Summary of Contents for Sandberg 134-22
- Page 1 ConfCam EPTZ 1080P HD Remote Quick guide 134-22 www.sandberg.world...
-
Page 2: Product Overview
Quick guide Product overview Green LED: Constant light: In use, ashing when remote control is activated Microphone Lens Microphone USB 2.0 port... -
Page 3: Mounting Options
On a PC Monitor On a tripod, for example Sandberg item no. 134-26 Screw the wall mount bracket on the wall, refer to the following picture 1. Fasten the camera on the wall mount bracket, refer to the following picture 2. - Page 4 Quick guide Connect webcam to USB port on computer...
-
Page 5: Software Installation
The camera works driver-less and is compatible with most chat-applications. If you want to get further options for video-effects and image adjustments, please follow this link: www.sandberg.world/webcamguide Choose this device name on the device list for video-camera and recording microphone: Sandberg Confcam EPTZ 1080p... -
Page 6: Remote Control
Quick guide Remote control Open the back of the remote control and insert 2 x AAA batteries. - Page 7 Quick guide Digital Pan, Tilt and Zoom functions (EPTZ) Zoom: The camera supports EPTZ 3x digital zoom. When you zoom into the image the option opens for moving Up / Down (Tilt) and Left / Right (Pan). 1. Press Zoom+ on the remote control to zoom in image.
- Page 8 Quick guide 2. After the image is zoomed in, you can move the image viewing angle Up / Down (Tilt) and Left / Right (Pan). Down Down Left Left Right Right...
- Page 9 Quick guide Picture in Picture (PIP) After the image is zoomed in, you can see the full out-zoomed image in a small overlay frame (PIP). 1. Press “Camera OSD Menu (Middle)”, select “Image”. 2. Select “PIP” to “On”. Picture in Picturefunction turns on, users can see smallpicture-in-picture window at the bottom of right.
- Page 10 Quick guide On-Screen-Display (OSD) menu...
- Page 11 Quick guide...
-
Page 12: Warranty
Support http://helpdesk.sandberg.world Warranty There is a ve-year warranty on your Sandberg product. Please read the warranty terms and register your new www.sandberg.world/warranty Sandberg product at Years Warranty For information on handling electronic waste, see www.sandberg.world/weee...
