Page 1: Table Of Contents
WAFFEL MAKER Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page...
Page 2: Ageneral Information
WAFFEL MAKER Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.
Page 3: A1 Product Description
Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION *The Professional Waffel Maker ,that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.WF.010 300x320x300 360x460x360 EMP.WF.020 600x320x300 660x460x360 TECHNICAL INFORMATION Operating Product...
Page 4: A3 Transportation
WAFFEL MAKER TRANSPORTATION Kasap Tip Dik Buzdolapları *This appliance can be moved by hand from area to area.Do not crash and drop the appliance while transporting. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.
Page 5: Csafety Instructions
WAFFEL MAKER Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ...
Page 6: Doperation
WAFFEL MAKER OPERATION Kasap Tip Dik Buzdolapları *Control Panel ; A : OFF position B : ON position C : Thermostat D : Indicator lamp E ; Signal lamp *Operating ; • Before operating the appliance,clean cooking surfaces and body with a moist cloth. •...
Page 7: Ecleaning & Maintenance
WAFFEL MAKER Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Clean the cooking surfaces with dry paper towel or soft moist cloth after every use. • Always turn off the appliance and disconnect from the power supply before cleaning. •...
Page 8: Ftroubleshooting
WAFFEL MAKER TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. THE APPLIANCE DOESN’T OPERATE Check the electrical connections and voltage. The appliance can stop due to low THE APPLIANCE STOPPED voltage.In this situation check the voltage. Check the appliance’s resistances.
Page 9: Gspare Part List-Exploding Drawing
WAFFEL MAKER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.WF.010...
Page 10 WAFFEL MAKER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE:EMP.WF.010 PRODUCT NAME P.CODE BASE FRAME Y.EMP.WF.010.001 TOP LID Y.EMP.WF.010.002 INNER FRAME Y.EMP.WF.010.003 RESISTANCE HOLDER (TOP) Y.EMP.WF.010.004 RESISTANCE HOLDER (BOTTOM) Y.EMP.WF.010.005 AIR CONDITIONING GRILL-BOTTOM Y.EMP.WF.010.006 CONTROL PANEL Y.EMP.WF.010.007 DOUGH FLOWINGDIVISION (BACK) Y.EMP.WF.010.008...
Page 11 WAFFEL MAKER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.WF.020...
Page 12 WAFFEL MAKER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE:EMP.WF.020 PRODUCT NAME P.CODE BASE FRAME Y.EMP.WF.020.001 TOP LID Y.EMP.WF.020.002 INNER FRAME Y.EMP.WF.020.003 RESISTANCE HOLDER (TOP) Y.EMP.WF.020.004 RESISTANCE HOLDER (BOTTOM) Y.EMP.WF.020.005 AIR CONDITIONING GRILL-BOTTOM Y.EMP.WF.020.006 CONTROL PANEL Y.EMP.WF.020.007 DOUGH FLOWINGDIVISION (BACK) Y.EMP.WF.020.008 DOUGH FLOWINGDIVISION Y.EMP.WF.020.009...
Page 13: Helectric Circuit Schema
WAFFEL MAKER Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA Lower Upper Thermostat Porcelain ON/OFF Thermostat Open Resistance Resistance Open Connector Switch (50-300ºC) Lamp 1100W 1100W Lamp...
Page 14 WAFFEL MAKER ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları Lower Upper Porcelain ON/OFF Thermostat Thermostat Open Resistance Resistance Connector Switch (50-300ºC) Open Lamp Lamp 1100W 1100W...
