Ultra-Portable IP Audiocodec that is easy to configure and use
Optimized for OPUS encoding algorithms
Firmware Versions:
Software Version:
App Version:
USER'S MANUAL
ED. 04/21
V. 1.1 - 11/05/2021
CPU 9.30 / DSP 3.35 or higher
AEQ ControlPHOENIX 2.2.1.47 or higher
AEQ TALENT PILOT 1.0.2 or higher

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TALENT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AEQ TALENT

Summary of Contents for AEQ TALENT

  • Page 1 Ultra-Portable IP Audiocodec that is easy to configure and use Optimized for OPUS encoding algorithms USER’S MANUAL ED. 04/21 V. 1.1 - 11/05/2021 Firmware Versions: CPU 9.30 / DSP 3.35 or higher Software Version: AEQ ControlPHOENIX 2.2.1.47 or higher App Version: AEQ TALENT PILOT 1.0.2 or higher...

  • Page 2: Table Of Contents

    3.7. Call control keys....................... 14 3.8. Microphone ON / OFF (MUTE) key................. 14 3.9. Status indicators....................... 14 4. CONFIGURATION AND OPERATION OPTIONS FROM "AEQ ControlPHOENIX" REMOTE CONTROL SOFTWARE......................15 4.1. Individual codec control window..................15 4.1.1. CONFIGURATION Menu..................17 4.1.2.
  • Page 3 5. CONFIGURATION AND OPERATION OPTIONS FROM "AEQ TALENT PILOT" REMOTE CONTROL APPLICATION......................37 5.1. Downloading "AEQ TALENT PILOT"................37 5.2. Running "AEQ TALENT PILOT" for the first time............37 5.3. Main Screen........................38 5.3.1. Upper area......................39 5.3.2.
  • Page 4 Application note AN1....................... 74 Application note AN2....................... 74 Application note AN3....................... 74 Application note AN4....................... 74 Application note AN4B....................74 Application note AN5....................... 74 Application note AN6....................... 74 APPENDIX E: TALENT TROUBLESHOOTING GUIDE............75 APPENDIX F: ADDITIONAL INFORMATION................80 TALENT...

  • Page 5: Introduction

    TALENT. It is also possible to control the unit using "AEQ TALENT PILOT" App for Android and iOS, • running on a Bluetooth-linked smart device. It is also possible to transfer audio between a smart device and TALENT audiocodec.

  • Page 6: Available Encoding Algorithms

    AEQ offers the "SmartRTP" call initiation protocol in order to greatly simplify the operation of the audiocodec. AEQ also offers two SIP servers free of charge as a standard service for the users of Phoenix ALIO. One of them is configured as main and the other is provided as a backup.

  • Page 7: Audio Routing

    G722 (64 Kbps, low delay, 7 KHz audio bandwidth). • AEQ-LD with Fs=16, 32 or 48 KHz, mono or stereo. Available bit rates between 64 and • 384 Kbps, audio bandwidth between 7 and 19 KHz. MPEG 1 and 2 - LII, with Fs between 16 and 48 KHz, mono, stereo, dual channel and •...

  • Page 8: Compatibility With Third-Party Codecs

    IP networks. Therefore it is possible to connect TALENT with any codec from other manufacturer over IP provided that this unit has been developed according to N/ACIP (please check third-party codecs technical specifications).

  • Page 9: Physical Description Of The Unit

    First of all, it is necessary to become familiar with the connectors and other elements present in the back and right panels of the unit, in order to understand the wiring and installation required to use TALENT. 2.1. Description of the right panel and connections.

  • Page 10: Description Of The Back Panel And Connections

    8.8.8.8 DNS server, without further alteration. 3) If, the push-button is held until the unit beeps three times and then released, after a different triple confirmation tone it will perform a full FACTORY CONFIGURATION RESET, although ONLY the following parameters will remain unchanged: TALENT...

  • Page 11: Ethernet Port

    2.2.4. Ethernet port. TALENT features one Ethernet port. Using this port, the unit can be connected to a LAN or WAN network and send / receive audio over IP. This port is also used to configure and administrate the unit from one or more computers using the remote control software.

