MUELLER CO. H-11199 Manual

Relubricating tool
Hide thumbs
1
2

Advertisement

Table of Contents

Relubricating Instructions

1. Unscrew cap from the H-11199 Relubricating Tool.
2. Remove shaft from body and turn handle counter-clockwise to retract shaft until "O" ring and piston are
withdrawn into cap.
3. Insert a stick of Mueller Grease (H-853) into the body.
4. Replace and tighten cap.
5. Turn handle clockwise to force grease out of the nozzle opening.
6. Be sure the Luboseal
®
groove in the key with the grease port recess.
7. Remove the grease plug by using the hex wrench on Relubricating Tool handle. Screw tool nozzle into grease plug
threads as far as possible.
8. Turn the handle clockwise, forcing the grease into the vertical groove in the key. If immediate resistance is
encountered, probably the groove in the key is not aligned with the grease port. Turn the key slightly in either
direction until the grease begins to flow.
Stop is in either the FULLY OPEN or FULLY CLOSED position. This aligns the vertical
H-11199 Relubricating Tool
(continued)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H-11199 and is the answer not in the manual?

Questions and answers

Summary of Contents for MUELLER CO. H-11199

  • Page 1 H-11199 Relubricating Tool Relubricating Instructions 1. Unscrew cap from the H-11199 Relubricating Tool. 2. Remove shaft from body and turn handle counter-clockwise to retract shaft until “O” ring and piston are withdrawn into cap. 3. Insert a stick of Mueller Grease (H-853) into the body.
  • Page 2 Relubricating Instructions (continued) • The amount of grease required to relubricate a Luboseal Stop depends upon how hard the stop turns and how much ® grease must be replaced. The table below shows the number of complete revolutions of the handle required to fully relubricate each size of Luboseal Stop.
