USE AND
MAINTENANCE MANUAL
Swing gates
Rev.02 30/03/2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BE20 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Roger BE20 Series

  • Page 1 USE AND MAINTENANCE MANUAL Swing gates Rev.02 30/03/2020...
  • Page 2 ROGER TECHNOLOGY is the exclusive proprietor holder of all rights regarding this publication. ROGER TECHNOLOGY reserves the right to implement any modifications without prior notification. Copying, scanning or any alterations to this document are prohibited without express prior authorised from by ROGER TECHNOLOGY.
  • Page 3 2 Important information for risk analysis The diagram below shows a typical installation, which details the potential hazards associated with any automated swing gate. LEGENDA: FEET CRUSHING HAZARD NO PASSING Warning! Danger of crushing feet due to moving mechanical surfaces or Warning door or gate moving.
  • Page 4: Maintenance

    Failure to observe these instructions may lead to danger. 4 Maintenance The ROGER TECHNOLOGY automation system for sliding gates requires periodical maintenance to keep it in proper working order and to ensure that it continues to function in complete safety.
  • Page 5 5 Unlock instructions Warning: always disconnect the installation from mains electricity and, if applicable, from the batteries before unlocking and locking the automation system. Fig. 1 BE20 - BR20 - R20 Series UNLOCKING (fig. 1) Open the lock cover (ref. 1), insert the key included in the lock and turn clockwise by 90°...
  • Page 6 BR21 - R21 Series UNLOCKING RL650 (fig. 1) Remove the lock cover (ref. 1), fit the lock release lever included and turn by approximately 120° towards the centre of the gate (ref. 2). Manoeuvre the gate manually (ref. 3). LOCKING RL650 (fig. 2) RL650 Fig.
  • Page 7: Troubleshooting

    6 Environmental requisites ROGER TECHNOLOGY products consist of electronic components and may also be equipped with batteries containing substances that are harmful to the environment. Disconnect from mains electricity before removing electronic components and the battery. Observe local regulations for disposing of used materials and packaging. Disposing correctly of products when no longer in use will contribute to preventing harm to the environment and to human health.
  • Page 8: Installation Details

    8 Installation details INSTALLER COMPANY Trading name Address (Street No, street etc.) PO CODE City Country Telephone no. E-mail INSTALLER Name Surname Mobile E-mail CUSTOMER Name Surname Address (Street No, street etc.) PO CODE City Country Telephone no. E-mail INSTALLATION APPLICATION RESIDENTIAL CONDOMINIUM INDUSTRIAL...
  • Page 9 PRODUCTS INSTALLED MOTOR CONTROL UNIT • ROGER  H70/200AC BRUSHLESS R20/300 M20/340 BRUSHLESS H20/370     B70/2DC BE20/200 R20/302 SMARTY4/HS H20/550      EDGE1 BE20/200/HS R20/500 SET M20/342 SMARTY5      BE20/400...
  • Page 10: Accessori Supplementari

    R85/60EAE H85/TDR/E   R85/60EAE/TRIX H85/TDR/I   R85/60IS H85/TDR/TRIX   R85/60IAS  R85/60IAE  ACCESSORIES • ROGER  • OTHER COMPANY  (Specify model) (Specify model) CFT500 TRIX50 CRA50    CFT501 TRIX100 CRA100   ...
  • Page 11: Preliminary Checks

    Initial test report CUSTOMER COPY Installer details Document No: Product description: B.code: CUSTOMER Name Surname Address of installation (Street, Square, ...) PO CODE City Country Telephone no. E-mail THE ABOVE PRODUCT HAS SUCCESSFULLY PASSED INITIAL TESTING PRELIMINARY CHECKS FUNCTIONAL TESTS Product complete and undamaged Test opening and closing of system unconnected to gate In-built safety devices undamaged...
  • Page 12: Automatic System

    CUSTOMER COPY Note: • The passing of the above mentioned tests allows the product to be considered suitable for use; it is also the formal act of final delivery of the product in its place of installation and use. • The CE plate applied to the motorized door or gate must be similar to the one shown below. •...
  • Page 13 Initial test report INSTALLER COPY Installer details Document No: Product description: B.code: CUSTOMER Name Surname Address of installation (Street, Square, ...) PO CODE City Country Telephone no. E-mail THE ABOVE PRODUCT HAS SUCCESSFULLY PASSED INITIAL TESTING PRELIMINARY CHECKS FUNCTIONAL TESTS Test opening and closing of system unconnected to gate Product complete and undamaged In-built safety devices undamaged...
  • Page 14 INSTALLER COPY Note: • The passing of the above mentioned tests allows the product to be considered suitable for use; it is also the formal act of final delivery of the product in its place of installation and use. • The CE plate applied to the motorized door or gate must be similar to the one shown below. •...
  • Page 15: Maintenance Log

    9 Maintenance log Corrective action 1 Trading name and address (or stamp) of maintenance company Date of work: Description of work: Replacement Reason for replacement: Material replaced: Date: Technician signature: Client signature: Signature for acceptance...
  • Page 16 Corrective action 2 Trading name and address (or stamp) of maintenance company Date of work: Description of work: Replacement Reason for replacement: Material replaced: Date: Technician signature: Client signature: Signature for acceptance...
  • Page 17 Corrective action 3 Trading name and address (or stamp) of maintenance company Date of work: Description of work: Replacement Reason for replacement: Material replaced: Date: Technician signature: Client signature: Signature for acceptance...
  • Page 18 Corrective action 4 Trading name and address (or stamp) of maintenance company Date of work: Description of work: Replacement Reason for replacement: Material replaced: Date: Technician signature: Client signature: Signature for acceptance...
  • Page 19 Corrective action 5 Trading name and address (or stamp) of maintenance company Date of work: Description of work: Replacement Reason for replacement: Material replaced: Date: Technician signature: Client signature: Signature for acceptance...
  • Page 20 10 Monthly maintenance checks To avoid problems it is important to perform simple maintenance checks on your automation on a monthly basis. Some basic information on the maintenance of your automation are indicated in chapter 4 of this USER MANUAL. Below you will find a summary table to record your checks.
  • Page 21 11 Force test measurements Force 1400 N Dynamic force IMPACT 400 N Static force CRUSHING 150 N 25 N 0,75 s time The force measurement data sheet is an important document for certification in compliance with the EC Directive. It is important that the forces exerted by the automatic gate are within the permitted values.
  • Page 22 12 Force measurement technical sheet POINT #1 TEST RESULT: POSITIVE  FAILED  System: ................................TEST Fd (N) Td (s) Fs (N) Fe (N) Date of test: ..............................Date of measurement : ............................ Serial number: ..............................Date of the last calibration: ..........................MEDIA POINT #1 TEST RESULT: POSITIVE ...
  • Page 23: Ec Declaration Of Conformity

    13 EC Declaration of Conformity (according to Annex II A of the Machinery Directive 2006/42 / EC) The legal representative of the company: Company name Legal address Fiscal Code or VAT number: Telephone: e-mail address Name and address of the person authorized to set up the technical file: Declare under his own responsibility that the product / s named: Objective description: Batch and serial number...
  • Page 24 ROGER TECHNOLOGY is the exclusive proprietor holder of all rights regarding this publication. ROGER TECHNOLOGY reserves the right to implement any modifications without prior notification. Copying, scanning or any alterations to this document are prohibited without express prior authorised from by ROGER TECHNOLOGY.
