WT Knowles & Sons Bradford Windguard Push-On Top Fitting Instructions

Established 1906
nstructions
These instructions are for the fitting push-on tops into
existing pots.
The sketch shows the push-on top fitted to an existing pot
as a typical example. If a new pot is being installed with
push-on top, refer to the separate fitting instructions for the
particular pot.
Inspect the existing chimney pot and the new push-on top
and confirm they are undamaged.
Ensure the push-on top is suitable for use with the existing
chimney pot, flue system and the type of fire installed.
Using a sand/cement ratio of 3:1, apply a bead of mortar
around the top face rim of the chimney pot and fit the
push-on top in place. Align the push-on top with the
chimney pot and/or the chimney stack and ensure it is
vertical. Any exposed mortar at the joint should be
smoothed and angled downwards to allow rain to run away.
Fitting Instructions
Fitting Instructions
Bradford Windguard Push-On Top
W T Knowles & Sons Limited
Ash Grove Pipe Works
Elland
West Yorkshire
HX5 9JA
www.wtknowles.co.uk
Bradford Windguard
Push-On Top KBWTP
Existing Chimney Pot
(Example is Double Beaded
K10353)
Code No: KBWTP
Mortar bed
Exposed mortar
smoothed
©
October 2016: Issue 1
Push-on
top
Existing
pot
WT Knowles & Sons Limited 2016
