The M870D Remote Display connects to 70 Series IEDs through one of the serial communications ports. The M870D is designed to provide a convenient way to view measurements made by the 70 Series IEDs. A maximum of 64 user-configurable measurement screens can be displayed. The instrument can be set to display a single screen continually or automatically scroll through all available screens. -
Page 11: Physical
Pollution: Any degree of foreign matter, solid, liquid, or gaseous that can result in a reduction of electric strength or surface resistivity of the insulation. Pollution Degree 2: Only non-conductive pollution occurs except that occasionally a temporary conductivity caused by condensation is to be expected. ML0027 October 28, 2013 Copyright 2013 Bitronics, LLC... -
Page 12: Standards And Certifications
Open Circuit Voltage: 1.2 / 50 µs Short Circuit Current: 8 / 20 µs Amplitude, AC Power Port: 2 KV common mode, 1 KV differential mode Amplitude, I/O Signal Port: 1 KV common mode ML0027 October 28, 2013 Copyright 2013 Bitronics, LLC... - Page 13 Level: 3 Frequency: 150 kHz – 80 MHz Amplitude: 10 V rms Modulation: 80% AM @ 1 kHz AC Supply Voltage Dips and Short Interruptions EN 61000-4-11: 2004 (supersedes EN 61000-4-11: 1994) ML0027 October 28, 2013 Copyright 2013 Bitronics, LLC...
-
Page 14: Installation
Bitronics instruments are carefully checked and "burned in" at the factory before shipment. Damages can occur, however, so please check the instrument for shipping damage as it is unpacked. Notify Bitronics LLC immediately if any damage has occurred, and save any damaged shipping containers. -
Page 15: Surge Protection
2.5 Supply/Mains Disconnect Equipment shall be provided with a Supply/Mains Disconnect that can be actuated by the operator and simultaneously open both sides of the mains input line. The disconnect should be UL ML0027 October 28, 2013 Copyright 2013 Bitronics, LLC... -
Page 16: Power Supply Connections
2.6 Power Supply Connections Power and ground are applied to three screws on a barrier strip on the rear of the M870D. There is one chassis ground point that MUST be connected to Earth Ground. This is located on the mounting flange. -
Page 17: Setup
3.0 SETUP 3.1 Communications Connections ML0027 October 28, 2013 Copyright 2013 Bitronics, LLC... - Page 18 M870D RS-232 Cable Connections to the M57x ML0027 October 28, 2013 Copyright 2013 Bitronics, LLC...
-
Page 19: Setup Mode
3.2 Setup Mode The M870D has three configurable parameters that must be set to match the device to which it is connected. Press the up arrow key and the right arrow key simultaneously to enter the display setup mode. The alphanumeric display will describe the selected parameter, while the digit display will show the value. -
Page 20: Measurement Screens
Measurements that are shown on the M870D are setup using the Windows based 70 Series Configurator. There are two folders in the Communication section, which must be configured before the M870D can be used. The first folder is used to setup the Port Assignments, as shown in Figure 3. - Page 21 Please refer to the online help in the 70 Series Configurator for additional information. Note: The Meter ID of the M870D must match the "ID of Display" value. ML0027 October 28, 2013...
-
Page 22: Operation
3.4 Operation 3.4.1 Overview ML0027 October 28, 2013 Copyright 2013 Bitronics, LLC... -
Page 23: Keypad
When connecting the Service Port to a PC, a straight through cable, either 9-pin to 9-pin or 9-pin to 25-pin, is required. A null modem cable is not required. ML0027 October 28, 2013 Copyright 2013 Bitronics, LLC... -
Page 24: Troubleshooting
Applies only to devices reapply. manufactured prior to July, 2002. 5.0 FIRMWARE UPGRADES The M870D is field upgradable. Please refer to specific instructions provided with new firmware. ML0027 October 28, 2013 Copyright 2013 Bitronics, LLC... - Page 25 ML0027 October 28, 2013 Copyright 2013 Bitronics, LLC...
- Page 26 ML0027 October 28, 2013 Copyright 2013 Bitronics, LLC...
- Page 27 ML0027 October 28, 2013 Copyright 2013 Bitronics, LLC...
- Page 28 Revision Date Changes 01/30/2009 Update Bitronics Name, Logo E. DeMicco 05/01/09 Updated logos and cover page MarCom 9/22/09 Updated Section 1.5 to reflect current standards, updated RAF/EJD Declaration of Conformity 3/6/13 Updated Declaration of Conformity 10/28/13 Updated for 61010-1 Edition 3, Declaration of Conformity...
