facebook icon, then press “ ENTER ” key to enter Facebook. Visit https://www.facebook.com/device on your smartphone or computer to get code and enter the code. Press arrow key to browse the pages and press “ ENTER ”...
-
Page 43: Internet
Internet APP Setup Use arrow key to browse the pages. press “Back” key to return to main menu and press “EXIT” key to exit twitter. Red key: log in or log out twitter. Green key: refresh current page. Yellow key: write new twitter. Blue key: Search twitter. - Page 44 Home Operation 11) Screencast This function is for ANDROID smart phone sharing screens with TV. Download “miracast” app of google store in Android smart phone. Connect TV and phone to the same WIFI. Turn on the SCREENCAST application of TV. Turn on the Miracast function of phone.
-
Page 45: Digital Media Player
Digital Media Player Introduction This TV is embedded with one USB port digital media player. It can find the devices support USB1.1/2.0,including flash disk, USB hard disk and digital camera. It supports functions as: Display pictures. Play music files, Play video files. Notice: 1. -
Page 47: Limilted Warranty
Limilted Warranty...
