01
[09] x14
6bi4
Overlap
shed with
[06] x 1
plastic
roof
[02]
ABQ46DEV2 (Door end)x1
02
[10] M8 x 50mm x3
[05] ABQ46V2FL
(OSB Floor)x1
Your Product
[03] ABQ46PSV2 (Plain side)x1
[01]
ABQ46PEV2 (Plain end)x1
[03]
ABQ46PSV2 (Plain side)x1
[02]
ABQ46DEV2 (Door end)x1
[04]
ABQ46WSV2 (Window side)x1
Safety
[05]
ABQ46V2FL
[06]
PTGVDR1672
[08]
64PPRBCEWG
(Roof)x1
(OSB Floor)x1
(Door)x1
Fixing pack ref: FP64EZ
[09]
M6 x 30mm x45
[10]
M8 x 50mm x24
[11]
30mm x12
[12]
Panel Pin x12
[13]
Hasp and Staple x1
[15]
T-Hinge x2
[14]
Top Hat x18
[16]
45281784 Batten 45x28x1784 x1
[17]
15120585DTR Glazing strip 15x12x585 Dtreat x3
[18]
70080730A1DTR Barge board 70x8x730 A1 Dtreat x4
[19]
45151690DTR Corner strip x4
[20]
85009 PVC trim x1
[21]
PW610610 Styrene Window
You will need
factory applied surface treatment. To protect the
product against rot we recommend annual
re-treatment with a suitable timber preservative.
[15] x 2
[01] ABQ46PEV2
(Plain end)x1
Helpline Information
Timber is a natural material. It will
1
shrink and swell as a result of varying
moisture content.
Please keep all plastic bags and
small parts away from children
in order to reduce the risk of
suffocation.
this product. The roof is not a load
bearing structure.
Always pre-drill the timber with a
3mm drill bit to avoid splitting.
Ensure your product is built on a solid
and level base.
Barcode: 5397007006674
03
[10] M8 x 50mm x9
[02] ABQ46DEV2 (Door end)x1
[04] ABQ46WSV2 (Window side)x1
04
[10] M8 x 50mm x10
Contact us
If there are any technical queries with
www.diy.com
this product, please contact our customer
helpline on 0844 248 9853
B&Q plc
This helpline is managed by Forest Garden
Chandlers Ford
and is open between the hours of 8.30 am
Hampshire
and 5.00pm Monday to Friday
SO53 3LE
05
[10] M8 x 50mm x 2
[16] Batten 45x28x1784 x1
06
[09] M6 x 30mm x18
[09] 30mm x3 per corner strip
[08] 64PPRBCEWG (Roof)x1
[13] Top Hat x18
[07] x8
IMPORTANT:
RETAIN FOR FUTURE REFERENCE:
READ CAREFULLY
