Twilight BL-BGD306 Operation Instruction Manual

Impact tester
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
Impactómetro tipo ISO Sistema Métrico e Inglés
BL-BGD306

Advertisement

loading
Need help?

Need help?

Do you have a question about the BL-BGD306 and is the answer not in the manual?

Questions and answers

Related Manuals for Twilight BL-BGD306

Summary of Contents for Twilight BL-BGD306

  • Page 1 Impactómetro tipo ISO Sistema Métrico e Inglés BL-BGD306...
  • Page 2 BGD 306 Impact Tester Operation Instruction...
  • Page 3 1.0 Introduction BGD 306 Impact Tester is used for testing the impact resistant performance when the coating such as paints, varnish and other relative coating get impact and deformed under the standard conditions. This instrument conforms to ISO 6272-1 ： 2002 《 Paints and varnishes--Rapid-deformation （ impact resistance）...
  • Page 4 Indenter 2kg additional weight 1kg additional weight Metal Base Ring φ27mm die Guide Tube: black alumina, around 1.2m in length; there is a notch with graduation. Height limit ring: black nylon ring, when making test, slip it into the tube and move up and down to adjust the the falling height, then fix it on the tube with the screw.

  • Page 5: Installation

    4.0 Procedure 4.1 Preparation of test panels 4.1.1 Substrate Unless otherwise specified, the substrate should conforms to the requirement of ISO1514. The panel should be planar, free from distortion and at least 0.25mm thick. The dimensions shall be allow the test to be carried out at least five different positions not less than 40mm from each other and not less than 20mm from the edge of the panel.
  • Page 6 After placing test panel, the top of the weight handle is at the zero mark 4.3 Procedure 4.3.1 Environmental requirements Before testing, condition the coated panels at a temperature of （23 ± 2） °C and a relative humidity of （50 ± 5） % （or at another temperature and humidity, agreed between the interested parties, from those specified in ISO 3270 ）...
  • Page 7 position by means of the clamping sleeve. 4.3.3.4 Lift the weight to the height limit ring, and let it fall on to the test panel. 4.3.3.5 Remove the test panel from the apparatus and examine the deformed area with the lens for coating cracks and/or peeling from the substrate.

  • Page 8: Packing List

    the test. Smear some preservative oil if not use in a long period of time. 6.0 Maintenance & After service Biuged offers 1 year after service（from the day of delivery） to all our products free of charge, and offers repair and calibration service for their whole life. A.
