Summary of Contents for Hewi Bohrlehre
- Page 1 Bohrlehre Installation jig Montageanleitung Mounting instructions...
- Page 2 00 800 4394 4394 (BE, LU, CH appel gratuit, poste fixe) HEWI support 00 800 4394 4394 (BE, LU, NL gratis, vaste lijn) Supporto HEWI 0049 5691 82 0 Soporte HEWI 0049 5691 82 0 Wsparcie HEWI 0048 22 330 0052 2 | HEWI...
- Page 3 ø 6 mm Zentrierdorn | Centering pin ø 9 mm Zentrierdorn | Centering pin KABA ø 7 mm geteilter Zentrierdorn, auch als Verlängerung nutzbar | Split centering pin, also usable as extension ø 7 mm Bohrer | Drill bit HEWI | 3...
- Page 4 Vorbereitung | Preparation ø 10 mm X mm ø 9 mm ø 8,5 mm ø 8 mm ø 7 mm 4 | HEWI...
- Page 5 ø 17 mm Profilzylinder (PZ) Euro cylinder ø 17 mm ø 7 mm Buntbart (BB) Lever key ø 7 mm WC (NR/FB) X mm vacant/engaged ø 8 mm ø 7 mm ø 6 mm ø 5 mm HEWI | 5...
- Page 6 Montage | Mounting Abstand | Distance 72 -92mm 6 | HEWI...
- Page 7 Auswahl Bohrbilder für Schilder und Rosetten siehe Seiten 8-9. Very important to note! Do not drill into or through the lockcase! Drill pattern for backplate and roses see pages 8-9. 90° B B / P Z N R / F B 90° HEWI | 7...
- Page 8 305... 306... 307... 308... Schlossnussmitte Lock center line (square) Schild | Backplate 217...R 305.6.10 U 230...R 230...H 285...R Schlossnussmitte Lock center line (square) Schutzbeschlag (Kurzschild) | Security backplate (short) ...ES1 305.6.10 U Schlossnussmitte Lock center line (square) 8 | HEWI...
- Page 9 305.6.10 U 230...E Schlossnussmitte Lock center line (square) Schild | Backplate 235...R 219...H 305.6.10 U 220...H 235...H 236...H Schlossnussmitte Lock center line (square) Schutzbeschlag (Langschild) | Security backplate (long) ...ES3 305.6.10 U Schlossnussmitte Lock center line (square) HEWI | 9...
- Page 10 10 | HEWI...
- Page 11 HEWI | 11...
- Page 12 Deutschland HEWI Heinrich Wilke GmbH Postfach 1260 D-34442 Bad Arolsen Telefon: +49 5691 82-0 Telefax: +49 5691 82-319 www.hewi.com info@hewi.de G305.03 2021/02...
