Summary of Contents for Monaghan GPS 400
- Page 1 User Guide GPS 400 GPS Receiver August 20, 2018 Version 1.00 Monaghan Engineering 862 Las Colinas Drive Dripping Springs, TX 78620 USA Telephone: 1-512-858-4271 Facsimile: 1-512-858-1355 http://www.monaghan-engineering.com Email: techsupport@monaghan-engineering.co...
- Page 2 Document Revisions Version Date Document Changes Number 8/20/2018 1.00 Preliminary Draft All trademarks and registered trademarks are the property of their respective owners. Subject to change without notice. © Monaghan Engineering, Inc. 2018 All Rights Reserved monaghan + ENGINEERING GPS 400...
- Page 3 3.3 Environmental Characteristics ........................... 5 3.4 Acquisition Times ..............................5 3.5 Accuracy ..................................5 3.6 Size ....................................5 3.7 Weight ................................... 5 3.8 Case Material ................................6 3.9 Mounting ..................................6 3.10 Cable Connector ................................ 6 monaghan + ENGINEERING GPS 400...
- Page 4 60529 IPX7, immersion in 1 meter of water for 30 minutes. Installation is simple. All that is required is for the GPS 400 to have a clear view of the sky. It can connect directly to either a PME GPS 0100 Network Time Serve or a ProTime GPS Clock.
- Page 5 0.1 knot RMS steady state • PPS Time: +/- 1microsecond at rising edge of PPS pulse 3.6 Size • 3.58” (91 mm) diameter, 4.44” (113 mm) high 3.7 Weight • 16.4 oz. (500 g) with 10 foot cable monaghan + ENGINEERING GPS 400...
- Page 6 30 minutes) 3.9 Mounting • 1”-14 thread Marine antenna mount 3.10 Cable Connector • Industrial Ethernet • IP 67 Rated • May be panel mounted • Amphenol LTW part number RDP-00BFFA-SLM7001 monaghan + ENGINEERING GPS 400...
