Chauvet Q-Mix Supplementary Manual

DMX Channel Values

D
EFAULT
1
2
Q-Mix User Manual
V
ALUE
Gobo
000 005 Blackout
006 039 Strobe: Slow > Fast
040 045 Open
046 051 Gobo 1
052 057 Gobo 2
058 063 Gobo 3
064 069 Gobo 4
070 075 Gobo 5
076 081 Gobo 6
082 087 Gobo 7
088 093 Gobo 8
094 099 Gobo 9
100 105 Gobo 10
106 111 Gobo 11
112 129 Open
130 135 Gobo 1 Bounce™: Slow > Fast
136 141 Gobo 2 Bounce™: Slow > Fast
142 148 Gobo 3 Bounce™: Slow > Fast
149 153 Gobo 4 Bounce™: Slow > Fast
154 159 Gobo 5 Bounce™: Slow > Fast
160 165 Gobo 6 Bounce™: Slow > Fast
166 171 Gobo 7 Bounce™: Slow > Fast
172 177 Gobo 8 Bounce™: Slow > Fast
178 183 Gobo 9 Bounce™: Slow > Fast
184 189 Gobo 10 Bounce™: Slow > Fast
190 196 Gobo 11 Bounce™: Slow > Fast
197 225 Open
226 255 Scroll: Slow > Fast

Gobo Wheel Rotation

000 005 Static
000 005 Rotation Counter-Clockwise: Slow > Fast
000 005 Static
000 005 Rotation Clockwise: Slow > Fast
13
F
UNCTION
Appendix
2007-04-06/18:29
