- Page 1 WIRELESS COMMUNICATION SYSTEM NB-IoT NB-K430 Revision 1.0 SOFTLINK s.r.o., Tomkova 409, 278 01 Kralupy nad Vltavou, Czech Republic Phone.: +420 315707111, e-mail: sales@softlink.cz, www.softlink.cz...
-
Page 2: Table Of Contents
2 Technical parameters overview 3 Configuration of the NB-K430 module 3.1 Setting of NB-K430 module parameters by configuration cable ..... - Page 3 ....” Set of NB-K430 module components with stick antenna ......
-
Page 4: Introduction
(AMR) in form of radio-messages of NB-IoT service (”INFO” messages). The NB-K430 module can by used for remote reading up to 10 iPERL watermeters placed in its radio-reach (that is up to hundreds meters). Each watermeter transmits BUP messages with fixed period of 15 seconds. The module receives data from watermeters in regular ”receiving windows”... -
Page 5: Hardware Features And Power Supplying
Access Point of GSM provider. Application server receives the messages and performs their decoding, storing and further processing. The NB-K430 module supports bi-directional communication and it is able to receive through the network messages of ”SET” type, generated by remote computer. These messages can be used for setting of module parameters from the remote server. -
Page 6: Technical Parameters Overview
Technical parameters overview Overview of NB-K430 module technical parameters is shown in the Table1 below. Table 1: Overview of NB-K430 module technical parameters RF subsystem parameters Frequency band 800 MHz (RX/TX) 791-821 / 832-862 Frequency band 850 MHz (RX/TX) 869-894 / 824-849... -
Page 7: Configuration Of The Nb-K430 Module
Configuration of the NB-K430 module Configuration parameters of the NB-K430 module can be displayed and changed from the common computer (PC) by one of these methods: - with using of USB-CMOS” converter and configuration cable connected to the module; ”... -
Page 8: Setting Of Nb-K430 Module Parameters By Configuration Cable
Setting of NB-K430 module parameters by configuration cable In following part of the document there is a description of these parameters of the NB-K430 module, that can be displayed and examined from PC connected to the module by configuration cable. Some of the parameters can be changed by configuration commands entered... - Page 9 : Show this help Overview of configuration parameters with short description of their meaning can be also found in table on the page 21. The meaning of individual parameters and detailed description of their usage can be found below. NB-K430...
-
Page 10: System Commands" Group For Control Of Module Basic Functions
The ”uptime” parameter value shows the time interval passed from the last device reset in seconds so that the exact moment of the last module reset can be recognized by this parameter. The parameter is of read only” type. ” Example: cfg#uptime Uptime 0d, 0:13:26 mon# NB-K430... -
Page 11: Configuration" Group Of Commands For Writing Of Configuration
”deb”, ”ta”, ”mb”, ”du addr”, ”rw addr”, ”rb addr”, ”rd addr”, ”sw addr val”, ”sb addr ” val”, ”tshort”, ”tlong”, ”port”, ”ppm” and ”at” are used for troubleshooting and repair of the device in a factory. Manufacturer strongly recommends not to use these commands during common operation. NB-K430... - Page 12 Recv ID 130551474, Val 8, status 0, rssi -81, prev 0:01:00 ago Recv : 00 51 07 c8 0e b3 68 68 68 68 68 9e 2b 1d .Q..hhhhh.+. Recv ID 130551475, Val 0, status 0, rssi -63, prev 0:01:00 ago mon#mr 0 Receive 0 mon# NB-K430...
- Page 13 The ”Set Sensus meter ID” variable serves for setting of list of Sensus iPERL watermeters, that is intended to be read by the NB-K430 module. Each record to the list could be created by using of ”sid [index] [value]” command, where meter ID (serial number) is linked with meter index (0 - 9).
-
Page 14: Mask")
”mask” table (see figure 2), where there are different masks in different rows (one mask in one row) and all transferred information of one particular mask are marked by ”1” in corresponding column. Figure 2: Table for selection of message content ( mask”) ” NB-K430... - Page 15 ID) and ”Alarm” (Sensus Alarm Flag) values, without RSSI value. This setting will determine message content as it is described in detail in paragraph The NB-K430 module data messages”. Values of watermeter counters are ” always transferred, they cannot be removed from the message.
- Page 16 - APN) should be entered to the module configuration by using of ”apn” command. APN is assigned by GSM operator. Setting of APN can be deleted by entering of ”.” value (dot). Example of setting of APN-name to ”cms.softlink” value: NB-K430...
- Page 17 Setting of both parameters should be reasonable compromise between energy consumption and reliability of message delivery. As the NB-K430 module can broadcast not only current values, but also historical” values from internal memory, ”...
-
Page 18: Displaying Of Other Operational Entries In The List Of Parameters
Session count : 1 Session timeout : 172664 sec - 1d, 23:57:44 Modem IMEI : 867724031580613 SIM CCID : 89882390000036330010 SIM IMSI : 901288001028645 Last RSSI : -79 dBm Conf. version : 19 SW version 1.01, date Apr 1 2020 NB-K430... - Page 19 In the ”Conf. version” row there is a current version (number) of configuration set, that increases with each storing of the configuration into the FLASH memory. The number is cleared by erasure of FLASH memory. In the ”SW version” row there is a module software version and release date. NB-K430...
