Kitvision JB 3822 User Manual

Bluetooth Selfie Stick
User Manual
Please read this manual carefully before use.
Box Contents
• Bluetooth Selfie Stick
• Micro USB cable
• Phone holder
Functions
1. Phone holder
2
2. ¼" tripod screw
3. Tripod screw dial
4
4. Bluetooth Selfie Stick head
5. Head side-screw
6. Telescopic section
6
7. Rubber grip
8. Camera remote button
9. LED indicator
10. Micro USB port
8
11. Power switch
10
Charging
1. Using the micro USB charging cable, connect the micro USB connector
1
to the micro USB port (10) on the base of the Bluetooth Selfie Stick
and the other to a PC USB port or USB mains charger.
2. The LED indicator (9) will illuminate solid red on the base whilst charging.
3. When fully charged the LED indicator (9) will turn off.
Operation
3
1. Turn the Bluetooth Selfie Stick on by sliding the power switch (11)
to the ON position.
5
2. Make sure your smartphone is turned on and Bluetooth is activated
3. Open the Bluetooth settings on your smartphone and connect to
'KV Selfie Stick'.
4. Open your smartphone's camera application.
5. Place your smartphone in the provided phone holder, ensuring it is
7
well secured.
6. Attach the phone holder to Bluetooth Selfie Stick by screwing it onto
the ¼" tripod screw (2), tighten fully using the tripod screw dial (3).
7. Adjust the tilt of the Bluetooth Selfie Stick head (4) to gain the
desired angle and tighten using the head side-screw (5).
8. Extend the Bluetooth Selfie Stick by pulling the telescopic section
outwards (6)
9. Press the camera remote button (8) to take a photo.
10. Slide the power switch (11) to the OFF position to turn the Bluetooth
Selfie Stick off when finished.
9
11
OFF ON