  • Page 12: User Interface Description. Manual Control

    3. USER INTERFACE DESCRIPTION. MANUAL CONTROL. Configuration and operation of the TALENT unit can be done locally either using the controls and indicators featured in the front panel, locally using "AEQ TALENT PILOT" App or remotely, using the "AEQ ControlPHOENIX" application (Control and Configuration software for AEQ TALENT, Phoenix STRATOS, STUDIO, MERCURY, VENUS, VENUS V2, VENUS V3 and ALIO audiocodecs).

  • Page 13: Help" Key

    This key sends a notification to the remote control software provided that this is in use. This way, a TALENT user that requires assistance or has doubts can ask the operator that is remotely controlling or monitoring the unit with the "AEQ ControlPHOENIX" software for help.

  • Page 14: Call Control Keys

    Phone). The red color is associated to the control link: so if the unit is paired both for audio and control (TALENT Pilot App is connected), this indicator will look steady pink, while if it is only paired for control it will blink between red and pink.

  • Page 15: Configuration And Operation Options From "Aeq Controlphoenix" Remote Control Software

    The individual codec control window is thoroughly described in chapter 6 of "AEQ ControlPHOENIX" user’s manual. The screen corresponding to TALENT is as follows: The name assigned to the device can be seen in the lower area of the window ("AEQ 03" in this example), as well as the corresponding URI.
  • Page 16 When it is green, clicking on it opens the call window (see section 6.6 of "AEQ ControlPHOENIX" user’s manual). When it is red, clicking on it hangs up the current call, after asking for confirmation:...

  • Page 17: Configuration Menu

    "Config Mix" button. The amplifier symbols at the inputs are filled in red colour when they are ON air, in order to ease quick identification of the audio routing at a glance. TALENT...

  • Page 18: Mixer Control Window

    Other configuration menu options are "Contacts" (call book management), "Ethernet" (device IP configuration), "Miscellaneous" (several adjustments) and "Network" (other network functions parameters). Details about these menus are provided in chapter 6 of "AEQ ControlPHOENIX" user’s manual. Just click on the button again to close this menu.

  • Page 19: Vumeters Window

    However, the maximum number of vumeters that can be simultaneously displayed can be altered in the "Remote connection" tab of "General Application Values" (see section 5.1.9.1 of "AEQ ControlPHOENIX" user’s manual). The vumeters represent the transmitted audio level to the L and R channels, and the received L and R channels from the communications channel.

  • Page 20: Connection Modes

    "SmartRTP" can be activated in both involved audiocodecs (provided that they are AEQ Phoenix units compatible with this mode). This way, the call can be established from one end only (and thus, we only need to know the IP address and ports of one of the communication ends).

  • Page 21: Proxy Sip

    "SmartRTP". 4.2.2. PROXY SIP. This type of connection is selected when the TALENT is used working together with an external SIP server that will provide connection with remote unit through any network, even Internet, without caring about IP addresses. Both units (local and remote) must be registered in the same SIP server, which function is to maintain a database with the registered codecs, storing their connection parameters (IP address, audio ports…) in order to ease the task of making calls...
  • Page 22 Authentication: enables you to edit the password and security information for the user profile associated with the unit in the previously selected SIP server. By default, the data configured in this field in order to use AEQ server are the following: User: the "User Name"...

  • Page 23: Direct Sip

    You can access the IP configuration submenu for DIRECT SIP mode by clicking on "I/F Setup" button, and that it is explained in section 6.1.4.2 of "AEQ ControlPHOENIX" user’s manual. In "SIP Parameters" submenu you can find: •...

  • Page 24: Sending Audio To Multiple Destinations: Broadcast, Multicast And Multi-Unicast

    Multiple-unicast: TALENT units can send the same RTP stream to several different IPs by replication of the encoded audio. This can traverse switches and routers in the same way it...
  • Page 25 The OPUS MUSIC STEREO 48 KHz / 64 Kbps mode will be used in this example, configuring the contact to issue replicas to 2 different IP/Port pairs (we have used the "New Replica" button in order to do that). Detail of the creation of RTP replicas within a General agenda contact TALENT...
  • Page 26 TALENT will stop sending replicas as soon as the call is manually hung. The list will be erased from the unit and the only way to send them again is to call selecting the same contact.

