Warning
This Quick Start Guide provides general information on IRISNotes
use it on a Windows® PC.
For information on how to use it on a Mac® computer, see the Addendum for Mac version.
For information on how to use IRISNotes
TM
Android
-based Smartphones, see the Addendum for Smartphones.
Detailed instructions on IRISNotes
and help file provided with the installation CD-ROMs.
TM
IRISNotes
is a pen and mobile note taker that allows you to capture, edit, save and export your
handwritten notes and drawings. Your notes can be instantly converted into editable text in a
wide range of languages.
TM
IRISNotes
also allows you to annotate any JPEG photos on your computer, Blackberry and
Google Android-based device.
Package contents
- Note Manager installation CD-ROM
- MyScript Notes Lite installation CD-ROM
- Quick Start Guide
- Digital pen, receiver unit, retractable USB cable, two sets of batteries, three ink refills
The digital pen
! Do not dismantle the pen.
This may damage it.
Slide an ink refill into the pen tip (standard M21 refill of 67.0mm long X 2.35mm) and
press it gently until it is correctly lodged
Quick Start Guide
TM
TM
' full range of functionalities can be found in the user guide
Rubber grip with
mouse click
Pen tip
English
in combination with Blackberry® and Google
Batteries
TM
, and on how to install and
Unscrew the battery
compartment cover and
insert 2 GP SR41 batteries
with positive polarity
facing up
Advertisement
Summary of Contents for IRIS IRISNotes 1.0
- Page 1 Quick Start Guide Warning This Quick Start Guide provides general information on IRISNotes , and on how to install and use it on a Windows® PC. For information on how to use it on a Mac® computer, see the Addendum for Mac version. For information on how to use IRISNotes in combination with Blackberry®...
-
Page 2: The Receiver Unit
To replace the ink refill (the pen cap serves as an ink refill extractor): - Firmly press the top of the cap against the tip of the pen and pull the used ink refill out. - Slide the new ink refill in. The receiver unit ON/OFF button Press for 5 seconds to turn... -
Page 3: Installing The Software
Installing the software Insert the Note Manager CD-ROM in your CD-ROM drive. This CD-ROM contains the Easy Note Taker and Photo Sketcher applications. Select the applications you want to install and follow the on-screen instructions. When the installation is complete, click Finish, then remove the CD-ROM from the CD- ROM drive. -
Page 4: Managing Notes
Uploading notes Connect the receiver unit to your PC (using the USB cable) and start Easy Note Taker. In the Note Manager, click on Upload on the main toolbar. All the notes get uploaded from the receiver to your computer and can be viewed on screen. You can select other preferences for the upload. - Page 5 Using the pen in mouse mode You can set the pen to mouse mode. In this mode, tapping the pen in the writing area or pressing the button on the side of the pen will act like a single mouse click. Pressing and holding the pen down for a moment will act like a right mouse click.
- Page 6 Addendum Using IRISNotes on a Mac® computer Digital pen and receiver unit For a detailed description of the digital pen and the receiver unit, please refer to the IRISnotes Quick Start Guide provided with your IRISnotes package. Using the Digital Pen on a Mac System ...
- Page 7 Notes: Performing a standard installation will install the software directly into your Applications folder on your Mac’s hard drive. If you want to change the location to which the software will be installed, clicking Change Install Location will return you to the previous step, Choose Destination Location. Click Install.
- Page 8 The Digital Pen Preferences dialog consists of the following elements: • The Target Path – displays the path to the location on your Mac’s hard drive where TIFF images from the Digital Pen will be saved. • The Clear Device Memory checkbox – if this checkbox is checked, the Digital Pen’s memory will be cleared (erased) after you upload TIFF images to your Mac.
- Page 9 Digital Pen operation with Mac Step 1 Use the Digital Pen to capture and save your notes while you are away from your Mac, in meetings or lectures. Step 2 Connect the Digital Pen to your Mac to upload the saved notes. The notes are saved in TIFF format.
- Page 10 Addendum Using IRISNotes on Smartphones Warning This Addendum provides guidelines for using IRISNotes on Smartphones. For general information on IRISNotes , see the Quick Start Guide, and for detailed instructions refer to the user guide and help file provided with the installation CD-ROMs. Thanks to its built-in Bluetooth®...
-
Page 11: Pairing Your Bluetooth Devices
6. When the application has been imported, it is listed as Inote in the Applications list. Select it from the list and then click Apply. Inote will now be installed in the Downloads section of your Blackberry. Tip: to move Inote from Downloads to Applications, click the button while in the home screen your Blackberry. - Page 12 (8) You are prompted to enter a passkey. Enter 0000. (9) Press Enter. Your Blackberry is now successfully paired with the digital pen. Using the digital pen in combination with your Blackberry You can either create notes directly on the screen of your Blackberry, or upload them later on. Creating notes on screen (1) Turn on your Blackberry and the pen’s receiver unit.
- Page 13 (4) Click Snapshot to take a picture. (5) Now use the digital pen to write comments on the photos. Note: always make sure the Bluetooth connection is activated. Working with Google Android-based devices Before you can use IRISNotes in combination with your Google Android-based device, you first need to download the mNote application from Android Market.
