O P T I M I Z E S
W O R K
R O U T I N E S
E N V I R O N M E N T A L L Y
E F F E C T I V E
S E C U R E
i
n
AB-Z # 21 015
Weiterentwicklung im Sinne des Fortschrittes behalten wir uns vor. - Technical Modifications are subject to change. - Details techniques subject à modification sans avis préalable
Translation of the original operation manual GB, Stand 06 / 2018
Advertisement
Related Manuals for Rapid AB-Z
Summary of Contents for Rapid AB-Z
- Page 1 E F F E C T I V E S E C U R E AB-Z # 21 015 Weiterentwicklung im Sinne des Fortschrittes behalten wir uns vor. - Technical Modifications are subject to change. - Details techniques subject à modification sans avis préalable...
-
Page 2: Table Of Contents
· Please observe: This operation manual contains all necessary information. Please read carefully to avoid damages and faults. All Rapid pieces of equipment are checked carefully before delivery for their perfect composition and function. In case of improper use all rights to claim under guarantee are void. -
Page 3: General Advice
+49 (6158) 92980-0 2. General advice The liquids compatible with turbine digital meter must be at low viscosity, namely: - Water/urea solution Use of other fluids may be inaccurate and can damage the meter Not suitable when used in a retail sale! 3. - Page 4 +49 (6158) 92980-0 6. Spare party and accessories 9 10 11 12 No. Description Qty. No. Description Qty. M eter cover M eter body Rubber protection Bearing Self-tap screw ST 2.9x9.5 Self-tap screw ST 2.9x13 Battery holder Turbine Electro board Bearing holder Battery CR2 Self-tap screw ST 2.9x6.5...
-
Page 5: Operation
+49 (6158) 92980-0 7.Operation 7.1 User buttons The turbine digital meter features two buttons (MENU and RESET) which individually perform two main functions and together, other secondary functions. 7.2 The main functions performed are: RESET key: Resetting the partial register and reset table total (reset total) MENU key: Entering instrument calibration mode. - Page 6 +49 (6158) 92980-0 FLOW RATE FLOW RATE Fig.4 FLOW RATE 7.4 Reset the resettable total (Fig.5) When the meter is on standby, press RESET key for two seconds to reset the present total first. RESET TOTAL FLOW RATE Fig.5 RESET TOTAL FLOW RATE...
- Page 7 +49 (6158) 92980-0 RESET TOTAL Abb.5 7.5Procedure for enter the correction factor directly Carefully follow the procedure indicated below Formula: actual value Proper correction factor current correction factor display value Example: Actuyl value: 20,75 Display value: 18,96 Current corection factror: 1000 20,75 1.094 1000...
- Page 8 +49 (6158) 92980-0 7.5.3. Press the MENU key. Keep it pressed until similar with the image showed (the digit flash in Zone 1), it means the meter is in correction factor modification mode. RESET TOTAL 7.5.4. Press the RESET key to choose the right digit from 0 to 9. Press the MENU key to start the next digit.
- Page 9 +49 (6158) 92980-0 7.6.2 Reset the resettable total RESET TOTAL 7.6.3 Start dispensing into a meassuring glass. Stop dispensing when over 5 Litres of volume is reached, read out the actual value. The volume that is displayed on the LCD is the display value, not the actual value, which may be slightly higher.
-
Page 10: M Aintanance And Trouble Shooting
+49 (6158) 92980-0 7.6.5 Make sure the correction factor is right and then press the MENU key. Keep it pressed until calibration is finished and the factor is save. The meter will then return to standby. RESET TOTAL 8. Maintanace and trouble shooting 8.1 Battery replacement When replacing the battery, please open the cover, remove the plaug and replace the battery. - Page 11 +49 (6158) 92980-0...
- Page 12 +49 (6158) 92980-0 www.rapid-group.de• F a x : + 4 9 ( 6 1 5 8 ) 9 2 9 8 0 - 5 0 • info@rapid-group.de Rapid Group GmbH• Bahnhofstraße 53-55• 64560 Riedstadt• Telefon:+49 (6158) 92980-0•...
