GHM Greisinger G 1110 Operating Manual

Barometer / altimeter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating manual
G 1110
EN
barometer | altimeter

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G 1110 and is the answer not in the manual?

Questions and answers

Summary of Contents for GHM Greisinger G 1110

  • Page 1 Operating manual G 1110 barometer | altimeter...

  • Page 2: Table Of Contents

    Table of contents Table of contents About this documentation .......................... 4 Foreword ................................4 Purpose of the document ..........................4 Legal notices ..............................4 Correctness of content ........................... 4 Layout of this document ..........................5 Further information ............................5 Safety ................................6 Explanation of safety symbols ........................
  • Page 3 Table of contents Disposal ................................. 23 Technical data .............................. 24 Spare parts and accessories ........................26 Ordering code .............................. 27 Service ................................28 13.1 Manufacturer ..............................28 13.2 Repairs processing ............................28 B-H88.0.01.DB2-1.0 3 / 28...

  • Page 4: About This Documentation

    1 | About this documentation G 1110 About this documentation Foreword Read this document carefully and familiarise yourself with the operation of the product before you use it. Keep this document ready to hand and in the immediate vicinity of the product so that it is available to the personnel/user for reference at all times in case of doubt.

  • Page 5: Layout Of This Document

    G 1110 About this documentation | 1 Layout of this document Description Each chapter is explained at the beginning in the description. Prerequisite All mandatory prerequisites are then listed for each step. Instruction Tasks to be carried out by the personnel / user are represented as numbered instruc- tions.

  • Page 6: Safety

    2 | Safety G 1110 Safety Explanation of safety symbols DANGER This symbol warns of imminent danger, which can result in death, severe bodily injury, or severe property damage in case of non-observance. CAUTION This symbol warns of potential dangers or harmful situations, which can cause dam- age to the device or to the environment in case of non-observance.

  • Page 7: Intended Use

    G 1110 Safety | 2 Intended use The G 1110 measures the absolute pressure in the air. The ambient pressure is measured directly via the integrated sensor. Pressure equali- sation between the unit and the environment takes place via a water-impermeable membrane on the front side.

  • Page 8: Description

    3 | Description G 1110 Description Scope of delivery Please check to ensure the completeness of the product after opening the package. You should find the following components: – Quick reference guide – Handheld measuring device, ready for operation, including batteries –...

  • Page 9: The Product At A Glance

    G 1110 The product at a glance | 4 The product at a glance The G 1111 Top view LCD Display Front view Display elements Display Battery indicator Evaluation of the battery status Unit display Display of the units or Min/Max/Hold information...
  • Page 10 4 | The product at a glance G 1110 Up / Down button Press briefly Display of the min/max value Change value of the selected parameter Long press Reset the min/max value of the current measure- ment Both simultaneously Rotate display, overhead display...

  • Page 11: Operation

    G 1110 Operation | 5 Operation Commissioning 5.1.1 Explanation Description The product is switched on with the On/Off button. It may be necessary to configure the product after switching on. See Configuration [ 11]. Prerequisite – Sufficiently full batteries are inserted in the product.

  • Page 12: Configuring Parameters Of The Configuration Menu

    5 | Operation G 1110 5. The changes are saved after running through the entire Configuration menu. STOR appears in the display. The Configuration menu can be exited from any arbitrary parameter by pressing and holding the Function key for 2 seconds. The changes made up that point are saved.
  • Page 13 G 1110 Operation | 5 Activatable special functions FVNC NVLL Function key At barometer display: tare function At altimeter display: setting the altitude AVR 0:02 / AVR Rapid measurement with mean value over 2 s / 5 s / 10 s activatable...
  • Page 14 5 | Operation G 1110 With activated TEND display additionally: TEND Trend value Temperature in °C und trend value °(.TE Temperature in °F und trend value °F.TE Temperature in °C, trend value and air pressure °(.P.T (only available at altimeter display units) °F.P.T...

