- Page 1 EM6010 – MPEG-4 Security Recorder...
-
Page 2: Table Of Contents
2.2 Package contents ....................4 3.0 Setting up the EM6010 ..................4 3.1 Connecting the EM6010 to the power grid ............4 3.2 Connecting the EM6010 to your TV or video monitor.........5 3.3 Configuring the EM6010 for use in your LAN network........6 4.0 First settings ......................7 4.1 Changing administrator and guest code.............7... -
Page 3: Warranty Conditions
When having bought a second- hand Eminent product the remaining period of warranty is measured from the moment of purchase by the product’s first owner. The Eminent warranty applies to all Eminent products and parts inextricably connected to and/or mounted on the main product. -
Page 4: Introduction
User manual 3.0 Setting up the EM6010 The EM6010 comes equipped with a hard disk which you do not need to built in yourself. It is however important that you configure and connect a couple of items before you can start using the EM6010, as explained below. -
Page 5: Connecting The Em6010 To Your Tv Or Video Monitor
3.2 Connecting the EM6010 to your TV or video monitor Now that the EM6010 is connected to the power grid you can also connect it to a television, video monitor or LAN network. In this paragraph we will explain how to connect the EM6010 to a television or monitor. -
Page 6: Configuring The Em6010 For Use In Your Lan Network
ENGLISH 3.3 Configuring the EM6010 for use in your LAN network The EM6010 can be connected to a LAN network, allowing it to be accessed by computers on the network using the supplied software. The default network address of the EM6010 is 192.168.1.10. If this address does not lie in the range of your network or is already in use, consult your network administrator to receive a correct network address. -
Page 7: First Settings
Press the ‘Menu’ button to leave this screen and save the changes to the codes. Important: If you are using the EM6010 in a network, it is also of importance that you change the password of the default network user ‘admin’. Consult chapter 8.2.2 on how to exactly achieve this. -
Page 8: Setting The Date And Time Using A Tv Or Video Monitor
4.3 Setting the date and time using a TV or video monitor Press the red ‘Menu’ button on the remote control. If the EM6010 asks for a code: Enter the Admin code as set in chapter 4.1. Use the ‘Down’ button to navigate to ‘Date’. -
Page 9: Software Installation (Optional)
ENGLISH 4.5 Software installation (optional) Place the CD-ROM as supplied with the EM6010 in the CD-ROM drive of your computer and follow the steps below to install the software. Choose your language and click ‘Next’. Choose ‘Install Java’ and click ‘Next’. -
Page 10: Checking The Camera Image
The image will then be shown full screen. 6.0 Recording Now that the cameras have been installed you can set the EM6010 to record the images. The EM6010 supports three methods of recording. Each method has its own pros and cons. -
Page 11: Manual Recording
Persons will be recognizable if they stand still long enough, but actions can not be monitored. The EM6010 is equipped with an advanced image processor and can automatically switch between images per second during recording. This allows you to constantly record at 3 IPS and switch to 25 IPS during interesting moments. -
Page 12: Time Based Recording
IPS to 25 as soon as motion is detected. 6.5 Recording with motion detection This option allows the EM6010 to start recording using motion detection. As soon as a camera detects motion, the EM6010 starts recording images. If at that time a recording is already running, the IPS will be temporarily increased during the motion detection. -
Page 13: Configuring Motion Detection
Higher values are more sensitive. The maximum is 61 images. ALARM: Determines the polarity of the alarm output on the EM6010. Default setting is off. (The general settings for motion detection are usually sufficient for the motion... -
Page 14: Enabling Recording After Motion Detection
Press the ‘Enter’ button to select ‘Yes’. Press the red ‘Menu’ button twice to leave the menu. The EM6010 will now start recording images as soon as motion is detected. 6.5. Motion detection at certain times / on certain days... -
Page 15: Managing Recorded Video
7.3 Saving a backup to a USB stick The EM6010 can export recorded images to a USB stick, so these can (for instance) be used as evidence. Saving the images to a stick may take a while (about 5 minutes... -
Page 16: Extensive Network Functions
Other brands / types may be incompatible. 8.0 Extensive network functions As stated earlier, the EM6010 is equipped with a network port. This allows it to be managed and configured from within a LAN network. You can accomplish this both by using the ‘Video Server E’... -
Page 17: Using The Video Server Software
After a few seconds the managing page will appear Using the remote control on the left part of the screen you can manage the EM6010. These functions are identical to using a real monitor or remote control. If an analogue monitor is connected at the same time, the settings you change using the computer will also be shown on this monitor. -
Page 18: Configuring The Alarm Mail
Double click ‘Network’. Click ‘FTP’. Enter the data of the FTP server to which the EM6010 needs to save images as soon as motion is detected. (To be able to use this function you need an FTP server and the correct login information. -
Page 19: Saving Images Over The Network
19 | ENGLISH The EM6010 will start to save images to the specified FTP server as soon as motion is detected. 8.2.5 Saving images over the network Login as described in chapter 8.2.1. Click the ‘System Config’ icon. (Upper right part of the screen, next to the photo camera and film.) Double click ‘DVR’... -
Page 20: Service And Support
If so, move the camera further away from the glass or window. Q: If I enter the IP address of the EM6010 in the address bar of Windows Explorer I can open the login screen, but I can not see a live view. - Page 21 To ensure your safety and compliance of the product with the directives and laws created by the European Commission you can obtain a copy of the Declaration of Conformity concerning your product by sending an e-mail message to: info@eminent- online.com. You can also send a letter to: Eminent Computer Supplies P.O.
