- Page 1 Original operating instructions CSL 505 Switching light curtains We reserve the right to make technical changes EN ● 2020/11/14 ● 50128679...
- Page 2 © 2020 Leuze electronic GmbH + Co. KG In der Braike 1 73277 Owen/Germany Phone: +49 7021 573-0 Fax: +49 7021 573-199 http://www.leuze.com info@leuze.de...
-
Page 3: Table Of Contents
Receiver bar ............................26 4.3.2 Transmitter bar ............................26 Substitution of Vario B ...........................27 4.4.1 Receiver bar ............................27 4.4.2 Transmitter bar ............................27 Maintenance ....................... 28 Technical data ......................29 General specifications ..........................29 Nomenclature ............................30 Leuze electronic GmbH & Co. KG CSL 505... - Page 4 Figures and tables Figure 1: CSL505 interface ..........................9 Figure 2: Pin assignment of CSL 505 switching light curtain cables ............9 Figure 3: Configuration window of CSL505 software .................10 Figure 4: Mounting the CSL 505 switching light curtain ................21 Figure 5: M8 connector version, open cable end..................23...
-
Page 5: General Information
About this technical description These operating instructions contain information regarding the proper and effective use of the CSL 505 switching light curtain. These operating instructions (PDF file) can be downloaded from the Internet at www.leuze.de. Used symbols and signal words The symbols used in this technical description are explained below. -
Page 6: Safety Notices
The CSL 505 switching light curtain was developed, manufactured and tested in accordance with the applicable safety standards. It corresponds to the state of the art. Approved purpose The CSL 505 switching light curtain is used for detecting objects in defined controlled areas as part of a superordinate overall system. ATTENTION The protection of personnel and the device cannot be guaranteed if the device is operated in a manner not corresponding to its intended use. -
Page 7: Working Safely
Installation and electrical connection of the light curtains should be performed only by qualified personnel in accordance with the applicable regulations, with the power supply disconnected and the device switched off. Leuze electronic GmbH & Co. KG CSL 505... -
Page 8: Product Description
Product description General information The CSL 505 switching light curtains monitor a defined area using invisible, infrared light beams. The light curtain systems consist of a transmitter bar (Tx) and receiver bar (Rx). They function in the same way as a system comprising multiple throughbeam photoelectric sensors. If one of the light beams between the transmitter bar and receiver bar is interrupted, this is registered by the evaluation electronics and signaled at the push-pull signal outputs. -
Page 9: Configuration Interface
Configuration interface The configuration can be read out and changed using the CSL505 software. The CSL505 software can be downloaded at the Leuze website: www.leuze.com. The CSL505 interface is used for connection to the serial port of a PC. Figure 1:... -
Page 10: Configuration Software
Product description Configuration software The CSL505 software configuration software can be used to change the functionality of the CSL 505 light curtain. The software operates under the Windows ® 95/98/2000/NT/XP/7/8 operating systems. Depending on the used parameter list, parameter values may have different designations or be hidden. -
Page 11: Parameters (Receiver)
The CSL 505 switching light curtains can be configured over a wide range. 3.5.1 Switching output (dark/light) You can configure the CSL 505 switching light curtain to be dark switching or light switching. Switching output (dark/light) This is set using the parameter... -
Page 12: Beam Mode
• A higher number of beams also increases the cycle time! • A total of max. 160 logical beams are possible. Factory settings: Pin 1 Pin 3 Description +24 V DC Only parallel beams +24 V DC Parallel and diagonal beams Leuze electronic GmbH & Co. KG CSL 505... -
Page 13: Relative Switching Threshold
, a serious error is signaled. Below this number, defective beams are blanked and not taken into consideration during evaluation. Blanking of defective beams All other blanked beams are not added to Input option: 0…160 Factory setting: Leuze electronic GmbH & Co. KG CSL 505... -
Page 14: Start Beam Of Second Switching Range
Start beam of second switching range Start beam of second switching range With you split the CSL 505 switching light curtain into two ranges. The state of the ranges is indicated at the outputs pin 2 and pin 4. Output functions... -
Page 15: Synchronization Beam
If the intensity of the received signal remains below a set value ( Warn signal delay [s] for a certain period ( ), the CSL 505 switching light curtain signals a "minor error". Possible remedies: • Clean the beam exit. -
Page 16: Warn Signal Delay [S]
Input option: 0…255 Factory setting: 3.5.14 Blanking warning Blanking warning specifies the position (beam number) as of which an error message is issued in the event of blanking. Input option: 0…160 Factory setting: Leuze electronic GmbH & Co. KG CSL 505... -
Page 17: Overview Table Of Configuration Values For Receiver
Threshold for soiling warning. Relative switching threshold: Warn Corresponds to 57 % (value * 256) (0…255) Only the value of the physically present beams should be set; an incorrect value can lead to malfunctions. Leuze electronic GmbH & Co. KG CSL 505... - Page 18 (0…255) '0' deactivates the function. Beam number as of which an error Blanking warning message is issued in the event of blanking (0…160) (not defective!). Table 5: Configuration values Receiver Leuze electronic GmbH & Co. KG CSL 505...
