Relay PRO UNIT B Overview The Sure-Fi DS010-RELAYPRO system consists of two factory paired units that are ready to use with no configuration required. The Relay PRO UNIT A Interface wires to the Control Panel and communicates wirelessly to the Relay PRO UNIT B Interface, which is placed out at the peripheral and any relay/switch activated device. -
Page 6: General Specifications
Sure-Fi Relay PRO Bridge General Specifications Operating Voltage: 12 to 30V AC/DC Operating Current (@ 24VAC): 0.02A (idle), 0.26A (transmit) Operating Power (@ 24VAC): 6.3VA (peak) Relay Inputs (R1IN – R8IN): Dry contact or digital 0 to 3.3VDC/5.0VDC interface Relays 1 & 2: Two Form C Mechanical Relays, 5A 220VDC / 250VAC Relays 3 –... -
Page 7: Device Overview, Relay Pro Unit A
Sure-Fi Relay PRO Bridge Device Overview Figure 1: Overview, Relay PRO UNIT A Interface SURE-FI, INC. | www.sure-fi.com... -
Page 8: Device Overview, Relay Pro Unit B
Sure-Fi Relay PRO Bridge Device Overview Figure 2: Overview, Relay PRO UNIT B Interface SURE-FI, INC. | www.sure-fi.com... -
Page 9: Unit A - Top & Bottom Connector Pin Descriptions
Sure-Fi Relay PRO Bridge Relay Pro UNIT A Interface connectors Table 1: Top Edge UNIT A connector P1. See Figure 1 for connector location and pin numbers CONNECTOR POSITION NAME DESCRIPTION R2A NC Relay 2A Normally-Closed terminal R2A COM Relay 2A Common terminal... - Page 10 Sure-Fi Relay PRO Bridge Relay Pro UNIT A connectors (cont.) Table 3: Bottom Edge UNIT A connector P3. See Figure 1 for connector location and pin numbers CONNECTOR POSITION NAME DESCRIPTION +VIN + VDC input or VAC input -VIN - VDC input or AC common input...
-
Page 11: Unit B - Top & Bottom Connector Pin Descriptions
Sure-Fi Relay PRO Bridge Relay Pro UNIT B Interface connectors Table 5: Top Edge UNIT B connector P1. See Figure 2 for connector location and pin numbers CONNECTOR POSITION NAME DESCRIPTION R2B NC Relay 2B Normally-Closed terminal R2B COM Relay 2B Common terminal... - Page 12 Sure-Fi Relay PRO Bridge Relay Pro UNIT B connectors (cont.) Table 7: Bottom Edge UNIT B connector P3. See Figure 2 for connector location and pin numbers CONNECTOR POSITION NAME DESCRIPTION +VIN + VDC input or VAC input -VIN - VDC input or AC common input...
-
Page 13: Relays
Sure-Fi Relay PRO Bridge Relays Operating the relays The relay outputs are operated by the corresponding relay inputs that are on the paired unit. For example, to energize Relay 1A on UNIT A, the Relay 1A input (R1A IN) on the UNIT B must be shorted to ground (0VDC) using a dry contact switch (relay closure, push-button, etc.), or a digital voltage 0 to 3.3VDC or 0 to 5VDC... -
Page 14: Mounting
Sure-Fi Relay PRO Bridge Mounting DIN Rail mount DIN rail mounting allows the unit to easily clip and unclip from the DIN rail. Attach a piece (minimum 5” length) of 35mm type DIN rail to the wall and then snap the unit to the DIN rail or slide it on from the end. - Page 15 Sure-Fi Relay PRO Bridge Figure 10: The top screw is shown mounted through the DIN clip to the wall: The bottom screw is shown mounted through the black DIN clip to the wall: Figure 11: SURE-FI, INC. | www.sure-fi.com...
-
Page 16: Sure-Fi App - Downloading, Installing, Connecting
A data connection must be available on the device (phone) that the Sure-FI App is running on. Be sure that the App remains connected to the Bridge unit during the update process which usually takes a couple minutes to complete. -
Page 17: Sure-Fi App - Setting System Heartbeat, Relay Defaults And Timeout
Sure-Fi App. In that case, the unit will set the output values as configured when the set time interval is reached. -
Page 18: Troubleshooting
Sure-Fi Relay PRO Bridge Troubleshooting Testing Range and RF communications Press and release the ‘Test’ button on one of the units and observe the six Signal Strength LEDs. If any of the blue LED 1 through LED 6 lights up momentarily then the transmission between the two units was successful. -
Page 19: Fcc And Industry Canada Regulatory Statements
Sure-Fi Relay PRO Bridge FCC and Industry Canada Regulatory Statements This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 20: Warranty
INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING INJURIES TO PERSONS OR PROPERTY, TO BUYER, ITS EMPLOYEES OR AGENTS, AS A RESULT OF THE SALE. BUYER ALSO AGREES TO HOLD SURE-FI, INC. HARMLESS FROM ANY CLAIMS BUYER, OR ANY THIRD PARTY, MAY HAVE AS A RESULT OF BUYER’S USE OR DISPOSAL OF THE GOODS.
