PS2000 USB 22lb
Internet Enabled Digital Scale with Thermal Printer
Max: 22lbs d = 0.1oz
3 way power: USB, AC Adapter or Battery
User Manual
Scale Features
Weighing Scale – displays weight in lbs oz and gram
Counting Scale – counts similar items based on counting samples made
USB Connection to Computer – USB interface connection to send data from computer to scale or to printer
RS232 Thermal Printer Connection – allows printing of labels from your computer to the thermal printer (via scale)
Scale Specifications
?
Capacity
?
Graduation / Resolution
?
Minimum Weight detection
?
Min startup weight detection : > 0.1
?
Accuracy
?
Power consumption
?
Tare
?
Weight of Unit Scale
?
Dimensions
?
Platform Size
?
Power
Thermal Printer Specifications
?
Printing System
?
Maximum Characters Per Line : 48
?
Print Width
?
Interface
?
Input Data Format
?
Baud Rate
?
Print Buffer Size
?
Power Supply
?
Power Consumption (standby) : 40mA
?
Power Consumption (operating) : 4A (max)
?
Operating Temperature Range : 0
?
Dimensions
?
Weight
: 22lb
: 0.1oz
: 0.1oz
: ± 0.1% of the reading
: Approx. 0.35 watts
: Unlimited (not exceeding the scale range)
: 2.30 lbs
: 10.4" X 7.9" X 3.1"
: 5.7" x 7.5"
: AC adaptor: 9V, 100mA (Optional)
USB: Self powered or
Battery: 6 AA size batteries (not supplied)
: Thermal
: 2.28"
: Serial
: RS232C (1 Start, 8 Data, 1 Stop, No Parity)
: 9600
: 4 kilobytes
: 5V DC
o
o
C to 50
C
: 7.28" X 4.53" X 3.94"
: 1.70 lbs (excluding cable and power adapter)
Advertisement
Table of Contents
Related Manuals for Stamps.com PS2000
Summary of Contents for Stamps.com PS2000
- Page 1 PS2000 USB 22lb Internet Enabled Digital Scale with Thermal Printer Max: 22lbs d = 0.1oz 3 way power: USB, AC Adapter or Battery User Manual Scale Features Weighing Scale – displays weight in lbs oz and gram Counting Scale – counts similar items based on counting samples made USB Connection to Computer –...
- Page 2 Press Line Feed key to feed empty lines. This will cause the paper to move forward to the next line. STAMPS.COM Support Press this key to open the support webpage of Stamps.com website on the web browser. Printing Mail Labels from the Computer to the Printer via the Scale Labels can be printed from the computer to the printer using the application program that comes with this product.
- Page 3 c. Postal Service d. Zip Code e. Shipping Address 7. Click Create Label button on the program. A preview of the label can be seen on the lower part of the application window. 8. Click Print Label button to print this label to the thermal printer. 9.
- Page 4 Name: CHARACTER SIZE Function: Sets the width and height of characters to be printed Expression: <0x1B><0x21><n> Where n is composed of the following bits: 7 6 5 3 2 1 0 (bit number) X X D5 D4 X X X X X bits can be either 0 or 1 (don’t care bit values) D5 if 0 sets to normal width of character if 1 sets to double-sized width of character (double than the normal width)