-
Page 19: Parameters (Transmitter)
[s]“ on page 14). All beams are switched off, e.g. to prevent interference at multiple sensors. The warning output remains unchanged. (Factory setting in bold type) Table 6: High signal and Low signal at input Leuze electronic GmbH & Co. KG CSL 505... -
Page 20: Operating Range
Extended (0) or reduced (1) operating range (0…255) 2…255: Disable transmitter deactivation first = Synchronization using first beam Synchronization beam first last = Synchronization using last beam Table 8: Configuration values for transmitter Leuze electronic GmbH & Co. KG CSL 505... -
Page 21: Mounting And Commissioning
Last beam Figure 4: Mounting the CSL 505 switching light curtain You will find the dimensions in: Table 13: "Dimensions CSL 505" on page 34 or Table 14: "Dimensions of CSL 505, special variant "VB"" on page 36. NOTE • Do not mechanically load, bend or warp the bars. - Page 22 Rotate the transmitter and receiver about the vertical axis until the front screens of the devices are perfectly aligned with each other. Align the transmitter and receiver with a common limit stop if necessary. Leuze electronic GmbH & Co. KG CSL 505...
-
Page 23: Electrical Connection
+24 V DC Pin 1 Pin 3 Description +24 V DC Only parallel beams +24 V DC Parallel and diagonal beams The depicted assignments are standard settings. The assigned functions can be freely configured. Leuze electronic GmbH & Co. KG CSL 505... -
Page 24: Teach Event
Mounting and commissioning Teach event NOTE • The teach event is important for ensuring the function of the CSL 505 switching light curtain • The teach event always occurs at the receiver • Transmitter and receiver must be optimally aligned with one another for maximum performance reserve •... -
Page 25: Teach Event For Devices After 40/2017 (Firmware Version Starting With V2.22)
Pressing the button on the adapter switches the supply voltage to pin 2. After the teach event, the adapter is removed and the device plugged directly back into the connection cable. Leuze electronic GmbH & Co. KG CSL 505... -
Page 26: Led Indicators/Error Diagnostics
Mounting and commissioning LED indicators/Error diagnostics If the CSL 505 switching light curtain detects a fault, the LEDs show one of the following error codes. Depending on the output assignment and output function, a warning output may be evaluated. As soon as the cause of the fault is rectified, the warning output becomes inactive again. -
Page 27: Substitution Of Vario B
1 and pin 3. 4.4.2 Transmitter bar In existing installations with all Vario B types, the function assignment of the electrical connection remains unchanged on the transmitter bar. Leuze electronic GmbH & Co. KG CSL 505... -
Page 28: Maintenance
Maintenance Maintenance The CSL 505 switching light curtain does not require regular maintenance. If the front cover should become soiled, clean it with a moist cloth. • Do not use any cleaners which contain solvents to clean. • Do not use any high-pressure cleaners or steam jet cleaners •... -
