German pool IRT-S1 User Manual

L I N T R E M O V E R
Accessory of USB Portable Travel Iron IRT-S1
U SE R M A N U A L
Please read these instructions and warranty information carefully before use
and keep them handy for future reference.
SAFETY INSTRUCTIONS
1. Never rinse the body with water, nor use it in the bathroom. Otherwise, it
will not function properly.
2. When charging or using the device, if you notice any abnormal situation such
as smell, temperature, or sound, cut off electricity immediately and stop
charging or using it.
3. Keep the device in a dry place, away from moisture.
4. When using the device, do not remove the body cover and other parts.
PRODUCT INTRODUCTION
This product is suitable for removing pills and fuzz balls from different kinds of
clothing items, such as wool cardigans, polyester clothing, sofa covers, curtains
and carpets, etc.
Note! This product is used in conjunction with the power bank, as part of the
mobile series. It cannot be used on its own.
PRODUCT STRUCTURE
1. Magnetic Connector
2. Body 1
3. Body Cover
4. Inner Cover
2
5. Safety Shaft
6. Fan Blade
3
7. Blade Rest
8. Mesh Cover
OPERATING INSTRUCTIONS
1. Lint Remover is used in conjunction with the Power Bank Handle*, as part of
the mobile series.
2. Hold and press down the button; the device goes to Speed Level 1
automatically. Place garment flat on the table, put the mesh plate of the
device touching the garment and move back and forth gently. Be careful
where the hairball form knots so as not to damage the fabric.
3. This device has 3 levels of speed available, Level 1 with 1 light, Level 2 with
2 lights and Level 3 with 3 lights.
4
5
CLEANING
6
1. Turn off the device, unscrew the body cover.
7
2. Get rid of the lint and hairballs in the area.
3. Unscrew the mesh cover. Use a clean brush to clean the mesh cover and
the inside compartment. Get rid of any debris and dirt.
8
4. Screw back the mesh cover and the body cover in place.
*Power Bank Handle not included
TECHNICAL SPECIFICATIONS
產品規格
Model No. IRT-S1
型號
Power Bank Handle*
Voltage 5 V
電壓
Dimensions 機身尺寸 (W) 73 x (D) 83 mm
Lint Remover
Net Weight 138 g
淨重
Specifications are subject to change without prior notice.
If there is any inconsistency or ambiguity between the English version and the
Chinese version, the Chinese version shall prevail.
Refer to www.germanpool.com for the most up-to-date version of the User Manual.
產品規格及設計如有變更，恕不另行通知。
中英文版本如有出入，一概以中文版為準。
本產品說明書以www.germanpool.com網上版為最新版本。
IRT-S1_M_19(1)