  • Page 15: Open The Adjustment Menu

    G 1110 Operation | 5 5.2.4 Open the adjustment menu Description In order to change sensor calibration, you must first open the adjustment menu menu. The menu is opened as shown in the illustration. Prerequisite – The product is switched off.
  • Page 16 5 | Operation G 1110 3. The available configuration options are listed for each parameter in the following representation. Representation Parameter Values Meaning Zero point correction PR.OF No offset PR.OF -5.0 .. 5.0 Offset active Gradient compensation specification PR.SL No slope PR.SL...

  • Page 17: Measurement Basics

    G 1110 Measurement Basics | 6 Measurement Basics General information about absolute pressure measurement The device measures absolute pressure. However, this should not be confused with the "sea level air pressure" indicated by weather stations. The altitude-based air pres- sure decrease is calculated for these pressure specifications. The device is capable of correcting this air pressure altitude correction.

  • Page 18: Use Of The Trend Indicator

    6 | Measurement Basics G 1110 Use of the trend indicator 6.3.1 Meteorology: weather forecasting Observation of variable weather conditions by assessing the rate of change of air pressure. To do this, set the device to: UN,T HPa (international standard)

  • Page 19: Protection Of Sensors With Use Of Filter Membranes

    G 1110 Measurement Basics | 6 Protection of sensors with use of filter membranes The product and the sensor are effectively protected by a filter membrane. This pre- vents the product from being destroyed by water, for example. The membrane is located under the pressure equalisation openings:...

  • Page 20: Operation And Maintenance

    7 | Operation and maintenance G 1110 Operation and maintenance Operating and maintenance notices NOTE Pressure equalisation opening must be protected from soiling. Battery 7.2.1 Battery indicator If the empty frame in the battery display blinks, the batteries are depleted and must be replaced.

  • Page 21: Calibration And Adjustment Service

    G 1110 Operation and maintenance | 7 Calibration and adjustment service 7.3.1 Certificates The certificates are categorised as ISO calibration certificates and DAkkS calibration certificates. The purpose of the calibration is to verify the precision of the measuring device by comparing it with a traceable reference.

  • Page 22: Error And System Messages

    8 | Error and system messages G 1110 Error and system messages Display Meaning Possible causes Remedy ---- Calculation not pos- Measurement data Waiting for data collection sible acquisition is run- ning No display, Battery depleted Battery depleted Replace battery...

  • Page 23: Disposal

    G 1110 Disposal | 9 Disposal Separation by material and recycling of device components and packaging must take place at the time of disposal. The valid regional statutory regulations and directives applicable at the time must be observed. NOTE The device must not be disposed of with household waste. Return it to us, freight pre- paid.

  • Page 24: Technical Data

    10 | Technical data G 1110 Technical data Measuring range Barometer 300.0 .. 1100.0 hPa (mbar) abs. 4.350 .. 15.950 PSI abs. 225.0 .. 825.0 mmHg (Torr) abs. Altimeter -500.0 .. 9000.0 m -1640 .. 19999 ft Temperature -20.0 .. 50.0 °C -4.0 ..
  • Page 25 G 1110 Technical data | 10 Directives and standards The devices conform to the following Directives of the Council for the harmonisation of legal regulations of the Member States: 2014/30/EU EMC Directive 2011/65/EU RoHS Applied harmonised standards: EN 61326-1:2013 Emission limits: Class B Immunity according to Table 2 Additional error: <...

  • Page 26: Spare Parts And Accessories

    11 | Spare parts and accessories G 1110 Spare parts and accessories A selection of spare parts and accessories for this product is listed below. Article Number Name Description 601060 GKK 1100 Case with nap foam, 340 x 275 x 83 mm...

  • Page 27: Ordering Code

    G 1110 Ordering code | 12 Ordering code G 1110 - 1. Set-Option Device only Measuring device, suitcase GKK 1002 Measuring device, suitcase GKK 1002, WPD5 calibration certificate B-H88.0.01.DB2-1.0 27 / 28...

  • Page 28: Service

    13 | Service G 1110 Service 13.1 Manufacturer If you have any questions, please do not hesitate to contact us: Contact GHM Messtechnik GmbH GHM GROUP - Greisinger Hans-Sachs-Str. 26 93128 Regenstauf | GERMANY Email: info@greisinger.de | www.greisinger.de WEEE reg. no. DE 93889386 13.2...