Page 29: Technical Data
IP 65 Environmental data Operating temperature -30 °C to +50 °C Storage temperature -40 °C to +65 °C Elevation < 2000 m Degree of contamination approx. 1000 … 10000 mm for -ER model Leuze electronic GmbH & Co. KG CSL 505... -
Page 30: Nomenclature
VB: Profile and mounting system compatible with VARIO B Electrical connection: M8: M8 connector xxxx: length of the cable tail in mm Table 11: Part number code Dimensioned drawings Figure 7: CSL 505 with beam spacing 5 mm Leuze electronic GmbH & Co. KG CSL 505... -
Page 31: Dimensions
Technical data Figure 8: CSL 505 with beam spacing > 5 mm Dimensions The housings have the following dimensions: Beam spacing Width Depth (mm) (mm) 5 mm 12.5 / 25 / 50 / 100 mm Table 12: Dimensions housing Dimensions CSL 505:... - Page 32 20.0 55.0 CSL505-T25-275-M8 CSL505-R25-375-M8 20.0 55.0 CSL505-T25-375-M8 CSL505-R25-475-M8 20.0 55.0 CSL505-T25-475-M8 CSL505-R25-575-M8 20.0 55.0 CSL505-T25-575-M8 CSL505-R25-675-M8 20.0 55.0 CSL505-T25-675-M8 CSL505-R25-775-M8 20.0 55.0 CSL505-T25-775-M8 CSL505-R25-875-M8 20.0 55.0 CSL505-T25-875-M8 CSL505-R25-975-M8 1050 20.0 55.0 CSL505-T25-975-M8 Leuze electronic GmbH & Co. KG CSL 505...
- Page 33 CSL505-R50-1950-M8 1950 2030 20.0 60.0 CSL505-T50-1950-M8 CSL505-R50-2350-M8 2350 2430 20.0 60.0 CSL505-T50-2350-M8 with 4 m cable tail with greater operating range These variants with special lengths have neither diagonal nor crossed-beam scanning. Leuze electronic GmbH & Co. KG CSL 505...
- Page 34 13.5 159 CSL505-T12.5-288-VB-M8 CSL505-R12.5-388-VB-M8 12.5 387.5 13.5 159 CSL505-T12.5-388-VB-M8 CSL505-R12.5-488-VB-M8 12.5 487.5 13.5 159 CSL505-T12.5-488-VB-M8 CSL505-R12.5-588-VB-M8 12.5 587.5 13.5 159 CSL505-T12.5-588-VB-M8 CSL505-R12.5-688-VB-M8 12.5 687.5 13.5 159 CSL505-T12.5-688-VB-M8 CSL505-R12.5-788-VB-M8 12.5 787.5 13.5 159 CSL505-T12.5-788-VB-M8 Leuze electronic GmbH & Co. KG CSL 505...
- Page 35 1950 2160 CSL505-T50-1950-VB-M8 CSL505-R50-2350-VB-M8 2350 2560 CSL505-T50-2350-VB-M8 CSL505-R50-2750-VB-M8 2750 2960 CSL505-T50-2750-VB-M8 CSL505-R50-3150-VB-M8 3150 3360 CSL505-T50-3150-VB-M8 CSL505-R100-700-VB-M8 CSL505-T100-700-VB-M8 CSL505-R100-1100-VB-M8 1100 1370 CSL505-T100-1100-VB-M8 These variants with special lengths have neither diagonal nor crossed-beam scanning. Leuze electronic GmbH & Co. KG CSL 505...
- Page 36 CSL505-T100-2700-VB-M8 CSL505-R100-3100-VB-M8 3100 3370 CSL505-T100-3100-VB-M8 Table 14: Dimensions of CSL 505, special variant "VB" Legend: Number of bore holes Distance housing edge - last beam Bore hole to profile edge X Distance housing edge - first beam (connection) Bore hole to bore hole...
-
Page 37: Accessories And Scope Of Delivery
Scope of delivery Transmitter and receiver both have their part number. • Transmitter / receiver with supplementary sheet These operating instructions (PDF file) can be downloaded from the Internet at www.leuze.com. NOTE Connection cables, interconnection cables, mounting brackets, etc. are not included in the scope of delivery and must be ordered separately.
