Implements Pty Ltd
OPERATOR'S MANUAL
PRODUCT NO.
0043
0044
0045
0046
0138
0139
0342
0343
0344
130 FRANKSTON/DANDENONG RD, DANDENONG SOUTH, VIC. 3175 AUSTRALIA
John Berends
AGRICULTURAL ENGINEERS
PARTS LIST
Stick Rakes
6' Stick Rake bottom only
7'6" Stick Rake bottom only
9' Stick Rake bottom only
10'6" Stick Rake bottom only
Fixed Top
Offset top
7'6" Stick Rake complete with toolbar linkage – 15 tines
9' Stick Rake complete with toolbar linkage – 19 tines
10'6" Stick Rake complete with toolbar linkage – 21 tines
PHONE (03) 9791 2494
www.johnberendsimplements.com.au
FAX NO. (03) 9794 5568
Advertisement
Table of Contents
Summary of Contents for JBI 0043
- Page 1 John Berends Implements Pty Ltd AGRICULTURAL ENGINEERS OPERATOR’S MANUAL PARTS LIST Stick Rakes PRODUCT NO. 0043 6’ Stick Rake bottom only 0044 7’6” Stick Rake bottom only 0045 9’ Stick Rake bottom only 0046 10’6” Stick Rake bottom only 0138...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Page No. SAFETY FEATURES..................... 3 SAFETY INSTRUCTIONS................... 6 ASSEMBLY......................7 OPERATION......................7 MAINTENANCE...................... 8 SPARE PARTS....................... 8... - Page 3 SAFETY Farm machinery is dangerous if operated incorrectly so please read this manual in its entirety prior to operating the machine. No operator, however experienced in farm machinery operation, should attempt to use any machine they have not been competently trained to use. Your local Department of Agriculture can help you with training, as can most Occupational Health and Safety offices, Agricultural schools and colleges and farm equipment dealerships.
- Page 4 If machine starts to vibrate, stop tractor using method as described in the operation section After striking a foreign object or if the there are doubts about the performance of the machine, stop the tractor as described and check if machine is making excessive noise. Extreme caution must be taken when working in public areas (roadsides etc).
- Page 5 INTRODUCTION: This manual was developed specifically for the machine you have purchased. The information within is to assist you in preparing, operating and maintaining your machine. Please read and understand the contents of the manual completely before attempting to operate your machine, paying special attention to all safety details.
-
Page 6: Safety Features
Safety Features 1. SERIAL NUMBER (Decal) 2. WARNING DECAL 3. BERENDS DECAL... -
Page 7: Assembly
ASSEMBLY Line the lower linkage arms between the lower linkage plates of the stick rake top, slide the linkage pins through the holes and secure with linch pins. Attach the top link to the stick rake. It may be helpful to support the linkage at the right height with a stable block or similar. Sway chains or bars should be used to prevent the machine swinging around in use. -
Page 8: Maintenance
Turning Lift the stick rake off the ground. Never turn before the tines are completely free from the soil, otherwise the inner most tines will be forced sideways and backwards. Alternatively a large wide sweep can be taken providing the tines never move backward. Reversing Never reverse with the tines in the soil, but make sure the rake is fully raised. - Page 9 Stick Rake (0044-0046, 0342-0344) Key No. Part No. Quantity Description 1670 Tine with point 32 x 10 3849 Clamp bracket, bolt/nut/sw to fit 1670 to 50 x 50 frame 1678 Reversible point 1684 Lucerne or grass point (optional) 1686 Plough bolt/nut 3850 7’6”...