  • Page 27: Nat Traversal

    TALENT offers a total of six different operating modes when traversing devices with NAT (routers, firewalls…). Each one of those modes is suitable for a different scenario. For instance, when the units that are establishing communication are in the same local network, the internal working way will be different than when it’s done through the Internet.

  • Page 28: Operation Without Nat: "Off (There Is No Nat)

    AEQ PHOENIX AUDIOCODECS. APPLICATION NOTE 0 - C (Connecting AEQ Phoenix units through Internet. Complex scenario configuration. Through LOCAL network(s), DHCP not used, manual NAT. Making use of AEQ Proxy SIP). The eight parameters to be configured in the dialog for this mode are: 1.

  • Page 29: Auto 1 (Local Network Audio)

    This mode will be used primarily when two units that are in the same local network need to communicate with each other, when a Proxy SIP on the Internet is used, it’s not the one provided by AEQ (sip.aeq.es) and only if the AUTO1 mode doesn’t work properly. 4.3.5. AUTO 3 (audio over internet).

  • Page 30: Auto 4 (Audio Over Internet)

    Adaptive Buffer Max/Fixed buffer length: this is the maximum size of the reception buffer. When it is defined as adaptive, TALENT will start to shorten it from this value as the network´s transmission quality allows. If it is defined as FIXED, this max value will remain, as the buffer’s size won’t be varied during the connection.
  • Page 31 4.5. Coding algorithm selection. See section 6.1.3.1 ("Coding selection") at "AEQ ControlPHOENIX" user’s manual. Although AEQ recommends the use of OPUS coding algorithms for most uses (several different modes are available to match almost any need), a coding selection window can be accessed by clicking on the "Select codec"...

  • Page 32: Ethernet Port Configuration

    After confirming, the equipment reboots and the communication re- establishes in approximately 15 seconds. If you have any doubts, please consult your IT network technician or directly contact AEQ or authorized distributors’ technical support department. 4.7. SNMP configuration.
  • Page 33 AEQ PHOENIX Audiocodecs (TALENT, Mercury, Venus, Studio, Stratos and ALIO) can connect to up to 3 SNMP clients, installed in remote PCs, by simply configuring their IP addresses in the "SNMP" tab of previous menu. Once one or more SNMP clients are connected and the corresponding "MIB"...

  • Page 34: Password Configuration

    MIB-II specification RFC1213 (http://tools.ietf.org/html/rfc1213 For more information, please consult section 7.7 of this manual and section 6.5.1 of "AEQ ControlPHOENIX" application manual. 4.8. Password configuration. Version 2.2.1.1 (or higher) of the application allows you to configure a numerical password of up to 4 digits required in order to be able to control the unit, by clicking on "User Password"...
  • Page 35 "Change input routing (MIC / Line in ON AIR)": allows or forbids the user to • change Input Routing from TALENT’s user panel. The restriction affects all 2 inputs. "Modify input level": allows or forbids the user to modify the inputs send level by •...
  • Page 36 "Change coding/profile (App only)": allows or forbids the user to change from • "AEQ TALENT PILOT" App the encoding or profile to be used in communication. On the other hand, the options of the local control interface that can be enabled/disabled are: "LINE IN/BT On Air =>...

  • Page 37: Configuration And Operation Options From "Aeq Talent Pilot" Remote Control Application

    You can always touch the red Refresh button at the bottom of the "Available Talent devices" screen if your TALENT is still not found or you forgot to turn it on. In case that several TALENT codecs are at reach, simply touch on the one you want to control (make sure that the serial number matches the one written at the back label of your device).

