Summary of Contents for Tokai R Series
- Page 1 Hand-Type Thermal Deposition Machine （Standard type） Operation Manual Tokai Metal Industry Co., Ltd. Tokai Bussan Co., Ltd.
- Page 2 Parts Name ○ Drill Stand Handle Soldering iron Punch ○Temperature controller...
- Page 3 Preparration for insert ○Temperature controller Actual Insert the soldering iron with built-in Power switch temperature controller into the outlet. ※3 cores ⇄ 2 cores conversion plug may be required. Preset Temperature Click here for details Setting Button Function key Set temperature Since set temp varies with the resin characteristics, determine the set temp by testing.
- Page 4 Press In 作業 ◇ ① Prepare Hand-Type Thermal Deposition Machine, and warm it after the setting of punch temperature. ②Place the insert nut at the opponent resin. ③Start press in by lowering the handle. ④Press in till the predetermined position, and raise the handle slowly.
