LED Low Voltage
50 ft. Linkable
Dusk to Dawn
w/ Adjustable Timer
Landscape Light Kit
PACKAGE CONTENTS
5x
Light
Head
Collar Ring
Quick Connector
1x
50 ft. Main Cord
WARNINGS
WARNING: Do NOT look directly at LED light sources.
WARNING: DO NOT use with extension cords near water or wherever water
may accumulate.
WARNING: ONLY use in a GFCI protected outlet for outdoor utilizations.
WARNING: Avoid using this product in the immediate vicinity of highly
flammable materials, liquids and gases.
WARNING: DO NOT alter or disassemble any of the parts of this fixture. It is
completely enclosed and does not contain replaceable or serviceable parts.
WARNING: This product has a grounded plug (two contact blades and a grounding
prong) as a feature to reduce the risk of electric shock. The plug is fashioned to
only fit in a grounded outlet one way. If it does not fit, contact a qualified electrician.
Never use with an extension cord unless plug can be fully inserted. DO NOT ALTER THE
PLUG OR CORD.
Shroud
Friction Lock
3 ft. Cord
Quick Connector
End Cap
1x
Dusk to Dawn
45W Transformer
Dusk-to-Dawn
Sensor
Plug
Quick
Adapter
5x
Thumbscrew
Ground
Stake
2x
Wood
Screws
LED Features:
Lumens: 1000 (200 each head)
Color Temperature: 5000K
CRI: 70
Efficacy (Lumen Per Watt): 90
Rated Watts: 15W (Total Kit)
LED Emitter Life: 50,000 hours
Operating temperature: -13° to 122°F (-25° to 50° C)
Power Factor: 0.9
Product Features:
Link Up to 3 Sets (15 total heads(45 watts))
Operating Voltage: 110-240v
Operating Time On: 4-6-8 Hours
Quick connect with movable heads
Cord Type: .18/2 SJTW
Total cord length: 50 ft
This fixture is IP65 rated and therefore is suitable for
indoor and outdoor use in wet locations.
1
MODEL No:
LL-200-50D
4-6-8
Hour
Switch
Revision Date: 03-08-2018
6.25 in.
15,87 cm