  • Page 38: Main Screen

    Once the App has linked to TALENT, the red light in the Bluetooth symbol of the device will be illuminated. So if the audio link is also paired, this indicator will have a pinkish color 5.3. Main Screen. Once the desired device is found and selected, after a few seconds the main App screen will be...

  • Page 39: Upper Area

    LINK indicator: • This symbol indicates that the TALENT device is currently linked to the App. If this symbol turns off, communications with it has been lost (for example, if the smart device is too far away, more than approx. 5 meters). The App will try to re-connect and, if impossible, it will give the user the possibility to retry or leave.
  • Page 40 "AEQ ControlPHOENIX" software running on local or remote PCs, if this button is touched, the effect will be the same as touching the corresponding TALENT’s physical HELP key: a pop-up window will appear in the software warning the operator that we are in need of assistance.

  • Page 41: Lower Area

    Bluetooth indicator: • When the Bluetooth symbol is blue, it means that TALENT is linked for audio (with this or any other smart device). Note that if the symbol is blue in the App, it will be pink on the device, since there will be control and audio connections simultaneously.
  • Page 42 CALL BOOK: Opens a call book stored in the TALENT device. • The management of this call book, which is saved into TALENT’s internal non-volatile memory, is carried out by means of "AEQ ControlPHOENIX" PC software. Contacts include a name and its dialling information. It is under the user’s responsibility to choose adequate contacts according to the communications mode selected at each moment (Proxy SIP, RTP, Direct SIP), as the call syntax varies from one to another.
  • Page 43 If we select Yes, TALENT will initiate a call. If successfully established, the CALL button will become steadily illuminated after a while, as will be the CONNECTED indicator.

  • Page 44: Audio Adjustments

    The slider at the right acts on the TELEPHONE output level, not on the auxiliary / Bluetooth input sensitivity level as in "AEQ ControlPHOENIX". This slider is useful to control the level of audio send by the phone, in case it is paired in A2DP and this function is used.

  • Page 45: Outputs Adjustment Menu

    "LINE IN" buttons have exactly the same source-selecting function for this output. If the MIC signal is sent to it, the indicator at the right of the right encoder will illuminate red when returning to the main screen, as will do the physical indicator by the corresponding encoder in TALENT’s front panel.

  • Page 46: Settings Screen

    This screen has three buttons: MODE: This button cyclically changes between the different communications modes: • Proxy SIP (PSIP), Direct SIP (DSIP) or RTP, each time we touch it: SETTINGS: This button gives access to different configuration options: • TALENT...
  • Page 47 (IP address, subnet mask, Gateway, DNS, DHCP on/off and selection of the outgoing control IP address). It is possible that all that information doesn’t fit the screen, so the lower options can be accessed by scrolling up with the finger: TALENT...
  • Page 48 When any of the values is modified, we can apply the changes by touching the "Save Changes" button, that will ask for confirmation: Once acceptance is provided, TALENT will reboot to apply the changes (unless the only modified field is "OUTGOING CONTROL TARGET IP ADDRESS", that doesn’t require the unit to be re-booted to be applied).
  • Page 49 & options menu), such as making calls, hanging them up, adjusting audio levels, etc. All these permissions will also affect "AEQ TALENT PILOT" App. Other permissions will affect the App only, like changing IP or SIP configuration, communications mode between RTP/PSIP/DSIP or coding algorithms/profiles.

  • Page 50: Quick Start Guide

    "AEQ_TALENT_BLE_<serial number>". Touch on its name and the App will connect to it. From then on, you have basic control of your TALENT from your mobile phone, and you will be able to make calls, configure audio routings and level, operating mode, and some more adjustments, with real-time control of the unit and total coherence with its physical controls.

  • Page 51: Connecting To A Network

    ControlPHOENIX" version to 2.2.1.47 or above in order to be able to control TALENT devices. Once your TALENT codec is found, please make sure that it has a green check at its left (otherwise, just click on it) and then click on "Add selected". The software will ask you for a name for that unit within the installation.