-
Page 20: Setting Of Parameters By Using Of Optical Converter
Any changes in module’s settings can be performed in Module configuration table that opens by click on the Read device” button in WACO OptoConf” program window. View of configuration table is depicted in figure 3. ” ” Figure 3: NB-K430 module configuration table NB-K430... -
Page 21: Commands For Setting Of Message Broadcasting System
Value of this parameter displays only in this configuration table. The ”Sensus ID” is a list of Sensus iPERL watermeters, that are intended to be read by the NB-K430 module. It contains 10 editable fields (index 1 - 10), where watermeter IDs (serial numbers) can be preset. Any received messages. -
Page 22: Basic Forms Of Nb-K430 Module In " Softlink Configurator" Application . . . . . . . . . . . . . . 19
In the figure there is an identification form of NB-K430 module (bordered by grey colour), administration form (bordered by blue colour) and form for basic module setting (bordered by red colour). -
Page 23: Remote Setting Of Module Parameters Through The Nb Iot Back Channel
NB-IoT network uses standard Internet Protocol (IP) that naturally enables data communication in both direc- tions. The NB-K430 module can use bi-directional communication for setting of its parameters from so called ”back channel”, that is (for the reason of saving battery) opened only during two second period after transmit- ting of each message (INFO, TRAP, or RESPONSE). -
Page 24: Overview Of Nb-K430 Module Configuration Parameters
3.3.1 Overview of module configuration parameters Overview of configuration parameters that can be used for user settings of the NB-K430 module is shown in the Table below. The parameters are presented in the same order as they appear in the List of all configuration parameters (see paragraph 3.1.1). -
Page 25: The Nb-K430 Module Data Messages
3.4.1 Structure and types of data messages The NB-K430 module is intended for wireless reading of Sensus iPERL watermeters and sending of read data to the superior system via NB-IoT services of GSM operator. NB-IoT service utilizes for transfer of messages packets (datagrams) of UDP protocol (UDP = User Datagram Protocol), that is a transport layer of the Internet Protocol (IP). -
Page 26: Description Of Info Message
Sequence No unique message number Temperature Processor temperature in 0.1 C Voltage Battery voltage in mV 3765 RSSI Last RSSI value Input value 1 Current status of watermeter 1 1996 Input value 2 Current status of watermeter 2 12887 NB-K430... -
Page 27: Description Of Trap Message
3.4.3 Description of TRAP message Messages of TRAP type are used for immediate transmitting of information about event detected by the NB-K430 module. The information contains type of detected event (e.g. ”Processor temperature exceeded limit”) that can be followed by one or several variables with parameters of the event (e.g. ”Temperature” and ”Temperature limit”). -
Page 28: Encryption Of Messages
Type of detected event is encoded into the ”Alarm code” variable (OID 60 - TRAP CODE), where value of variable determines event type. Current version of the NB-K430 module supports sending of one type of event - information about the module reset, with additional information about its cause. -
Page 29: Operational Conditions
Operational conditions This section of the document describes basic recommendations for transportation, storing, installation and operation of NB-K430 radio modules. General Operation Risks The radio modules are electronic devices power-supplied by internal batteries. The modules read counters or registers of the connected consumption meters. -
Page 30: The Condition Of Modules On Delivery
As NB-IoT services are charged by GSM operator, it is recommended to insert SIM and activate the service just before module installation. Safety precautions Warning! Mechanical and electrical installation of the NB-K430 module can be provided only by a person with necessary qualification in electrical engineering. Environmental protection and recycling The equipment contains non-rechargeable lithium battery. -
Page 31: Set Of Nb-K430 Module Components With Stick Antenna
Figure 7: Set of NB-K430 module components with stick antenna In the figure there is displayed the detail of NB-K430 module printed circuit board with configuration connec- tor marked by red colour, SIM-holder by violet colour, antenna connector marked by blue colour and battery switch marked by green colour. -
Page 32: Module And Meter Replacement
Always pay attention to the completing of the correct cap with the correct base of the module, that is the reason why it is always necessary to replace the whole NB-K430... -
Page 33: Module Dismantling
4.10 Operation of the NB-K430 module The NB-K430 module performs readings of watermeters and broadcasting of radio messages fully automatically. The greatest risks of permanent breakdown of module broadcasting are commonly caused by human activities within the installation site, especially mechanical damage of the module, excessive humidity or water inundation, or shading the RF signal by metallic object due to building operations. -
Page 34: Troubleshooting
The risk of premature battery discharge could be eliminated by respecting the instructions described in para- graph 4.1.2. Troubleshooting Possible causes of module failures If during operation of NB-K430 module some anomaly, malfunctions or other troubles are recognized, the possible causes of the failures can be classified by following categories: 5.1.1 Power supplying failures The module is supplied by electrical power from the long-life internal battery. -
Page 35: Power Supplying Failures
To identify a reason of device failure or any anomaly in its operation follow this procedure: 1. No data are available from any watermeter read by the NB-K430 module. In this case it is recommended to check functionality of the module subsystems in following order: check correctness of setting of the module in the central system database;... -
Page 36: Additional Information
ID and index in the table of read watermeters in the NB-K430 module configuration; check functionality of receiving of BUP messages from watermeters as described in paragraph 5.1.4...
