SSC 2150 Assembly & Operation

COMMERCIAL BROADCAST SPREADER
2150
Model:
P52110_MXXXXX_Jan2020
SSC ASSEMBLY & OPERATION
HELPFUL HINTS
+ If your spreader does not spread
evenly, be sure "FRONT" on the GEAR-
BOX points to the front of the spread-
er. The impeller must turn clockwise
when pushing forward. Reversing
the GEARBOX will cause the impeller
to turn counter clockwise. Clean the
impeller plate after each use. Fertilizer
stuck on the impeller blades will cause
uneven spreading.
+ Your spreader is designed to be
pushed at three miles per hour, which
is a brisk walking speed. Clean and
dry your spreader thoroughly after
each use. Coat all metal surfaces
(pay special attention to the inside &
outside of tubing - it's easiest to do
while assembling) with light oil, Fluid
Film or silicon spray to help prevent
®
corrosion. Wash between the shut off
plate and the bottom of the hopper.
Do not use powdered materials.
+ Gears are permanently lubricated at
the factory. Do not open the gearbox
or dirt may enter.
ROCK SALT &
POWDERED MATERIALS
SHOULD NOT BE USED
in this spreader as it will damage
gearbox and can void warranty.
GRANULAR MATERIALS
USE ONLY