  • Page 52: Pairing For Audio Exchange

    6.5. Pairing for audio exchange. If you want to send music to your TALENT from mobile phones or PCs or make calls and send them to the Program, please pair it for audio.
  • Page 53 In order to do that, please activate Bluetooth in your phone, and when TALENT is on, search for a device called "AEQ_TALENT_<serial number>" (be aware that you don’t have to pair the device "AEQ_TALENT_BLE_<serial number>"), and pair it for Audio and Calls, accepting the confirmation requests that may appear.

  • Page 54: Control Terminal Over Web Browser

    ETHERNET, check the IP address associated with the Ethernet interface. 2. Power down theTALENT. 3. Connect TALENT to the PC from which you are going to perform the upgrading process using a crossed cable. 4. Power up the TALENT. 5. Open the Internet Explorer web browser and, in the address bar, enter HTTP://<IP address obtained in point 1>.

  • Page 55: Configuring The Ip Parameters And The Mac Address Associated With The Ethernet Interface

    ETHERNET, check the IP address associated with the Ethernet interface. 2. Power down the TALENT. 3. Connect TALENT to the PC from which you are going to perform the upgrading process using a crossed cable. 4. Power up the TALENT.

  • Page 56: Technical Service And On-Line Manuals

    7.3. Technical Service and on-line manuals. Clicking on the "Support" tab in the upper part of the screen will take you to AEQ website, where you will find all the information you need to directly contact the AEQ Technical Service, as well as all the technical information and manuals regarding the unit.

  • Page 57: Status Menu

    SNMP screen detail If you follow that link, the text file will appear. Now you just need to right-click on it and select "Save as…" and browse a suitable destination folder (see the manual of the selected SNMP client). TALENT...

  • Page 58: Remotely Rebooting The Equipment

    For more information, please consult section 4.7 of this manual and section 6.5.1 of "AEQ ControlPHOENIX" application manual. 7.7. Remotely rebooting the equipment. Sometimes a remote unit can work abnormally or become unreachable by the remote control software as a result of a communications error or in the unit itself. A method has been developed in order to remotely reboot the audiocodec, so normal operation is recovered.

  • Page 59: Technical Specifications

    -10 to +45 º C (14 to 114 º F) Weight 620 grs. Dimensions Width x Depth x Height: 130x195x45 mm. * Characteristics are subject to changes without previous notice. Safety regulations CE Marking. Electromagnetic compatibility according to EU directives EN 50081-1, EN 50052-2. TALENT...

  • Page 60: Warranty

    AEQ shall not be liable for loss of information in the disks or data support that have been altered or found to be inexact, neither for any accidental damage caused by the user or other persons manipulating the product.

  • Page 61: Appendix A: General Characteristics Of Encoding Modes

    For further information on this subject, consult: ISO/IEC 11172-3 and ISO/IEC 13818-3. AEQ LD+: AEQ proprietary mode (based on the previous AEQ-LD Extend mode) that combines the low delay offered by G.722 with the greater bandwidth of the MPEG modes, optimizing these two aspects.
  • Page 62 Available coding algorithms list in TALENT. Please contact us to check availability of other algorithms. Approx audio BW CODEC RATE (Kbps) Fs (KHz) Mode (KHz) VOICE RB VOICE MUSIC MONO RB OPUS MUSIC MONO MUSIC STEREO RB MUSIC STEREO MUSIC STEREO HQ G.711 A-law...

  • Page 63: Appendix B: Protocols Associated With Ip Communications

    Its operation passes through the following stages: request, establishment, file transfer and connection clear down. B1.1.1. Advantages: The transmission is made in real time. • Dedicated resources. The nodes that are involved in the communication use the • established circuit exclusively as long as the session lasts. TALENT...

  • Page 64: B1.1.2. Disadvantages

    Packet switching increases network flexibility and profitability. • The pathway a communication takes can be altered from one moment to the next (for • example, in case one or more of the routers breaks down). TALENT...

  • Page 65: B1.2.3. Disadvantages

    For all these reasons, the protocol selected to serve as a communication substrate in real-time applications is UDP. UDP Datagram TALENT...

