Channel Plus 5114 Owner's Manual

Remotely Providing Power to the 5114
Power Supply
350-067
Wire Nuts
Cut off plug
polarity does
not matter
Warranty
Multiplex Technology, Inc., warrants this product to be free from defects
in materials and workmanship for a period of one year from the date of
purchase or MTI will repair or, at its option, replace the defective
product. To obtain warranty service, call MTI for a Return Material
Authorization (RMA) number and return the product pre-paid
accompanied by a copy of the purchase receipt,
Technology, Inc., 3001 Enterprise St., Brea, CA 92621,
Service. Please put the RMA number on the outside of the carton.
Any implied warranty arising from the sale of the product including
implied warranties of merchantability and fitness for purpose are limited
to the warranty stated above. MTI shall not be responsible for any loss,
damages or expenses, whether direct, consequential, or incidental
arising from the use or inability to use this product. Some states do not
allow limitations on how long an implied warranty lasts or the exclusion
or limitation or incidental or consequential damages, so the above
limitations may not apply to you. This warranty gives you specific legal
rights, and you may have other rights which vary from state to state.
600-019A
®
multiplex
technology , inc.
AWG 22
Twisted Pair
(up to 250')
Cut off connector
Model 5114
to Multiplex
Attn: Customer
1/16/96 5114_1.cdr 1/16/96 5114_1.cdr
3001 Enterprise Street, Brea, CA 92621-6213, U.S.A.
714-996-4100 * 800-999-5225 * FAX 714-996-4900
PERFORMANCE MULTI-ROOM VIDEO
Model 5114
In-wall Modulator
Owner's Manual