  • Page 66: B2.1. Ip Addressing

    The unicast method is the one currently being used on the Internet, and is applied for both live and on-demand transmissions. The multicast method can only be used in corporate environments, despite some isolated efforts to introduce it on the Internet, and is applied only for live transmissions. TALENT...

  • Page 67: B3. Rtp Protocol

    Recovery of the reference clock based on information inserted by the transmitting • equipment. Test tools to permit the user to verify the bandwidth, the delay and estimated jitter in the • connection. RTP Header For complete information on RTP/RTCP protocol, we recommend consulting: http://tools.ietf.org/html/rfc1889 http://tools.ietf.org/html/rfc1890 http://tools.ietf.org/html/rfc3550 http://tools.ietf.org/html/rfc3551 http://tools.ietf.org/html/rfc3711 TALENT...

  • Page 68: B3.1. Default Talent Configuration

    B4.1. Working modes. With the PROXY SIP option activated in the TALENT, when the unit is started up it will automatically connect and register itself in the SIP Proxy server configured in its memory, indicating its name (URI: name@domain) and position (IP address).
  • Page 69 This working method, supported by external SIP servers, enables the physical position of a device to be made independent from its logic identifier and, through the use of the SIP protocol, makes it unnecessary to know more data regarding the called device than its URI. TALENT...

  • Page 70: B4.2. Possible Work Scenarios

    B4.2. Possible work scenarios. Depending on the kind of network TALENT is connected to, and leaving apart the trivial case where both involved devices are in the same local network, each unit will present a certain kind of IP address.

  • Page 71: B5. Stun Protocol

    Internet. TALENT includes a STUN client that sends a request to a STUN server. The STUN server then informs the client of its public IP and which port has been opened by NAT to permit incoming traffic to enter the client’s network.
  • Page 72 For complete information on the STUN protocol, we recommend consulting: http://tools.ietf.org/html/rfc3489 AEQ always has a PHOENIX unit available for test at "phoenixMaster@sip.aeq.es" URI and its 2 SIP servers are also available at sip.aeq.es and sip2.aeq.es and with warranty that both work according to the official standard. TALENT...

  • Page 73: Appendix C: Ports Used By Talent

    Port Forwarding must be made in the router for each one of the ports described in section 2 and for each one of the IPs of TALENT or Phoenix units installed in that private network. In that case, remote unit will send its packets towards router IP (it’s a public IP) and the ports configured in router by means of Port Forwarding (these are public ports), not to each TALENT or Phoenix ports (these are private ports).

  • Page 74: Appendix D: Application Notes Guide

    Phoenix Studio, Venus or Mercury audiocodec connected to a LAN (together with other IP devices), connected to Internet by means of a router with NAT that can be configured (or we have access to the Network Manager). SIP call using AEQ SIP Proxy. Application note AN0D.
  • Page 75 (5V at USB or 5-15V at DC IN). In case that you are supplying power to the TALENT using a USB cable, a blinking blue power LED means that the power source in use is not able to provide enough current (this may happen with certain laptops or small phone chargers), so you should select another power supply method.
  • Page 76 If you find problems with "AEQ TALENT PILOT" App, make sure that your TALENT unit is updated to CPU version 9.30 or above. You can check this in "AEQ ControlPHOENIX" under Config Miscellaneous Firmware versions. If your firmware is older, please contact AEQ Technical Service to get a free upgrade.
  • Page 77 AEQ audiocodecs). At your side, you only need to configure TALENT so it points to the proper studio’s public IP address for outgoing control. In order to do that, you have two alternatives: 1) Using "AEQ ControlPHOENIX"...
  • Page 78 E7. I am able to make a call but the "CONNECTED" indicator is blinking. If that’s your case, your TALENT is not receiving any audio data back from the remote end. If the unit is configured in RTP mode, this may mean that the remote codec isn’t receiving •...
  • Page 79 "TX/RX PANORAMA" slider to provide some program-go feedback (TX) to your headphones. You can also do this from TALENT’s front panel by pressing the left encoder button and then turning the knob to the left until you get the desired feedback level.
  • Page 80 Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. TALENT...
